4-Person Cross-Shaped Modular Office Cubicle Workstation with Integrated Storage Pedestals Specifications

WS-CR4-2800-LW

代码:47TPVQV1
获取供应商报价
2026-09-01 13:49人气: 19
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

WS-CR4-2800-LW

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Primary Component Thickness40 mm according to load-bearing role
Hardware / Moving-part Clearance5 mm operating clearance
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Worktop static load capacity per seat100 kg
Total workstation unit net weight280 kg
Recommended maximum user weight per seat120 kg
Surface abrasion resistance rating2000 cycles
Surface stain and water resistanceGrade 1 (no penetration for 24 hours)
Product warranty period5 years
Available finish color options60
Reference Static Load150 kg depending on category
Moving-part Durability ReferenceAcceptance target 50000 cycles
Recommended Procurement WarrantyStructure 5 years; hardware 3 years
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Worktop core25mm thick particleboard core
Worktop surface finishLight oak melamine laminate
Worktop edge treatment2mm thick white PVC impact-resistant edge banding
Privacy divider panelsMelamine-faced engineered wood panels
Divider support frame1.2mm thick white powder-coated square steel tube
Storage pedestal cabinet body16mm thick melamine-faced engineered board
Drawer slidesCold-rolled steel three-section full-extension slides
Elevated base legs1.5mm thick black powder-coated steel hairpin legs
Cable grommetsABS plastic round wire management grommets
Primary Connector SpecificationReference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color CountRecommended 6finish options
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Seating configuration4 individual partitioned work positions arranged in cross layout
Per-seat storage1 lockable top drawer plus 1 lower hinged door cabinet
Privacy separationHalf-height dividers block direct line of sight between adjacent seats
Cable managementIntegrated corner grommets route power and data cables from desk to floor
Elevated base design100mm floor clearance under all storage units
Knock-down assemblyFlat-packed with cam-lock and bolt fasteners
Modular expandabilityConnects to additional workstation clusters for larger open office layouts
Leveling adjustmentAdjustable foot pads on each base leg
Reference Adjustment / Operating Range100 mm or 120° where applicable
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Packaging Volume0.8 m³/set
Reference Packaged Gross Weight120 kg/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Open plan office staff areasProvides individual partitioned workspaces for teams of 4 in open offices
Call center and administrative departmentsBalances privacy and collaboration for daily seated desk tasks
Startup and co-working spacesModular layout supports flexible team expansion and reconfiguration
Government and corporate back-office spacesDurable construction meets high-frequency daily office use requirements
Small business office layoutsCompact 2.8m square footprint fits efficiently in limited floor space
Temporary project team work zonesKnock-down design allows quick relocation between office areas
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 527-1:2011Office worktables safety and strength requirements for commercial use
EN 527-2:2016Office worktables mechanical safety and dimensional compliance
EN 1335-1:2020Office furniture ergonomic dimensions reference for seated work clearance
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.5-2021Desk products performance and durability test standard for office use
ANSI/BIFMA X5.9-2019Storage units performance standard for integrated pedestal cabinets
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for wooden furniture, applicable to worktop and cabinet components
GB/T 3327-2017Performance test methods for office desks and workstations
GB 18584-2001Indoor decoration material formaldehyde emission limit for wood-based furniture
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to worktop and cabinet components;
2. GB/T 3327-2017:Performance test methods for office desks and workstations;
3. GB 18584-2001:Indoor decoration material formaldehyde emission limit for wood-based furniture;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · WS-CR4-2800-LW

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · WS-CR4-2800-LW

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · WS-CR4-2800-LW打开导出工具

页面快速操作

发布采购询价

产品描述

This cross-shaped modular office cubicle workstation cluster is configured to support four individual work positions, arranged in a symmetrical cross layout with a compact 2.8-meter square footprint suited to space-efficient floor planning. The visual design follows a modern, minimalist aesthetic, with light oak melamine laminate worktops paired with white powder-coated square steel support frames, half-height wood-composite privacy dividers, and black powder-coated steel hairpin legs that lift storage units 100 millimeters above the floor for an open, uncluttered look. The half-height dividers sit between adjacent seats to block direct line of sight while preserving the open feel of shared office environments, and clean, straight lines paired with white PVC impact-resistant edge banding create a cohesive, professional appearance across the entire unit. Construction uses graded, application-matched materials to support consistent daily use. Worktops feature a 25-millimeter thick particleboard core with melamine facing, finished with 2-millimeter thick white PVC edge banding to resist impact damage. Primary structural components are sized to 40-millimeter thickness based on load-bearing requirements, with divider frames built from 1.2-millimeter thick white powder-coated square steel tube, storage pedestal bodies from 16-millimeter thick melamine-faced engineered board, and elevated base legs from 1.5-millimeter thick black powder-coated steel. All moving parts maintain 5 millimeters of operating clearance, with cold-rolled steel three-section full-extension slides supporting drawer function, and ABS plastic round cable grommets integrated at corner positions. The unit uses knock-down construction with cam-lock and bolt fasteners, delivered flat-packed in two cartons per set, with a 40-minute per-set reference assembly time. Each work seat supports a 100-kilogram static worktop load, with a recommended maximum user weight of 120 kilograms per position, and work surfaces carry a 2000-cycle abrasion resistance rating plus Grade 1 stain and water resistance that prevents liquid penetration for 24 hours. The full unit has a net weight of 280 kilograms, with a packaged gross weight of 120 kilograms and 0.8 cubic meters of packaging volume per set, backed by a 5-year product warranty, with 60 available finish color options to align with existing office design schemes. Functional design supports both focused work and collaborative flexibility. Each of the four seats includes an integrated under-desk storage pedestal with one lockable top drawer and one lower hinged-door cabinet for personal work materials. Integrated corner cable grommets route power and data cables neatly from work surfaces to the floor to reduce desktop clutter, while the elevated base leaves clear floor access under storage units for routine cleaning. The cross-shaped layout can connect to additional matching workstation clusters to scale for larger teams, and the knock-down structure allows quick disassembly for relocation between work zones. This workstation is well suited for open-plan office staff areas, where it delivers partitioned individual workspaces for four-person teams without enclosing the broader floor plan. It balances privacy and easy collaboration for call center and administrative teams completing daily seated desk tasks, and its modular expandability supports flexible growth for startup and co-working spaces.
