Fixed-Height L-Shaped Executive Desk with Left Return Pedestal and Modesty Panel,型号 EXD-L2400-ANGLE-LG,归属“CEO Executive Desk”栏目,整体尺寸 2400 × 1800 × 750 mm,主材为Particle‑board (PB)。承重参数:120 kg。认证标签:Modern,executive,style,L-shaped,fixed-height,design,left-side,storage,pedestal,modesty,panel,integrated,cable,management。本页汇总该型号 6 类产品参数及 GB / EN / ANSI/BIFMA 标准参考,支持公制与英制单位切换,目前已登记 1 家供应商,可直接发起询价。
| 纠错时间 | 修改字段 | 原参数 | 修改后参数 | 说明 / 状态 |
|---|---|---|---|---|
暂无参数纠错记录,发现错误可点击行末旗标提交 | ||||
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| Overall footprint | 2400 x 1800 x 750 mm | |
|---|---|---|
| Main desktop thickness | 50 mm | |
| Edge band thickness | 2 mm | |
| Main work surface depth | 900 mm | |
| Left return pedestal width | 1200 mm | |
| Left return pedestal depth | 600 mm | |
| Return pedestal height | 700 mm | |
| Central knee clearance width | 1200 mm | |
| Knee clearance height | 600 mm | |
| Modesty panel thickness | 25 mm | |
| Angular support leg section | 100 x 50 mm | |
| Cable grommet diameter | 80 mm | |
| Adjustable foot adjustment range | 10 mm | |
| Drawer internal dimensions (box) | 330 x 350 x 150 mm | |
| File drawer internal dimensions | 330 x 350 x 280 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Total product net weight | 180 kg | |
|---|---|---|
| Desktop distributed static load | 120 kg | |
| Drawer slide load rating | 30 kg per drawer | |
| Drawer slide cycle rating | 50000 cycles | |
| Cable tray load capacity | 10 kg | |
| Recommended user weight capacity | 150 kg | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Warranty period | 36 months | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Desktop surface | E1-grade MDF substrate with matte grey-beige melamine laminate | |
|---|---|---|
| Edge trim | 2mm thick ABS impact-resistant edge banding | |
| Support legs | Powder-coated steel with angular sculpted form | |
| Storage return carcass | E1-grade particleboard with matching two-tone grey-beige melamine finish | |
| Modesty panel | 16mm thick engineered wood with matching matte finish | |
| Hardware components | Zinc-plated steel screws, soft-close hinges, full-extension ball-bearing drawer slides |
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Height adjustment | Fixed 750mm work surface height | |
|---|---|---|
| Storage configuration | 2 utility drawers and 1 hanging file drawer in left return pedestal | |
| Cable management | 2 surface cable grommets with under-detachable cable tray | |
| Floor leveling | 4 adjustable feet at support bases |
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Primary application space | Private executive offices and director suites | |
|---|---|---|
| Recommended supporting furniture | High-back executive ergonomic chairs and matching wall storage bookshelves |
欧洲市场准入与化学品要求
| EN 527-2:2002+A1:2018 | Office worktables safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 14372:2004 | Office furniture storage units safety and durability, applicable to return pedestal |
美国及加拿大家具标准
| ANSI/BIFMA X5.5-2021 | Desk products safety and durability standard, recommended for commercial office grade |
|---|
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural safety | |
|---|---|---|
| GB/T 4897-2015 | Particleboard specification, applicable to engineered wood substrate quality | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to indoor air quality |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to desk structural safety; 2. GB/T 4897-2015:Particleboard specification, applicable to engineered wood substrate quality; 3. GB 18580-2017:Formaldehyde emission limits for wood-based panels, applicable to indoor air quality; 最终交付参数、检测报告和验收标准以双方采购合同为准。
