基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 3440 × 2650 × 825 mm | |
|---|---|---|
| Overall L-shape footprint | 3440 x 2650 x 825 mm | |
| Single seat module width | 860 mm | |
| Seat height from floor | 410 mm | |
| Total seat depth (cushion front to backrest) | 1050 mm | |
| Armrest height from seat surface | 200 mm | |
| Backrest height from seat surface | 415 mm | |
| Clearance under sofa base | 30 mm | |
| Throw pillow dimensions | 500 x 500 mm | |
| Corner module dimensions | 1050 x 1050 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Total static weight capacity | 397 kg | |
|---|---|---|
| Per-seat static load capacity | 136 kg | |
| Seat foam density | 45 kg/m³ | |
| Back cushion fill density | 28 kg/m³ | |
| Fabric abrasion resistance | 50000 Martindale cycles | |
| Seam stitch pitch | 8 stitches per 30 mm | |
| Net product weight | 205 kg | |
| Seating capacity | 5 adults | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Upholstery fabric | 380 gsm matte polyester performance fabric, biscuit-tufted quilted finish | |
|---|---|---|
| Internal frame | Kiln-dried solid pine wood with corner-blocked joinery, 30 mm thick frame members | |
| Seat support platform | 8 gauge sinuous S-springs spaced 100 mm apart, reinforced with elastic webbing | |
| Seat cushion core | 45 kg/m³ high-resilience polyurethane foam wrapped with 50 mm polyester fiber batting | |
| Back cushion fill | Blend of 28 kg/m³ polyurethane foam chips and conjugated polyester fiber | |
| Throw pillow fill | 100% hypoallergenic polyester fiber fill, sewn edge finish | |
| Modular connection hardware | Powder-coated steel alligator clips with reinforced plastic alignment brackets | |
| Support feet | 25 mm diameter black powder-coated steel cylinder feet, recessed under base | |
| Tufting hardware | Self-fabric covered buttons secured with heavy-duty polyester twine | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Modular reconfiguration | Sections connect via alligator clips, allow straight, L-shape or extended U-shape layouts | |
|---|---|---|
| Cushion retention | All seat and back cushions are fixed to frame with hook-and-loop fasteners | |
| Load distribution | Sinuous spring platform distributes weight evenly across seat base to prevent foam sag | |
| Cleaning access | Surface cleanable upholstery with hidden zipper access for spot treatment of cushion covers | |
| Floor protection | Recessed feet include attached felt pads to prevent scratches on hard flooring | |
| Structural stability | Corner-blocked joinery eliminates frame wobble during normal seating use | |
| Tufted surface retention | Evenly spaced tufting anchors upholstery to foam core to prevent fabric shifting | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Residential living rooms | Sized for open-plan lounge spaces, provides 5-seat casual lounge seating for families | |
|---|---|---|
| Modern minimalist interiors | Two-tone cream and sage finish matches neutral, soft contemporary decor schemes | |
| Open-concept loft spaces | Low-profile L-shape defines seating zones without blocking sightlines across large rooms | |
| Hospitality lounge areas | Durable performance fabric supports high-traffic use in boutique hotel lobbies or waiting zones | |
| Small home media rooms | Deep lounge seat depth supports relaxed reclined seating for movie viewing | |
| Apartment open plan layouts | Modular design allows reconfiguration to fit unusual floor plan shapes |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 12520:2015 | Furniture - Strength, durability and safety requirements for domestic seating | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability test for smouldering cigarette source |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal wood frame structure | |
|---|---|---|
| GB 18401-2010 | National general safety technical code for textile products, applicable to upholstery fabric | |
| GB/T 1952.1-2012 | Test methods for sofas, applicable to strength, durability and stability testing |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to internal wood frame structure; 2. GB 18401-2010:National general safety technical code for textile products, applicable to upholstery fabric; 3. GB/T 1952.1-2012:Test methods for sofas, applicable to strength, durability and stability testing; 最终交付参数、检测报告和验收标准以双方采购合同为准。
