基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 1800 × 800 × 750 mm | |
|---|---|---|
| Overall desk dimensions | 1800 x 800 x 750 mm | |
| Desktop thickness | 25 mm | |
| Edge banding thickness | 2 mm | |
| Under-desk knee clearance height | 620 mm | |
| Under-desk knee clearance width | 1200 mm | |
| Under-desk knee clearance depth | 500 mm | |
| Metal leg wall thickness | 2.0 mm | |
| Metal leg outer diameter | 60 mm | |
| Mobile storage pedestal dimensions | 450 x 560 x 650 mm | |
| Mobile pedestal drawer internal height | 270 mm | |
| Desktop corner radius | 30 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Complete set net weight | 110 kg | |
|---|---|---|
| Distributed static desktop load capacity | 200 kg | |
| Drawer slide open/close cycle rating | 50000 cycles | |
| Structural warranty period | 5 years | |
| Desktop surface pencil hardness | 3H | |
| Metal leg salt spray resistance duration | 100 hours | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Desktop substrate | E1-grade medium-density fiberboard | |
|---|---|---|
| Desktop surface finish | 0.6mm natural walnut wood veneer with matte lacquer | |
| Desk legs | Brushed 304 stainless steel round tubing | |
| Edge trim | Solid walnut wood edge banding with rounded profile | |
| Partial modesty panel | Walnut veneer finished MDF panel | |
| Pedestal frame and drawer fronts | Matte grey lacquered MDF with metallic finish | |
| Drawer hardware | Cold-rolled steel 3-section ball-bearing slides | |
| Drawer lock | Brushed steel central drawer lock with key | |
| Pedestal base glides | Nylon anti-scratch adjustable floor glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Work surface configuration | Fixed-height flat rectangular top for single executive user | |
|---|---|---|
| Mobile pedestal storage | 2 lockable drawers plus 1 open side compartment for office bags | |
| Pedestal mobility | 4 hidden swivel casters under pedestal base for repositioning | |
| Drawer operation | Silent 3-extension full-extension slides for complete file access | |
| Floor protection | Adjustable non-marking glides on desk legs for uneven floor leveling | |
| Assembly method | Knock-down cam-lock and bolt connection for flat-pack transport | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Executive private office | Fits 1.8m width workspace for manager/CEO daily document and computer work | |
|---|---|---|
| Open-plan manager workstation | Pairs with ergonomic executive chair for professional open office leadership space | |
| Small meeting room leader desk | Serves as primary work surface for small in-office meeting and discussion settings | |
| Recommended configuration | Pair with 1 executive office chair, 2 visitor chairs, and matching office storage cabinets | |
| Commercial office project use | Suitable for corporate, government, and co-working space outfitting projects |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| Office furniture work surface strength | EN 527:2002, static load and stability for office desks | |
|---|---|---|
| Office furniture storage unit safety | EN 14073:2004, stability and strength for office storage | |
| Formaldehyde emission from wood panels | EN 13986:2004, E1 class for indoor construction products |
北美市场采购验货参考 * ANSI/BIFMA 标准
美国及加拿大家具标准
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| Wood-based panel formaldehyde emission | GB 18580E1 grade, ≤0.124mg/m³ | |
|---|---|---|
| Medium-density fiberboard substrate | GB/T 11718suitable for painted veneer furniture | |
| Wood furniture surface coating performance | GB/T 3324adhesion class 1, hardness ≥2H | |
| Metal furniture structural strength | GB/T 3325static load and stability requirements |
本产品须满足以下技术参数要求: 1. Wood-based panel formaldehyde emission:GB 18580E1 grade, ≤0.124mg/m³; 2. Medium-density fiberboard substrate:GB/T 11718suitable for painted veneer furniture; 3. Wood furniture surface coating performance:GB/T 3324adhesion class 1, hardness ≥2H; 4. Metal furniture structural strength:GB/T 3325static load and stability requirements; 最终交付参数、检测报告和验收标准以双方采购合同为准。
