基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 3600 × 2050 × 760 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Main work surface depth | 1000 mm | |
| Side return extension width | 1500 mm | |
| Seated knee clearance height | 650 mm | |
| Knee clearance width | 1600 mm | |
| Left pedestal dimensions | 800 x 630 x 650 mm | |
| Right pedestal dimensions | 1500 x 630 x 650 mm | |
| Edge banding thickness | 2 mm | |
| Metallic trim section width | 50 mm | |
| Cable grommet diameter | 80 mm | |
| Base LED strip height above floor | 20 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Storage cabinet door hinge cycle rating | 80000 cycles | |
| High-gloss surface Taber abrasion resistance | 1000 cycles | |
| Recommended maximum user weight support | 150 kg | |
| Commercial warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Desktop core substrate | 25mm high-density MDF board | |
|---|---|---|
| Desktop surface finish | High-gloss UV-cured lacquer over burl wood veneer | |
| Front facade panels | Burl wood veneer with horizontal metallic brushed steel trim | |
| Pedestal side panels | Matte metallic lacquered MDF | |
| Edge trim | Solid stainless steel accent strips | |
| Storage hardware | Soft-close full-extension ball-bearing drawer slides | |
| Integrated lighting | 3000K warm white LED strip recessed at base | |
| Storage lock mechanism | Fingerprint biometric drawer lock | |
| Leveling feet | 15mm adjustable stainless steel glides | |
| Internal drawer components | 18mm melamine-faced MDF | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Storage configuration | 4 drawers + 2 enclosed cabinet compartments across two pedestals | |
|---|---|---|
| Cable management system | 2 desktop cable grommets + under-desk segmented cable tray | |
| Drawer operation | Soft-close full-extension drawers with fingerprint lock access | |
| Base accent lighting | Integrated dimmable warm white LED strip | |
| Leveling adjustment | Adjustable glides on all pedestal base corners | |
| Side return use case | Extended secondary work surface for guest meetings or additional office equipment | |
| Desktop surface resistance | Scratch, stain and chemical resistant high-gloss lacquer | |
| Return orientation | Right-side fixed return extension | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Primary application space | Private CEO, chairman or executive director office | |
|---|---|---|
| Matching suite recommendation | Pairs with matching high-back executive leather chair, guest chairs and display credenza | |
| Suitable user profile | C-suite executives, senior management, boardroom leadership | |
| Use case support | Supports daily computer work, document signing, small in-desk guest meetings and secure document storage | |
| Recommended office size | Minimum 30 sqm private office space | |
| Finish matching | Coordinates with dark wood, metallic gray and leather office interior finishes |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 527-1:2011 | Office work tables safety and strength requirements for commercial office desk performance | |
|---|---|---|
| EN 14749:2016 | Domestic and kitchen storage units worktops safety requirements for desk storage components |
北美市场采购验货参考 * ANSI/BIFMA 标准
美国及加拿大家具标准
| ANSI/BIFMA X5.5-2021 | Desk products standard for static load, durability and stability testing for commercial use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer cycle, load and safety performance of pedestals |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel and veneer desk construction | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard/MDF requirements for furniture-grade substrate used in desk panels | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to panel and veneer desk construction; 2. GB/T 4897.3-2015:Particleboard/MDF requirements for furniture-grade substrate used in desk panels; 3. GB 18584-2001:Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture; 最终交付参数、检测报告和验收标准以双方采购合同为准。
