商品供应商Two-Person Side-by-Side Modular Office Workstation with Privacy Screens and CPU Bays,Particle‑board (PB)
可联系供应商获取生产周期与报价。
| 纠错时间 | 修改字段 | 原参数 | 修改后参数 | 说明 / 状态 |
|---|---|---|---|---|
暂无参数纠错记录,发现错误可点击行末旗标提交 | ||||
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| Overall workstation footprint | 2860 x 1430 x 1200 mm | |
|---|---|---|
| Individual work surface | 1200 x 600 mm each | |
| Work surface height | 750 mm | |
| Desktop thickness | 25 mm | |
| Knee opening width per seat | 1100 mm | |
| Knee clearance under desktop | 680 mm | |
| Knee opening depth | 600 mm | |
| Central storage pier | 300 x 1430 x 1200 mm | |
| End CPU or utility bay | 300 x 600 x 650 mm | |
| Front privacy screen height above desktop | 450 mm | |
| Front privacy screen panel thickness | 32 mm | |
| Solid modesty panel height | 450 mm | |
| Cable grommet diameter | 80 mm | |
| Leveling foot diameter | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Recommended product weight | 145 kg per complete workstation | |
|---|---|---|
| Desktop static load capacity | 91 kg per work surface | |
| Central storage pier top load | 30 kg | |
| CPU or utility bay load | 20 kg | |
| Occupant capacity | 2 workers | |
| Recommended user weight per seated position | 135 kg | |
| Drawer or tray slide load | 25 kg per drawer | |
| Drawer slide durability | 50000 open-close cycles | |
| Hinge durability for cabinet doors | 80000 open-close cycles | |
| Structural warranty target | 5 years |
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Work surface | 25 mm melamine-faced engineered wood board with wood-grain finish | |
|---|---|---|
| Edge protection | 2 mm matching PVC edge banding on work surfaces and exposed panels | |
| Grey privacy and modesty panels | Melamine-faced engineered wood panels with dark metal perimeter trim | |
| Slatted upper screen | Horizontal coated metal or rigid polymer slats within a dark metal frame | |
| Central and end storage piers | 18 mm melamine-faced panel construction with fixed shelves | |
| Structural frame | 60 x 30 x 1.2 mm powder-coated rectangular steel tube | |
| Panel frame finish | Electrostatic powder-coated grey or dark grey metal | |
| Cable ports | 80 mm plastic or aluminum grommets with removable caps | |
| Cable tray | Steel under-desk trough separated into strong-current and weak-current routes | |
| Leveling system | Nylon-padded adjustable steel glides with 50 mm foot pads | |
| Fasteners and brackets | Zinc-plated steel connector plates, cam locks, and frame joining brackets | |
| Back and divider boards | 16 mm laminated engineered wood with concealed joining strips |
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Two-position layout | Side-by-side work surfaces give two individually assigned seats with one central separating pier | |
|---|---|---|
| Privacy separation | Low front screens and a full-height central pier reduce visual distraction without enclosing the worker | |
| Cable routing at desktop | An 80 mm grommet on each work surface passes monitor and power cables below the top | |
| Under-desk cable management | A steel tray routes power and data separately from each desktop toward the central or end bay | |
| Equipment storage | Central and end open bays accept CPU towers, power strips, or document storage with cable pass-through holes | |
| Leg-space design | Each station provides an open 1100 mm-wide knee bay free of drawers at the seated centerline | |
| Floor leveling | Adjustable glides compensate for uneven floors and align the modular panel bases | |
| Modular extension | The panel-and-pier structure can align additional seats laterally using matching frame connectors | |
| Modesty protection | A solid 450 mm front panel shields seated users and under-desk equipment from aisle view | |
| Storage locking provision | Central locking can be specified on drawer or door modules where secured storage is required | |
| Installation method | Knock-down panel assembly with mechanical frame joints, connector cams, and floor glides; wall fixing is not required | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg |
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Open-plan office | Suitable for two adjacent employees where defined privacy and shared layout efficiency are required | |
|---|---|---|
| Call center | Supports dense seating with cable ports, modesty panels, and CPU bays for headsets and computer equipment | |
| Administrative shared-service area | Fits data-entry, processing, and clerical teams using monitors, keyboards, and CPUs | |
| Back-office finance or HR zone | Provides separate seated positions while retaining close communication between two workers | |
| Project team benching | Can be arranged in rows for multiple two-seat modules in agile or team neighborhoods | |
| IT support workspace | Open utility bays accommodate towers and power management while preserving desk space for keyboards and documents | |
| Branch office standardization | Provides a repeatable 750 mm seated-height platform for multi-site procurement |
欧洲市场准入与化学品要求
| Office furniture structural safety | EN 16139:2013+A1:2018 applies to strength, durability, and stability of non-domestic seating-support furniture systems | |
|---|---|---|
| Surface chemical safety | EN 12720 supports resistance to cold liquids for laminated work surfaces | |
| Surface abrasion check | EN 14354 applies to laminate flooring-style surface evaluation concepts and may guide melamine wear testing | |
| Office storage hardware | EN 14074 supports office storage hardware requirements where locking drawers or doors are specified |
美国及加拿大家具标准
| Desk products safety and performance | ANSI/BIFMA X5.5 applies to desk load, stability, leg strength, and durability testing | |
|---|---|---|
| Storage products safety and performance | ANSI/BIFMA X5.9 applies if drawer pedestals or locking storage cabinets are part of the order | |
| Power and cable accessory guidance | ANSI/BIFMA X5.5 cable-management provisions can guide grommet, tray, and edge-protection checks |
适用于中国市场项目的标准
| Formaldehyde emission acceptance | GB 18580applies to formaldehyde emission from wood-based panels used in the workstation | |
|---|---|---|
| Wood furniture quality acceptance | GB/T 3324applies to dimensions, workmanship, stability, and inspection of wooden office furniture | |
| Melamine surface board reference | GB/T 15102applies to melamine-faced board used for work surfaces and panels |
本产品须满足以下技术参数要求: 1. Formaldehyde emission acceptance:GB 18580applies to formaldehyde emission from wood-based panels used in the workstation; 2. Wood furniture quality acceptance:GB/T 3324applies to dimensions, workmanship, stability, and inspection of wooden office furniture; 3. Melamine surface board reference:GB/T 15102applies to melamine-faced board used for work surfaces and panels; 最终交付参数、检测报告和验收标准以双方采购合同为准。
