PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源：工厂资料结构化字段，最终以实测值为准

产品外部尺寸（宽 × 深 × 高）	2400 × 1800 × 1150 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源：产品性能数据，采购前请核对具体测试口径

Product net weight	185 kg
Total desktop static load capacity	150 kg
Height adjustment stroke	390 mm
Recommended number of users	1
Lift adjustment cycle lifespan	10000 cycles
Laminate surface abrasion resistance	2000 cycles
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Life	Acceptance target 80000 cycles
Top Abrasion Reference	Acceptance target ≥4,000 abrasion cycles or finish-system test

PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源：以工厂材质清单与验货报告为准

Work surface	25mm E1 grade particleboard with light oak wood grain melamine finish, 2mm PVC edge banding
Edge trim and plinths	1.2mm powder-coated light gray steel, matte finish
Lift support columns	3mm thick steel rectangular columns, powder-coated gray
Left pedestal cabinet panels	18mm E1 grade particleboard with matching oak melamine, soft-close hinges
Right pedestal drawer fronts	18mm E1 grade particleboard with matching oak melamine, steel drawer slides
Central modesty panel	18mm MDF with light beige matte laminate finish
Recessed cable port	ABS plastic with brush strip insert, dark gray finish
Drawer lock	Zinc alloy keyed cam lock, 2 keys per unit
Pedestal base plinth	1.5mm powder-coated steel, light gray matte finish
Lift motor	DC 24V electric motor, integrated control system
Primary Panel Thickness	25 mm; load-bearing top may use 40 mm composite build-up
Edge Band Thickness	2 mm

PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源：功能配置参数，以供应商正式规格为准

Height adjustment	Electric dual-motor lift, adjusts work surface from 760mm to 1150mm, 38mm/s travel speed
Height memory preset	4 programmable memory positions for one-touch height adjustment
Right pedestal storage	Upper stationery drawer and lower hanging file drawer, soft-close slides, keyed lock on upper drawer
Left pedestal storage	Two soft-close hinged doors, one adjustable internal shelf for general storage
Cable management	Recessed desktop cable port with brush strip, integrated under-desk cable tray to route power and data cables
Anti-collision function	Obstacle detection during height adjustment stops movement within 20mm of contact
Overload protection	System cuts power when load exceeds 120kg to protect lift motor
Levelling feet	Adjustable 10mm travel glides on base plinths to compensate for uneven floors
Cable Management Capacity	Reference capacity 10power/data cables; tray load 10 kg
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源：外贸报价与装柜测算参考

Total shipping gross weight	210 kg
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源：依据产品结构与品类整理的推荐应用场景

Executive private office	Fits 20sqm private executive offices, provides sufficient work and storage space for senior management
Standing-sit workstation	Electric height adjustment supports alternating seated and standing work to reduce sedentary fatigue
Manager meeting area	L-shape layout supports small 3person informal meetings across the desk corner
Premium open office workstation	Suitable for high-end open plan team leader workstations with integrated storage to reduce additional cabinet needs
Modern corporate headquarters	Light oak wood grain and gray metal trim matches contemporary commercial office design schemes

STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

Office desk strength and durability	EN 527:2002 Office work tables - Safety, strength and durability requirements
Height-adjustable desk stability	EN 527:2003 Office work tables - Test methods for stability and mechanical strength
Wood-based panel formaldehyde emission	EN 13986:2004 Wood-based panels for use in construction - Formaldehyde release Class E1

STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.5

STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

Desktop panel formaldehyde emission	GB/T 39600E1 grade requirement
Desk structural stability	GB/T 3324General technical requirements for wooden furniture
Lift mechanism electrical safety	GB 4706.1Safety of household and similar electrical appliances
Surface coating adhesion	GB/T 4893.4Furniture surface paint film adhesion test

招标文件标准化描述文本

本产品须满足以下技术参数要求：
1. Desktop panel formaldehyde emission：GB/T 39600E1 grade requirement；
2. Desk structural stability：GB/T 3324General technical requirements for wooden furniture；
3. Lift mechanism electrical safety：GB 4706.1Safety of household and similar electrical appliances；
4. Surface coating adhesion：GB/T 4893.4Furniture surface paint film adhesion test；
最终交付参数、检测报告和验收标准以双方采购合同为准。

GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告，可选择公制或英制单位。

PDF · LSH-EXE-2400-LIFT

完整参数 Excel

导出全部商品信息与参数模块，文件内容统一使用英文。

XLSX · LSH-EXE-2400-LIFT

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段，可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · LSH-EXE-2400-LIFT打开导出工具

页面快速操作

发布采购询价

产品描述

The L-Shaped Lift Executive Office Desk (model LSH-EXE-2400-LIFT) is an unbranded height-adjustable executive workspace solution defined by clean modern lines and a purpose-built asymmetrical layout. Its light oak wood grain melamine work surfaces pair with matte light gray powder-coated steel trim and plinths, complemented by a light beige matte laminate central modesty panel for a polished, professional aesthetic aligned with contemporary corporate design standards. The finished desktop measures 50mm thick, supported by 80mm main lift columns with 2mm metal wall construction; each primary seating position offers 680mm of knee clearance height and 900mm of knee clearance width for unobstructed movement.
Constructed with durable, commercial-grade materials, the desk’s work surface uses 25mm E1 grade particleboard with 2mm PVC edge banding, built to withstand 2000 abrasion cycles for long-term daily use. Lift support columns are formed from 3mm thick powder-coated gray steel, with a steel lift mechanism rated for 10000 adjustment cycles. Storage components use 18mm E1 grade particleboard with matching oak melamine finishes: the left pedestal features soft-close hinged doors with one adjustable internal shelf, while the right pedestal holds an upper keyed-locking stationery drawer (fitted with a zinc alloy cam lock and two included keys) and lower soft-close hanging file drawer on steel slides. The recessed 80mm diameter cable port uses dark gray ABS with a brush strip insert, paired with a 120mm deep integrated under-desk cable tray to organize power and data lines.
The electric dual-motor lift system adjusts the work surface from 760mm to 1150mm at 38mm per second, with 4 programmable memory positions for one-touch height changes. Integrated anti-collision detection stops movement within 20mm of contact with obstacles, and overload protection cuts power when loads exceed 120kg to preserve motor function. The desktop supports 150kg of uniformly distributed static load, suitable for single user operation.
This desk fits 20sqm private executive offices for senior leadership, functions as a sit-stand workstation to reduce sedentary fatigue, supports small 3-person informal meetings at its corner, serves as a premium open-plan team leader workstation with built-in storage to eliminate extra cabinet needs, and aligns with modern corporate headquarters design schemes.
For procurement, note the desk ships as one set across cartons, with a 40-minute assembly time per unit and 1 cubic meter total packaging volume. The total net product weight is 185kg, with a shipping gross weight of 210kg, so teams should plan for appropriate delivery and installation support to align with project timelines and space requirements.

L-Shaped Lift Executive Office Desk Specifications
