基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 900 × 1800 × 750 mm | |
|---|---|---|
| Overall assembled dimensions | 1800 x 900 x 750 mm | |
| Tabletop thickness | 20 mm | |
| Leg cross-section diameter at floor | 60 mm | |
| Brass ferrule height at leg base | 50 mm | |
| Table corner radius | 50 mm | |
| Under-table knee clearance height | 700 mm | |
| Leg inset from table corner | 50 mm | |
| Table overhang from leg centerline (long side) | 100 mm | |
| Table overhang from leg centerline (short side) | 80 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Net product weight | 120 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 200 kg | |
| Seating capacity | 6 seats | |
| Tabletop surface Mohs hardness | 6 | |
| Tabletop water absorption rate | 0.05% | |
| Tabletop heat resistance temperature | 800 °C | |
| Metal leg finish rust/oxidation resistance | 500 hours salt spray | |
| Structural warranty period | 15 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Tabletop substrate | Polished grey veined sintered stone | |
|---|---|---|
| Tabletop backing layer | Aluminum honeycomb composite | |
| Table edge finish | Same-material polished rounded edge | |
| Leg core material | Thick-walled carbon steel tube | |
| Leg surface finish | Matte black powder-coated/electroplated coating | |
| Foot ferrule material | Polished solid brass electroplated stainless steel | |
| Leg-to-tabletop connection hardware | M10 zinc-plated steel bolts with locking nuts | |
| Floor protection pad under ferrule | 5mm thick non-slip rubber pad | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Table structure | Fixed non-extendable four-leg construction | |
|---|---|---|
| Surface cleaning property | Stain-resistant non-porous glossy finish | |
| Assembly requirement | Knock-down leg attachment with included hardware | |
| Floor leveling | Adjustable foot pads under brass ferrules | |
| Seating access | Unobstructed perimeter clearance on all four sides | |
| Edge safety | Softly radiused rounded corners and edges | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Residential dining room | 6-person daily dining for households with open-plan living/dining spaces | |
|---|---|---|
| Apartment open-plan kitchen | Compact 1.8m footprint suitable for urban apartment dining zones | |
| Light luxury hotel guest dining area | Polished stone and metal finish matches boutique hotel interior design | |
| Upscale cafe/light restaurant seating | Stain-resistant easy-clean surface suitable for commercial casual dining | |
| Model home/real estate show home staging | Contemporary light luxury aesthetic matches modern residential display styling |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| Furniture mechanical safety for tables | EN 12521:2015 | |
|---|---|---|
| Surface resistance to cold liquids | EN 12720:2013 | |
| Surface resistance to dry heat | EN 12722:2013 |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| Dining table dimensional stability | GB/T 3324 | |
|---|---|---|
| Formaldehyde emission limit | GB 18584 | |
| Surface coating adhesion | GB/T 4893.4 |
本产品须满足以下技术参数要求: 1. Dining table dimensional stability:GB/T 3324; 2. Formaldehyde emission limit:GB 18584; 3. Surface coating adhesion:GB/T 4893.4; 最终交付参数、检测报告和验收标准以双方采购合同为准。
