Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1600 x 400 x 2100 mm | |
|---|---|---|
| Open shelf depth | 340 mm | |
| Upper open shelf vertical clearance | 350 mm | |
| Individual drawer dimensions (3 units) | 400 x 340 x 150 mm | |
| Lower open cubby vertical clearance | 320 mm | |
| Cabinet door width (curved cutout unit) | 400 mm | |
| Cabinet door width (flat unit) | 400 mm | |
| Recessed LED strip width per shelf | 380 mm | |
| Vertical column divider thickness | 18 mm | |
| Shelf panel thickness | 25 mm | |
| Back panel thickness | 9 mm | |
| Base plinth height | 50 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Per open shelf static load capacity | 18 kg | |
|---|---|---|
| Number of storage bays | 12 | |
| LED color temperature | 3000 K | |
| Anti-tip hardware load rating | 50 kg | |
| Product net weight | 120 kg | |
| Recommended warranty period | 5 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Structural frame and fronts | 18mm E0-grade engineered wood with oak wood grain veneer | |
|---|---|---|
| Cubby back panels | 9mm MDF with matte beige powder coating | |
| Vertical accent divider | 18mm engineered wood with matte grey finish | |
| Shelf surfaces | 25mm thick veneered engineered wood with 1mm PVC edge banding | |
| Drawer slides | Under-mount soft-close full-extension metal slides | |
| Cabinet door hinges | Concealed 110-degree opening metal hinges | |
| Lighting assembly | Recessed 2835 SMD LED strip with frosted diffuser cover | |
| Curved cabinet door pull | Integrated routed wood cutout handle | |
| Base plinth | 25mm engineered wood with matte beige finish | |
| Anti-tip hardware | Zinc-plated steel wall anchor with mounting strap | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Integrated undershelf lighting | Recessed warm white LED strips illuminate each open shelf for display | |
|---|---|---|
| Drawer operation | Three soft-close drawers extend fully for concealed accessory storage | |
| Curved cutout cabinet access | Right-middle cabinet door uses integrated routed pull for handle-free opening | |
| Mixed storage zoning | Upper open bays for display, middle drawers for small items, lower bays for large storage | |
| Adjustable shelf compatibility | Pre-drilled shelf pin holes allow 32mm incremental shelf height adjustment | |
| LED control option | Touch-dimmable power switch located on unit side for brightness adjustment | |
| Wall anchoring | Included anti-tip strap secures unit to wall to prevent forward tipping | |
| Cable management | Hidden rear access notch allows LED power cord routing to wall outlets | |
| Door soft-close function | Concealed hinges pull doors closed gently without slamming | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Living room display wall | Holds decorative objects, books and collectibles with integrated accent lighting | |
|---|---|---|
| Study room library | Stores book collections with mixed open/closed storage to reduce dust buildup | |
| Residential entryway | Displays decor and stores entry accessories in lower closed compartments | |
| Target users | Homeowners and design professionals seeking contemporary mixed storage with display lighting | |
| Recommended placement | Wall-mounted with anti-tip anchors, positioned against flat load-bearing interior walls | |
| Surface care | Wipe clean with soft dry cloth, avoid abrasive cleaners to preserve veneer finish |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particleboard performance specification for structural furniture components | |
|---|---|---|
| EN 14749:2016 | Safety and strength requirements for domestic storage furniture including anti-tip performance | |
| EN 62471:2008 | Photobiological safety standard for integrated LED lighting systems | |
| EN 13722:2004 | Strength and durability test methods for furniture storage units |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural acceptance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, required for indoor air quality compliance | |
| GB/T 4897.3-2015 | Particleboard specification for furniture-grade structural panels used in carcass construction | |
| GB 7000.204-2008 | Safety requirements for built-in LED lighting fixtures used in furniture installations |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural acceptance; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, required for indoor air quality compliance; 3. GB/T 4897.3-2015: Particleboard specification for furniture-grade structural panels used in carcass construction; 4. GB 7000.204-2008: Safety requirements for built-in LED lighting fixtures used in furniture installations; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
