Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 3000 x 3000 x 2560 mm | |
|---|---|---|
| Square cross base footprint | 1000 x 1000 x 60 mm | |
| Vertical support post diameter | 48 mm | |
| Canopy rib length (center to edge) | 1500 mm | |
| Support arm offset clearance | 1200 mm | |
| Canopy valance overhang length | 150 mm | |
| Articulated joint section thickness | 60 mm | |
| Unobstructed shaded area under canopy | 9 m² | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Unweighted product net weight | 18 kg | |
|---|---|---|
| Recommended total weighted base load for stability | 70 kg | |
| Canopy UV protection rating | UPF 50+ | |
| Maximum safe wind speed rating (properly weighted) | 56 km/h | |
| Canopy fabric areal weight | 280 gsm | |
| Recommended maximum seated user capacity under shade | 4 people | |
| Frame static load capacity (canopy edge) | 15 kg | |
| Fabric fade resistance service life | 3 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Canopy fabric | 280gsm polyester with PU waterproof coating | |
|---|---|---|
| Offset support arm | Metal core with faux wood grain finish, black powder-coated joint brackets | |
| Support ribs | Powder-coated steel internal ribs for canopy tension | |
| Cross base | Galvanized steel four-arm cross base for weight plate attachment | |
| Joint hardware | Zinc-plated steel bolts, articulating pivot joints for tilt adjustment | |
| Crank lift mechanism housing | UV-stabilized ABS plastic with metal internal gearing | |
| Canopy edge binding | Polyester webbing stitched with UV-resistant polyester thread | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Canopy opening mechanism | Side-mounted crank handle for smooth, incremental canopy deployment | |
|---|---|---|
| Canopy tilt adjustment | 5-position articulated tilt to track sun angle throughout the day | |
| Rotation function | 360° foot-pedal controlled rotation to reposition shade without moving base | |
| Canopy ventilation | Top center air vent to reduce wind lift and improve air circulation | |
| Stabilization system | Cross base compatible with sand/concrete weight plates for wind resistance | |
| Locking mechanism | Positive lock at each tilt and rotation position to prevent unintended movement | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential patio application | Suitable for backyard concrete/wood patio decks to shade dining or lounge sets | |
|---|---|---|
| Commercial outdoor seating | Usable for cafe, restaurant, or beer garden outdoor seating areas with proper weighting | |
| Poolside placement | Water-resistant fabric and rust-resistant frame suitable for pool deck sun shading | |
| Garden courtyard use | Ideal for residential garden courtyards for outdoor relaxation and gathering spaces | |
| Required accessory note | Requires additional compatible weight plates or weighted base for safe operation |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
