Two-Person Fabric-Partitioned Office Cubicle Workstation with Mobile Pedestals Specifications

WS-2P-FB-MP-2800

代码:0VSNXNV1
获取供应商报价
2026-09-01 13:29人气: 10
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

WS-2P-FB-MP-2800

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall workstation dimensions2800 x 1200 x 1100 mm
Desk work surface height750 mm
Individual workstation surface size1400 x 600 mm per user
Worktop thickness38 mm
PVC edge banding thickness2 mm
Steel frame tube wall thickness1.2 mm
Privacy panel height above worktop350 mm
Seated knee clearance height673 mm
Knee clearance width per user600 mm
Mobile storage pedestal dimensions400 x 500 x 654 mm
Cable grommet diameter60 mm
Caster wheel diameter51 mm
Finished Top Thickness50 mm
Effective Knee Clearance680 mm high and 900 mm wide per main seat
Leg / Support Section80 mm main section with 2 mm metal wall
Cable Opening Size80 mm diameter; cable tray depth 120 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Total workstation unit weight170 kg
Static load capacity per work surface91 kg
Drawer slide static load per drawer25 kg
Drawer slide cycle rating50000 cycles
Pedestal caster dynamic load rating per wheel40 kg
Melamine surface abrasion resistance2000 cycles
Recommended user capacity2 people
Commercial warranty period3 years
Top Static Load Reference150 kg uniformly distributed
Drawer Slide Load / Life45 kg/pair; 50000 cycles
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Work surfaceE1-grade melamine-faced particle board, scratch/water-resistant finish
Desk edging2mm thick PVC edge banding, radius profile to prevent chipping
Support framePowder-coated white steel square tubing, 1.2mm wall thickness
Upper privacy dividersBeige tackable polyester fabric over rigid composite core
Lower side modesty panelsWhite melamine-faced engineered wood panels, rigid fixed installation
Mobile pedestal bodiesWhite/beige melamine-faced engineered wood with steel reinforced corners
Drawer slidesCold-rolled steel ball-bearing full-extension slides
CastersBlack nylon swivel casters, two lockable per pedestal
Cable grommetsABS plastic round desk grommets with removable cover
Primary Panel Thickness25 mm; load-bearing top may use 40 mm composite build-up
Edge Band Thickness2 mm
Metal Frame Wall Thickness2 mm cold-rolled steel
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Privacy separationFabric dividers block direct line of sight between adjacent users for individual focus
Mobile pedestal storageEach station includes a wheeled pedestal with 1 top drawer and 1 lower storage cabinet
Pedestal mobilityFour swivel casters per pedestal allow repositioning under or beside the desk
Cable managementOne 60mm grommet per work surface routes power/data cables from desk to floor
Floor levelingAdjustable glides on frame legs compensate for uneven office flooring
Pedestal lockingIntegrated key lock on each pedestal secures drawer and cabinet contents
Modular configurationKnock-down design allows reconfiguration into linear or clustered workstation layouts
Fabric panel functionalityTackable fabric surface supports pinning notes and documents without panel damage
Cable Management CapacityReference capacity 10power/data cables; tray load 10 kg
Reference Reassembly CountMain joints should support 5controlled assembly cycles
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Package DimensionsMain top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight180 kg/set in 4 cartons
Reference Packaging Volume1 m³/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Open-plan office layoutsProvides semi-private workstations for team members without full high-wall cubicles
Startup and small team workspacesCompact two-person footprint fits small office spaces while providing dedicated storage
Administrative and back-office staff useStandard 750mm desk height supports standard office chair and computer work use
Temporary project work areasMobile pedestals allow fast reconfiguration for shifting team assignments
Co-working shared office spacesStandardized size and locking storage support rotating individual user assignments
Call center and administrative pool areasLow dividers maintain supervisor sightlines while reducing cross-user distraction
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 527-1:2011Safety, strength and durability requirements for office work surfaces and desks
EN 1335-1:2020Office work furniture ergonomic dimensional requirements for seated work
EN 716-1:2019Structural integrity requirements for furniture storage components including pedestals
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.5-2021Performance and durability standard for office desk products
ANSI/BIFMA X5.9-2019Performance and testing standard for office mobile storage pedestals
ANSI/BIFMA X7.1-2020Formaldehyde emission limits for low-emitting office furniture components
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for wooden office furniture, applicable to worktop and panel components
GB/T 3327-2017Stability, strength and durability requirements for office desks and workstations
GB 18580-2017Formaldehyde emission limits for engineered wood panels used in indoor furniture
GB/T 4897.3-2003Performance requirements for particle board used in furniture structural applications
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for wooden office furniture, applicable to worktop and panel components;
2. GB/T 3327-2017:Stability, strength and durability requirements for office desks and workstations;
3. GB 18580-2017:Formaldehyde emission limits for engineered wood panels used in indoor furniture;
4. GB/T 4897.3-2003:Performance requirements for particle board used in furniture structural applications;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · WS-2P-FB-MP-2800

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · WS-2P-FB-MP-2800

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · WS-2P-FB-MP-2800打开导出工具

页面快速操作

发布采购询价

产品描述

The Two-Person Fabric-Partitioned Office Cubicle Workstation with Mobile Pedestals, model WS-2P-FB-MP-2800, is an unbranded modern dual-workstation solution built for open-plan work environments. Its balanced visual design pairs clean white structural elements with soft beige fabric dividers, creating a semi-enclosed layout that delivers personal focus without the closed-off feel of full-height cubicles. The overall unit measures 2800 x 1200 x 1100 mm, with two equal 1400 x 600 mm individual work surfaces set at a standard 750 mm desk height, separated by a 350 mm tall fabric privacy divider that sits above the worktop to block direct adjacent sightlines while retaining open visibility across the broader office space. Constructed for consistent daily use, the workstation features a 38 mm thick E1-grade melamine-faced particle board worktop with a scratch and water-resistant finish, edged with 2 mm radius-profile PVC banding to prevent chipping. The support structure uses 1.2 mm wall thickness white powder-coated square steel tubing, fitted with adjustable leg glides to compensate for uneven flooring. Privacy dividers use beige tackable polyester fabric over a rigid composite core, paired with fixed white melamine lower modesty panels. Each user position includes a matching mobile storage pedestal built with melamine-faced engineered wood, steel-reinforced corners, cold-rolled steel ball-bearing full-extension drawer slides, and four black nylon swivel casters (two lockable per unit). Each work surface holds a 60 mm round ABS cable grommet with a removable cover for tidy power and data routing. Functional design supports flexible office operations: each pedestal includes one top drawer, one lower storage cabinet, and an integrated key lock to secure personal or work materials, with casters that allow easy repositioning under or beside the desk. The knock-down modular structure supports assembly into linear or clustered layouts, with a 40-minute per-set assembly reference time. Each work surface supports 91 kg of static load, with drawer slides rated for 50000 open/close cycles and 25 kg static load per drawer, and caster wheels rated for 40 kg dynamic load per wheel. This workstation fits a wide range of commercial spaces, including open-plan team floors, startup and small team offices, administrative back-office areas, temporary project zones, co-working shared spaces, and call center pool areas, as its low divider height maintains supervisor sightlines while reducing cross-user distraction. Procurement teams should note each unit ships across multiple cartons with a total packaged gross weight of 180 kg and 1 m³ total packaging volume, and plan for on-site assembly prior to deployment; the unit is sized to accommodate two dedicated users with standard office chairs and computing equipment.
