基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 2800 × 2200 × 750 mm | |
|---|---|---|
| main work surface depth | 900 mm | |
| side return width | 1200 mm | |
| side return depth | 600 mm | |
| desktop thickness | 50 mm | |
| edge band thickness | 3 mm | |
| knee well clearance height | 650 mm | |
| knee well clearance width | 1200 mm | |
| modesty panel height | 450 mm | |
| metal support leg base plate thickness | 10 mm | |
| metal support panel thickness | 2 mm | |
| wood veneer thickness | 0.6 mm | |
| cable grommet diameter | 80 mm | |
| storage drawer internal depth | 450 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| desktop static load capacity | 300 kg | |
|---|---|---|
| undermount drawer slide load rating | 45 kg | |
| drawer slide cycle rating | 50000 operations | |
| cabinet hinge cycle rating | 80000 operations | |
| finish abrasion resistance | 2000 cycles | |
| product net weight | 250 kg | |
| recommended user weight capacity | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| desktop substrate | E1 grade MDF core | |
|---|---|---|
| desktop surface | 0.6mm dark walnut wood veneer with matte UV coating | |
| work surface inlay | Top-grain leather desk pad integrated into desktop | |
| support structure | Matte light grey cold-rolled steel panel legs | |
| modesty panel | Wood veneer accent panel with metal frame trim | |
| left storage pedestal | Matching MDF core with matte grey paint finish | |
| drawer slides | Soft-close full-extension cold-rolled steel undermount slides | |
| cabinet locks | Mechanical combination lock for secured drawer storage | |
| edge trim | 3mm PVC rounded edge banding matching wood finish | |
| base feet | Adjustable stainless steel leveling glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| fixed-height work surface | 750mm standard seated office working height | |
|---|---|---|
| left side return storage | Multi-drawer pedestal with lockable compartment | |
| concealed cable management | Undermount cable tray with 80mm desktop grommets | |
| embedded power module | Integrated AC outlets and dual USB charging ports | |
| soft-close drawer operation | Self-closing mechanism prevents slamming and reduces noise | |
| central knee well access | Open unobstructed leg space for seated executive use | |
| leveling adjustment | Adjustable base feet correct for uneven floor surfaces | |
| modesty panel coverage | Front panel blocks view of seated legs from office entry | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| executive private office | Suitable for CEO, president, or senior management workspaces | |
|---|---|---|
| corporate headquarters | Ideal for finance, real estate, and technology firm executive suites | |
| luxury home office | Appropriate for high-end residential executive workspaces | |
| recommended pairing | Matches high-back leather executive office chairs and matching lateral file cabinets | |
| minimum space requirement | Room size of 4000 x 3500 mm | |
| surface use case | Supports laptop, dual monitors, desk pad, and document work |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 527-1:2011 | Office worktables safety and strength requirements | |
|---|---|---|
| EN 527-2:2019 | Office worktables dimensional safety and clearance requirements | |
| EN 13722:2004 | Office furniture storage units performance requirements |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 3327-2018 | Office desks and tables physical and chemical performance tests | |
| GB 4943.1-2022 | Safety requirements for integrated IT/power components |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden office furniture; 2. GB 18580-2017:Formaldehyde emission limits for wood-based panels; 3. GB/T 3327-2018:Office desks and tables physical and chemical performance tests; 4. GB 4943.1-2022:Safety requirements for integrated IT/power components; 最终交付参数、检测报告和验收标准以双方采购合同为准。
