Single-Person L-Shaped Office Cubicle Workstation with Integrated Storage Pedestal Specifications

L-CUB-1P-1500-BEECH

代码:24ZD9CV1
获取供应商报价
2026-09-01 13:53人气: 22
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

L-CUB-1P-1500-BEECH

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall dimensions1500 x 1400 x 1200 mm
Main work surface size1500 x 600 mm
Return work surface size1200 x 600 mm
Work surface thickness25 mm
Edge band thickness2 mm
Work surface height750 mm
Knee clearance width800 mm
Knee clearance height650 mm
Knee clearance depth550 mm
Privacy divider total height1200 mm
Clear acrylic upper panel height300 mm
Beige divider infill panel height900 mm
Storage pedestal width400 mm
Storage pedestal depth600 mm
Metal leg diameter30 mm
Cable grommet inner diameter50 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Work surface static load capacity150 kg
Drawer slide cycle rating50000 cycles
Cabinet door hinge cycle rating80000 cycles
Laminate surface abrasion resistance2000 cycles
Net product weight68 kg
Seated user capacity1 person
Manufacturer warranty3 years
Reference Static Load150 kg depending on category
Moving-part Durability ReferenceAcceptance target 50000 cycles
Recommended Procurement WarrantyStructure 5 years; hardware 3 years
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Work surface coreE1 grade particleboard
Work surface finishThermally fused light beech-effect melamine
Privacy divider framePowder-coated white steel tube
Lower divider infill panelsBeige fabric-laminated fiberboard
Upper right divider panel5 mm thick clear acrylic
Storage pedestal carcassWhite melamine laminated particleboard
Pedestal lower door panelLight beech-effect melamine particleboard
Support legsPowder-coated black tubular steel
Drawer slidesCold-rolled steel full-extension ball bearing slides
Cabinet hingesCold-rolled steel concealed soft-close hinges
Cable grommetsABS plastic round wire port covers
Edge banding2 mm thick PVC matching work surface finish
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Privacy screeningThree-sided wrap-around partial-height dividers block direct sightlines for seated workers
Storage organizationLeft integrated pedestal includes 1 upper shallow drawer and 1 lower closed cabinet door
Cable managementTwo round surface grommets route power and data cables from desktop to floor
Level adjustmentAdjustable glide feet on all leg bases compensate for uneven floor surfaces
Drawer operationFull-extension ball-bearing slides allow full access to drawer interior without binding
Door operationConcealed hinges allow cabinet door to open 110 degrees for storage access
Modular assemblyBolt-together steel frame and panel connectors allow reconfiguration with adjacent workstations
Surface protectionMelamine finish resists common office stains, scratches and heat from hot beverage containers
Reference Adjustment / Operating Range100 mm or 120° where applicable
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Packaging Volume0.8 m³/set
Reference Packaged Gross Weight120 kg/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Open plan office spacesProvides individual seated privacy for staff in shared open office layouts
Small home officesCompact L-shaped footprint fits residential work spaces with storage integrated
Call center work areasPartial dividers reduce visual distraction while allowing supervisor visibility
Startup office environmentsModular design supports reconfiguration as team size and layout changes
Temporary project workspacesKnock-down design allows quick assembly and disassembly for short-term office setups
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 527-1:2011Office work tables - safety and strength requirements, applicable to structural performance
EN 527-2:2016Office work tables - dimensional and safety requirements, applicable to ergonomic dimensions
EN 13722:2004Office furniture - storage units, applicable to pedestal drawer and cabinet performance
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.5-2021Desk products - safety and performance standard for commercial office work surfaces
ANSI/BIFMA X5.9-2019Storage units - performance standard for integrated pedestal drawers and cabinets
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for wooden furniture, applicable to panel desk components
GB/T 3327-2018Office desks and tables, applicable to dimensional and performance specifications
GB 18580-2017Formaldehyde emission limits for wood-based panels, applicable to panel material acceptance
GB/T 4897.3-2018Particleboard for furniture use, applicable to work surface and cabinet core material
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to panel desk components;
2. GB/T 3327-2018:Office desks and tables, applicable to dimensional and performance specifications;
3. GB 18580-2017:Formaldehyde emission limits for wood-based panels, applicable to panel material acceptance;
4. GB/T 4897.3-2018:Particleboard for furniture use, applicable to work surface and cabinet core material;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · L-CUB-1P-1500-BEECH

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · L-CUB-1P-1500-BEECH

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · L-CUB-1P-1500-BEECH打开导出工具

页面快速操作

发布采购询价

产品描述

The Fanshidun Single-Person L-Shaped Office Cubicle Workstation with Integrated Storage Pedestal, model L-CUB-1P-1500-BEECH, is a purpose-built single workstation designed to balance personal privacy, functional work space, and built-in storage for both commercial and residential settings. Visually, it features a warm light beech-effect work surface paired with white and black steel framing, beige fabric lower divider panels, and a clear acrylic upper right panel, creating a clean, professional aesthetic that blends seamlessly with a range of interior palettes. Its L-shaped layout provides two connected work surfaces arranged to wrap around a single seated user, supported by partial-height three-sided dividers that frame the work zone without fully enclosing the space. The workstation is constructed with durable steel-wood components: work surfaces use E1 grade particleboard cores finished with thermally fused light beech-effect melamine, edged with 2mm thick banding for long-term wear resistance. Privacy divider frames are made from powder-coated white steel tube, with lower infill panels of beige fabric-laminated fiberboard and a clear acrylic upper right panel. Support legs are powder-coated black tubular steel, while the integrated storage pedestal uses white melamine laminated particleboard for its carcass, with a light beech-effect melamine front door panel. Drawers operate on cold-rolled steel full-extension ball bearing slides, and cabinet doors use concealed hinges for smooth operation. Functionally, the three-sided wrap-around dividers block direct sightlines for seated users to reduce distraction, while the clear upper panel maintains appropriate visibility for shared spaces. The left-side integrated pedestal includes one upper shallow drawer and one lower closed cabinet to keep office supplies and personal items organized close at hand. Two round cable grommets built into the work surface route power and data cables neatly from the desktop to the floor, eliminating clutter from loose cords. Adjustable glide feet on all leg bases compensate for uneven floor surfaces to keep the workstation stable, while full-extension slides allow unobstructed access to the full drawer interior, and cabinet doors open 110 degrees for easy access to stored items. Its bolt-together modular design supports reconfiguration with adjacent matching workstations as spatial needs evolve, and knock-down assembly allows efficient setup and disassembly. This workstation is well suited for open plan office spaces, where it delivers individual seated privacy for staff in shared layouts; small home offices, where its compact L-shaped footprint and integrated storage fit efficiently in residential work areas; call center work areas, where partial dividers reduce visual distraction while retaining supervisor visibility; startup office environments, where modular construction supports layout changes as teams grow; and temporary project workspaces, where quick assembly and disassembly support short-term setups. For procurement, note that each unit ships in two cartons, requires 40 minutes of assembly time per set, and carries a 3-year manufacturer warranty. The work surface supports a static load of 150kg, drawer slides are rated for 50,000 open-close cycles, cabinet hinges for 80,000 cycles, and the melamine surface delivers abrasion resistance rated for 2000 cycles.
