Automatic mm / inch conversion · Core engineering specifications
| Overall unit dimensions | 2400 x 400 x 2000 mm | |
|---|---|---|
| Standard open shelf clear height | 250 mm | |
| Open shelf clear depth | 350 mm | |
| Right frosted glass door compartment width | 600 mm | |
| Central solid door panel width | 600 mm | |
| Left open column width | 600 mm | |
| Center-right open LED column width | 600 mm | |
| Vertical tan accent trim width | 150 mm | |
| Frosted glass door thickness | 5 mm | |
| Carcass panel thickness | 18 mm | |
| Shelf panel thickness | 25 mm | |
| Adjustable shelf pin hole spacing | 32 mm | |
| Base plinth height | 50 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Unit net weight | 85 kg | |
|---|---|---|
| Fixed open shelf static load capacity | 25 kg | |
| LED strip service life | 30000 hours | |
| Recommended maximum uniform load per shelf | 25 kg | |
| Door hinge cycle rating | 80000 open/close cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main carcass construction | 18mm E1-grade engineered wood with dark walnut laminate finish | |
|---|---|---|
| Vertical accent trim | 18mm engineered wood with warm tan matte laminate finish | |
| Right display door | 5mm frosted tempered glass with matching tan edge trim | |
| Shelf surfaces | 25mm laminated engineered wood, matching dark finish, 1mm PVC edge banding | |
| Back panel | 5mm hardboard with dark matte finish, secured to carcass with staples | |
| Door hinges | Cold-rolled steel soft-close concealed hinges, nickel-plated finish | |
| LED lighting components | Low-voltage 2835 SMD LED strips with frosted diffuser cover, recessed under shelves | |
| Cabinet base | 18mm engineered wood plinth with scratch-resistant laminate bottom | |
| Anti-tip hardware | Zinc-plated steel wall anchor straps, 2 included per unit | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Integrated display lighting | Recessed under-shelf warm white LED strips, touch-controlled on/off, 3000K color temperature | |
|---|---|---|
| Mixed storage configuration | 3 open display columns, 1 central solid-door concealed compartment, 1 right frosted-glass display compartment | |
| Shelf adjustability | 3 adjustable shelf positions in frosted glass compartment, fixed shelves in open display zones | |
| Door operation | Solid central door and frosted glass door open 110 degrees via soft-close concealed hinges | |
| Stability safety | 2 wall-mounted anti-tip straps secure unit to wall studs to prevent forward tipping | |
| Surface maintenance | Laminate surfaces wipe clean with dry or lightly dampened cloth, no harsh chemical cleaners required | |
| Display functionality | Frosted glass door diffuses contents while allowing LED light to illuminate stored books and decor | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Executive office backdrop | Installed behind executive desks to store reference books, awards and decorative display items | |
|---|---|---|
| Home office study storage | Used in residential studies to organize books, documents and collectibles with ambient display lighting | |
| Meeting room reference storage | Placed in conference rooms to store meeting materials, presentation resources and corporate decor | |
| Library open-shelf display | Used in small office libraries to organize frequently accessed books with lit display zones | |
| Reception area display | Installed in office reception zones to display company branding, awards and informational materials |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements, structural stability and load performance | |
|---|---|---|
| EN 312:2010 | Particleboard specifications for load-bearing furniture applications | |
| EN 14749:2016 | Domestic and kitchen storage units safety, anti-tip and structural integrity requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture performance standard, shelf load and stability test methods | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, formaldehyde and material content criteria |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel structural strength and finish quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, requires E1 or better emission rating | |
| GB/T 4897.3-2003 | Particleboard specifications for furniture use, applicable for carcass panel structural performance | |
| GB 28007-2011 | Safety requirements for children's and adult freestanding furniture, anti-tip performance criteria |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel structural strength and finish quality; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, requires E1 or better emission rating; 3. GB/T 4897.3-2003: Particleboard specifications for furniture use, applicable for carcass panel structural performance; 4. GB 28007-2011: Safety requirements for children's and adult freestanding furniture, anti-tip performance criteria; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
