基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 2100 × 900 × 880 mm | |
|---|---|---|
| Seat height from floor | 420 mm | |
| Seat depth (usable) | 580 mm | |
| Backrest height above seat | 460 mm | |
| Armrest height from floor | 620 mm | |
| Armrest width (padded surface) | 120 mm | |
| Per-seat width (three-seater) | 640 mm | |
| Wood trim base clearance above floor | 30 mm | |
| Recommended central area rug size | 2000 x 1200 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Total set net weight | 260 kg | |
|---|---|---|
| Per-seat static load capacity | 500 kg | |
| Seat foam density | 40 kg/m³ | |
| Backrest foam density | 20 kg/m³ | |
| Foam rebound rate | 45% | |
| Foam 75% compression set | 10% | |
| S-spring fatigue cycle rating | 50000 cycles | |
| Hardwood frame moisture content | 12% | |
| Standard warranty period | 5 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Upholstery material | 1.5mm thick black Xipi faux leather | |
|---|---|---|
| Seat cushion fill | High-density polyurethane foam, wrapped in soft polyester batting | |
| Backrest cushion fill | Medium-density polyurethane foam | |
| Internal structural frame | Solid kiln-dried hardwood, dowel and screw joined | |
| Seat support system | 3.2mm diameter S-shaped serpentine steel springs, spaced 100mm apart | |
| Armrest and base trim | Polished solid hardwood with scratch-resistant water-based clear lacquer | |
| Integrated support legs | Solid hardwood feet with non-slip rubber floor pads | |
| Seam construction | Bonded nylon thread with 30mm seam pitch | |
| Wood finish performance | Water-based coating resistant to scratches, heat, and mild acid/alkali spills | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Seating configuration | 1 three-seater sofa + 2 single armchairs arranged in U-shape | |
|---|---|---|
| Seat function | Fixed non-reclining, non-swivel seating designed for upright formal guest use | |
| Surface maintenance | Smooth non-porous upholstery allows wipe-cleaning of common office spills | |
| Floor protection | Non-slip rubber foot pads prevent floor scuffing and unwanted sliding | |
| Load distribution | Even spring support prevents cushion sagging under extended static load | |
| Customization option | Black is standard; custom upholstery colors available on request | |
| Arrangement flexibility | Units can be separated and repositioned for different meeting room layouts | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Executive office reception areas | Formal styling creates professional first impression for visiting clients and guests | |
|---|---|---|
| Corporate meeting and waiting zones | Durable easy-clean upholstery suitable for high-traffic daily public use | |
| High-rise office visitor spaces | Compact footprint fits standard window-side reception layouts as shown in image | |
| Hotel business lounge areas | Sturdy construction supports continuous commercial hospitality use | |
| Government and institutional meeting rooms | Conservative black and wood finish matches formal public sector decor requirements | |
| Recommended paired accessory | Low-profile central coffee table and textured area rug to complete reception set | |
| Maximum occupancy | 5 adults at full capacity across three-seater and two single armchairs |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 13759:2004 | Domestic and contract seating – test methods for strength and durability | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture – ignitability resistance to smouldering cigarette |
北美市场采购验货参考 * ANSI/BIFMA 标准
美国及加拿大家具标准
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to solid wood trim and frame | |
|---|---|---|
| GB/T 1952.1-2012 | Technical requirements for upholstered sofas, applicable to seating structure and durability | |
| GB 18584-2001 | Limit of harmful substances in wood furniture, applicable for indoor air quality |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to solid wood trim and frame; 2. GB/T 1952.1-2012:Technical requirements for upholstered sofas, applicable to seating structure and durability; 3. GB 18584-2001:Limit of harmful substances in wood furniture, applicable for indoor air quality; 最终交付参数、检测报告和验收标准以双方采购合同为准。
