Nordic Light Oak Solid Wood TV Media Console with Central Drawers and Open Side Shelves Specifications

TVC-NORD-OAK-1800

代码:X8ATUSV1
获取供应商报价
2026-08-16 14:53人气: 22
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

TVC-NORD-OAK-1800

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall dimensions1800 x 450 x 480 mm
Leg height150 mm
Under-unit floor clearance130 mm
Central drawer front dimensions (per drawer)450 x 120 mm
Side open shelf dimensions (per side)600 x 400 x 200 mm
Top panel thickness30 mm
Lower shelf panel thickness20 mm
Back panel thickness9 mm
Drawer internal usable depth380 mm
Carcass Panel Thickness25 mm
Door / Drawer Front Thickness22 mm
Shelf Thickness25 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Top surface static load capacity50 kg
Product net weight38 kg
Drawer slide cycle rating30000 open/close cycles
Recommended maximum TV screen size75 inches
Available finish color options4
Open shelf load surface height above floor150 mm
Shelf Distributed Load30 kg/shelf
Drawer Slide Load / Life45 kg/pair; 50000 cycles
Hinge Opening Angle / Life165°; 80000 cycles
Anti-tip Fixing ReferenceProducts above 1200 mm should use at least 2 wall fixing points
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Top panelSolid FSC-certified oak/ash hardwood, natural matte oil finish, 30mm thickness
Body carcassSolid oak/ash hardwood frame, mortise and tenon joinery, no added veneer
Drawer frontsSolid oak/ash hardwood, flush handleless push-to-open edge profile
Lower open shelvesSolid oak/ash hardwood, rounded front edges, 20mm thickness
Support legsSolid oak/ash tapered angled legs, splayed outward for stability
Drawer slidesCold-rolled steel full-extension side-mount slides, zinc plated finish
Back panelSolid wood veneered MDF dust back, pre-drilled cable pass-through cutouts
Surface treatmentLow-VOC natural matte wood oil, scratch-resistant top coat
Edge Band Thickness2 mm
Primary Connector SpecificationReference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints
Reference Finish / Color CountRecommended 6finish options
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Central storageTwo equal-width soft-closing drawers for media accessory and remote storage
Side open storageTwo lower open side shelves for media devices, books and display decor
Cable management60mm diameter pre-cut cable pass-through openings at back of open shelves
Floor protectionFelt pads pre-installed on leg bases to prevent hardwood floor scratching
Cleaning access130mm under-unit clearance allows robot vacuum and mop access under full unit
Assembly requirementOnly 4 legs require screw-on installation, body ships fully pre-assembled
Leveling adjustmentSmall adjustable glide feet on leg bases to compensate for uneven floors
Cable / Vent Opening Reference80 mm diameter; recommend 4rear cable/vent openings
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Package Dimensions2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight100 kg/set in 3 cartons
Reference Packaging Volume0.65 m³/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Living room media placementPositioned against a wall facing 3seat sofas for TV and media equipment display
Small to medium apartment useLow-profile open storage design fits compact Nordic style urban living rooms
Scandinavian/Japanese wabi-sabi interiorsLight natural wood finish complements light fabric sofas and neutral-toned decor
Low-height display useOpen lower shelves can hold books, decor items and AV receivers without blocking sightlines
Combined living room setCan be paired with matching solid wood coffee tables, side tables and fabric sofa sets
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 312:2010Particleboard and fibreboard performance requirements, applicable for wood-based panel components if used
EN 14749:2016Domestic and kitchen storage units and worktops safety requirements, applicable for storage safety
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for wooden furniture, applicable for dimensional and structural acceptance
GB 18584-2001Indoor decoration material formaldehyde emission limit for wooden furniture, required for indoor use acceptance
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable for dimensional and structural acceptance;
2. GB 18584-2001:Indoor decoration material formaldehyde emission limit for wooden furniture, required for indoor use acceptance;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · TVC-NORD-OAK-1800

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · TVC-NORD-OAK-1800

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · TVC-NORD-OAK-1800打开导出工具

页面快速操作

发布采购询价

产品描述

The Nordic Light Oak Solid Wood TV Media Console from Zhenxi Muye (model TVC-NORD-OAK-1800) delivers understated Scandinavian minimalist appeal with a streamlined low-profile silhouette, measuring 1800 x 450 x 480 mm. The design features a 30mm-thick solid hardwood top, two central flush handleless push-to-open drawers, and symmetric lower open side shelves set atop splayed, tapered angled solid wood legs that angle outward for balanced visual weight and structural stability. The 150mm open shelf height sits level with the top of the leg structure, maintaining clean, unbroken visual lines across the unit’s front face. Constructed with a solid FSC-certified oak or ash hardwood frame joined with traditional mortise and tenon joinery and no added surface veneer, the console uses solid hardwood for its top, drawer fronts, and 20mm-thick rounded-edge lower shelves. The 9mm solid wood veneered MDF back panel includes pre-cut cable management openings, while cold-rolled steel zinc-plated full-extension slides support each drawer, rated for 30000 open/close cycles. All wood surfaces are treated with low-VOC natural matte oil and a scratch-resistant top coat, with 2mm edge banding for durable wear. Felt pads and small adjustable glide feet come pre-installed on leg bases, with 130mm of under-unit clearance to support easy cleaning access. Functionally, the unit’s two equal-width central soft-closing drawers store media accessories and remotes, while the two side open shelves each support 30 kg of distributed weight for media devices, books, or display decor. The 50 kg static load top surface accommodates televisions up to 75 inches, with 60mm diameter rear cable pass-throughs to organize wiring for connected equipment. Only the four legs require screw-on installation, as the main body ships fully pre-assembled for a 40-minute setup time. This console is ideally suited for small to medium urban apartments, fitting seamlessly against living room walls facing three-seat sofas, and complementing Scandinavian, Japanese wabi-sabi, or light neutral interior schemes paired with fabric sofas and matching solid wood occasional furniture. When procuring, note the product ships across 2 cartons (reference packaged gross weight listed as 100 kg per set across packaging splits, total packaging volume 0.65 m³), and select from 4 available finish options to match existing decor. The low open shelf design ensures placed AV equipment and decor do not block sightlines for comfortable media viewing.
