基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 2800 × 2000 × 760 mm | |
|---|---|---|
| Worktop thickness | 36 mm | |
| Main work surface depth | 900 mm | |
| Left storage return width | 1200 mm | |
| Left storage return depth | 600 mm | |
| Knee well width | 1600 mm | |
| Knee well minimum height clearance | 650 mm | |
| Right cylindrical support leg diameter | 120 mm | |
| Fluted front apron panel height | 320 mm | |
| Cable grommet diameter | 80 mm | |
| Drawer interior depth | 450 mm | |
| Edge band thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Static uniform worktop load | 152 kg | |
|---|---|---|
| File drawer slide static load | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Cable tray static load capacity | 10 kg | |
| Desk net weight reference | 160 kg | |
| Finish abrasion resistance | 2000 cycles | |
| Recommended maximum user weight for seated use | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Main worktop substrate | E1-grade MDF core with dark walnut wood veneer finish | |
|---|---|---|
| Left return pedestal cladding | Top-grain saddle leather in caramel tan finish with dark metal trim | |
| Front fluted apron panel | Powder-coated dark grey aluminum alloy with vertical rib texture | |
| Right support leg | Thick-walled cylindrical dark powder-coated steel | |
| Storage drawer fronts | Leather-matched MDF panel with soft-close hardware | |
| Worktop edge trim | Solid wood edge banding stained to match veneer tone | |
| Integrated lighting diffuser | Frosted polycarbonate cover for warm white LED strips | |
| Pedestal base plinth | Matte dark lacquered MDF with leveler feet | |
| Drawer slide hardware | Cold-rolled steel ball-bearing full-extension slides | |
| Cable management grommets | Brushed dark metal finished ABS grommets | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Fixed height work surface | 760 mm finished height aligned to ergonomic seated office work use | |
|---|---|---|
| Left fixed storage return | Integrated 3-drawer pedestal including locking hanging file drawer | |
| Integrated under-apron LED lighting | Warm 3000K accent strip with hardwired low-voltage power supply | |
| Desktop cable management | Dual desk surface grommets routing to under-desk cable tray | |
| Soft-close drawer mechanism | Soft-close slides prevent slamming, full extension for full file access | |
| Lockable central storage drawer | Central keyed lock secures file and supply drawers for document security | |
| Adjustable floor levelers | Base levelers correct for uneven office floor surfaces | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Executive private office | Suited for CEO or senior management private offices with premium luxury interior design | |
|---|---|---|
| Corporate boardroom ancillary space | Suitable for high-end boardroom supporting work area for meeting preparation | |
| High-end home office | Appropriate for luxury residential home offices requiring executive-level workspace | |
| Private client meeting office | Ideal for professional service offices hosting high-value client meetings | |
| Recommended companion seating | Pairs with ergonomic high-back executive leather office chairs and matching lounge seating | |
| Recommended matching storage | Coordinates with fluted-front matching back wall bookcases and display cabinets |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 527-2:2019 | Office work tables dimensional safety and ergonomic clearance requirements | |
| EN 13722:2004 | Furniture strength and durability for storage units integrated into office desks |
北美市场采购验货参考 * ANSI/BIFMA 标准
美国及加拿大家具标准
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard applicable to integrated drawer pedestal | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and recyclability |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to desk structure and finish | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, required for E1-grade substrate verification | |
| GB/T 4897.3-2003 | Particleboard specification for furniture use, applicable to structural panel components |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden office furniture, applicable to desk structure and finish; 2. GB 18580-2017:Formaldehyde emission limit for wood-based panels, required for E1-grade substrate verification; 3. GB/T 4897.3-2003:Particleboard specification for furniture use, applicable to structural panel components; 最终交付参数、检测报告和验收标准以双方采购合同为准。
