Modern Glass Top Console Table with Geometric Block Legs Specifications

CON-GEO-1200BLK

代码:SWCYVXV1
获取供应商报价
2026-09-10 16:19人气: 13
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

CON-GEO-1200BLK

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall dimensions1200 x 350 x 800 mm
Primary Component Thickness40 mm according to load-bearing role
Hardware / Moving-part Clearance5 mm operating clearance
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Tabletop static load capacity50 kg
Product net weight32 kg
Stability lateral load resistance15 kg
Surface abrasion resistance cycles2000 cycles
Recommended placement wall clearance50 mm
Reference Static Load150 kg depending on category
Moving-part Durability ReferenceAcceptance target 50000 cycles
Recommended Procurement WarrantyStructure 5 years; hardware 3 years
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Tabletop panel12mm clear tempered glass with black tinted back coating
Support blocks18mm thick MDF panel with matte warm beige paint finish
Support block edge banding0.8mm thick matching matte PVC edge banding
Floor contact pads5mm thick non-slip silicone pads
Glass to support mounting hardware30mm diameter stainless steel adhesive pads
Internal support frame1.2mm thick powder coated steel cross bracing
Primary Connector SpecificationReference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color CountRecommended 6finish options
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Surface display functionFlat horizontal top supports decorative objects, table lamps and small accessories at entry height
Wall-aligned placementRear face of support assembly sits flush against flat walls for narrow hallway fit
Floor protection functionIntegrated silicone base pads prevent scuffing on hard stone, tile or wood flooring
Assembly structureKnock-down construction connects individual support blocks with pre-installed cam locks
Stability featureStaggered geometric leg layout distributes weight evenly across contact points
Central support block width150 mm
Side support block depth300 mm
Reference Adjustment / Operating Range100 mm or 120° where applicable
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Packaging Volume0.8 m³/set
Reference Packaged Gross Weight120 kg/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Residential entry hallwayNarrow depth fits standard 1200mm wide entry walls for key and decor display
Living room accent wallPositioned behind low-profile sofas to hold table lamps and art objects
Luxury hotel corridorFits upscale hotel hallway wall designs for decorative vase and amenity placement
Showroom display areaUsed as a display plinth for high-end decor in furniture or home goods showrooms
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

该市场暂无标准数据。
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

该市场暂无标准数据。
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. 技术标准与检测报告由供应商在投标或采购确认阶段提供;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · CON-GEO-1200BLK

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · CON-GEO-1200BLK

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · CON-GEO-1200BLK打开导出工具

页面快速操作

发布采购询价

产品描述

The Modern Glass Top Console Table with Geometric Block Legs (model CON-GEO-1200BLK, unbranded) presents a sleek minimalist silhouette defined by clean lines and a balanced geometric layout. Its staggered block leg structure sits flush against flat walls, creating a streamlined profile that integrates seamlessly with narrow vertical surfaces without protruding awkwardly into circulation paths. The clear tempered glass top features a black tinted back coating for subtle depth, paired with warm beige matte-finished support blocks that offer soft visual contrast, lending understated contemporary appeal to interior settings. Constructed for durable, long-term use, the console features a 12mm tempered glass tabletop mounted to supports via stainless steel adhesive pads. The support structure uses 18mm thick MDF panels finished with matte warm beige paint, edged with 0.8mm matching matte PVC banding to prevent edge wear. Internal 1.2mm powder coated steel cross bracing reinforces the frame, connected via knock-down assembly with pre-installed cam locks and primary connectors with a minimum of two fixing points at every major joint. Non-slip 5mm silicone pads line all floor contact points to prevent surface scuffing. Functionally, the flat, entry-height tabletop supports decorative objects, table lamps, and small everyday accessories, while the staggered leg layout distributes weight evenly across contact points for stable placement. The narrow depth allows close wall alignment to suit tight circulation spaces, and the knock-down design enables straightforward on-site assembly. This console fits a range of residential and commercial settings, including residential entry hallways for key and decor display, living room accent walls positioned behind low-profile sofas to hold lighting and art objects, luxury hotel corridors for decorative vase and amenity placement, and showroom display areas as a plinth for high-end home goods. Procurement teams should note units ship across two cartons per set, with assembly completed in roughly 40 minutes per unit; sufficient wall clearance should be allocated at installation, and multiple finish options are available to align with varied interior design schemes.
