Backless Bar Stool with Light Gray Molded Seat and Bent Wood Legs Specifications

BS-BW076-LG-NB

代码:RLCDYBV1
获取供应商报价
2026-08-26 15:52人气: 15
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

BS-BW076-LG-NB

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall dimensions480 x 400 x 760 mm
Floor to seat height760 mm
Seat surface width460 mm
Seat surface depth380 mm
Footrest height from floor280 mm
Leg splay width at floor500 mm
Leg material thickness25 mm
Footrest bar diameter10 mm
Finished Seat Cushion Thickness90 mm
Backrest Padding Thickness70 mm
Lumbar Support Zone Height240 mm
Clear Width Between Armrests540 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Unit net weight7 kg
Maximum static user load150 kg
Seat surface uniform load capacity200 kg
Leg structure static stability load180 kg
Recommended user weight120 kg
Abrasion resistance of seat surface30000 cycles
Floor protection pad load per leg40 kg
Product warranty period365 days
Seat Foam Density / Rebound Reference45 kg/m³ / 65%
Back Foam Density Reference38 kg/m³
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Seat componentMatte light gray molded polypropylene
Leg structureNatural walnut-tone bent plywood
Footrest frameBlack powder-coated square steel tubing
Seat-to-leg fastenersZinc-plated steel hardware
Leg foot padsNon-slip thermoplastic rubber
Wood leg finishClear matte lacquer coating
Steel footrest finishElectrostatic powder coating
Seat edge treatmentRounded polished molded edge
Seat Internal Support Board Thickness14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness14 mm bent plywood/composite reinforced frame
Gas-lift Engineering SpecificationRecommended Class 4; outer tube 50 mm; stroke 100 mm
Tilt Mechanism Plate Thickness2.5 mm cold-rolled steel
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Height adjustmentFixed non-adjustable 760mm seat height
Foot support functionIntegrated square steel footrest ring
Seat ergonomicsShallow curved dish-shaped seat
Stability performanceOutward-splayed four-leg base
Floor protectionNon-marking rubber foot pads
Cleaning functionWipe-clean non-porous seat surface
Space storagePartial nesting capability
Assembly requirementKnock-down assembly with included hardware
Recline Angle / Lock Reference125° with 3suggested lock positions
Tilt Tension User-weight RangeReference adjustment coverage 120 kg
Rotation / Mobility Configuration360° swivel with 5-caster multidirectional movement
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Carton Dimensions850× 420× 720 mm
Reference Packaged Gross Weight23 kg/set
Reference Carton Volume0.26 m³/set
Indicative 20GP Loading135 sets at 85% space utilization
Indicative 40HQ Loading320 sets at 85% space utilization
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Residential kitchen bar areaSuitable for fixed-height home breakfast bars and kitchen island seating
Commercial cafe and bar useDurable easy-clean design suitable for high-traffic hospitality seating areas
Co-working breakout spaceMinimalist design fits modern flexible work casual seating zones
Small apartment dining nookCompact footprint fits tight elevated dining spaces with limited floor area
Recommended pairing surfaceSuitable for 1100 mm high bar tables and counter surfaces
Indoor use onlyNatural wood and steel construction not rated for outdoor weather exposure
Seating configurationRecommended sold in sets of 2 or 4 for home and commercial bar installations
Recommended Matching Desk Size2.4 m executive desk
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 12520:2015Furniture – Strength, durability and safety for domestic seating, applicable to structural testing
EN 1022:2018Furniture – Seating – Determination of stability, applicable to anti-tip performance verification
EN 16139:2013Furniture – Strength, durability and safety for non-domestic seating, for hospitality use cases
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.1-2017General purpose office chairs – Tests for backless seating strength and stability
ANSI/BIFMA X5.4-2020Lounge and public seating – Applicable for commercial/bar area seating durability
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for wooden furniture, applicable to bent plywood leg structural integrity
GB/T 24821-2009Safety requirements for public seating, applicable to strength and stability verification
GB 18584-2001Limit of harmful substances in wooden furniture, applicable to formaldehyde emission testing
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to bent plywood leg structural integrity;
2. GB/T 24821-2009:Safety requirements for public seating, applicable to strength and stability verification;
3. GB 18584-2001:Limit of harmful substances in wooden furniture, applicable to formaldehyde emission testing;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · BS-BW076-LG-NB

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · BS-BW076-LG-NB

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · BS-BW076-LG-NB打开导出工具

页面快速操作

发布采购询价

产品描述

The BS-BW076-LG-NB backless bar stool blends modern and Scandinavian design sensibilities for streamlined, functional elevated seating. It features a matte light gray molded polypropylene seat with a shallow curved dish shape and rounded polished edges, supported by four outward-splayed natural walnut-tone bent plywood legs finished with a clear matte lacquer. A black powder-coated square steel footrest ring connects the leg structure, positioned for comfortable foot placement, while non-slip thermoplastic rubber foot pads cap each leg base. The splayed leg configuration creates a stable footprint, with a leg splay width of 500 mm at the floor, and all seat-to-leg connections use zinc-plated steel hardware for reliable assembly. The 14 mm thick internal bent plywood support board reinforces the seat, which sits at a fixed 760 mm height from the floor, aligning with 1100 mm high bar tables and counter surfaces. The non-porous, matte seat surface supports easy wipe cleaning, resists abrasion across 30000 cycles, and holds a uniform load capacity of 200 kg, with a maximum static user load of 150 kg and recommended user weight of 120 kg. The 10 mm diameter powder-coated steel footrest sits 280 mm from the floor, while the leg structure delivers a static stability load of 180 kg. Non-marking foot pads protect floor finishes, supporting 40 kg per leg, and the compact form enables partial nesting to reduce storage footprint when not in use. This stool is suited for a range of indoor spaces, including residential kitchen bars and breakfast islands, high-traffic commercial cafes and bars, co-working breakout zones, and small apartment dining nooks with limited floor area. It is not rated for outdoor use due to its natural wood and steel construction. For procurement, note each unit weighs 7 kg net, ships as one set across two cartons with a packaged gross weight of 23 kg and total carton volume of 0.26 m³, requiring 40 minutes of assembly per set. A 20GP container can hold 135 sets at 85% space utilization, ideal for bulk commercial or multi-unit residential orders. Overall dimensions measure 480 x 400 x 760 mm, with a 460 mm wide and 380 mm deep seat, and bent wood legs measuring 25 mm in thickness.
