Name: 2-Seat Linear Office Cubicle Workstation with Frosted Partitions and Mobile Pedestal
Brand: aibi furniture
SKU: 9FRRYG

纠错时间

修改字段

原参数

修改后参数

说明 / 状态

暂无参数纠错记录，发现错误可点击行末旗标提交

PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源：工厂资料结构化字段，最终以实测值为准

产品外部尺寸（宽 × 深 × 高）	2400 × 1400 × 1200 mm
Overall station dimensions	2400 x 1400 x 1200 mm
Work surface height	750 mm
Per-seat work surface size	1200 x 600 mm
Partition total height	1200 mm
Lower solid partition panel height	900 mm
Upper frosted glass partition height	300 mm
Partition frame profile thickness	57 mm
Work surface thickness	25 mm
Rear elevated shelf depth	250 mm
Knee clearance height under worktop	620 mm
Knee clearance width per seat	1100 mm
Mobile pedestal dimensions	400 x 500 x 600 mm
Leveling foot diameter	30 mm
PVC edge banding thickness	2 mm
Primary Component Thickness	40 mm according to load-bearing role
Hardware / Moving-part Clearance	5 mm operating clearance

PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源：产品性能数据，采购前请核对具体测试口径

Work surface static load capacity	100 kg
Total station net weight	120 kg
Recommended user count	2
Work surface abrasion resistance	2000 cycles
Mobile pedestal caster rolling durability	40000 cycles
Partition panel tack holding strength	500 g per pin
Warranty period	3 years
Reference Static Load	150 kg depending on category
Moving-part Durability Reference	Acceptance target 50000 cycles
Recommended Procurement Warranty	Structure 5 years; hardware 3 years

PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源：以工厂材质清单与验货报告为准

Work surface	25mm thick E1-grade melamine-faced MFC board
Edge banding	2mm thick PVC trim, heat-sealed to all worktop edges
Partition support frame	Powder-coated silver aluminum alloy extruded profile
Lower partition panels	Light green fabric-wrapped fiberboard, sound-dampening
Upper partition panels	Frosted semi-translucent tempered safety glass
Rear shelf surface	White melamine-faced MFC, matching worktop finish
Mobile pedestal body	0.8mm thick cold-rolled steel with white powder coat
Mobile pedestal hardware	Zinc-plated steel lock, three-section full-extension drawer slides
Pedestal casters	30mm diameter PU silent swivel casters, 360-degree rotation
Frame leveling feet	Nylon base with steel threaded adjustment stem
Cable management raceway	1mm thick PVC channel integrated inside partition frame
Drawers and cabinet interior	Melamine-lined storage compartments with steel reinforcement

PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源：功能配置参数，以供应商正式规格为准

Seated privacy partition	1200mm height blocks direct line of sight between seated adjacent users
Lockable under-desk storage	One key-locked drawer and one hinged door cabinet secures personal office items
Mobile pedestal mobility	Four swivel casters allow pedestal to move freely under or beside the work surface
Concealed cable management	Internal raceway routes power and data cables from floor to work surface without exposed wiring
Elevated rear storage shelf	Raised ledge holds books, small plants and office supplies off main work surface
Leveling adjustment	Threaded feet adjust to compensate for uneven floor surfaces up to 15mm
Modular expandability	Aluminum frame connection points allow additional workstations to be joined for larger layouts
Frosted glass light transmission	Upper glass panels allow natural light to pass between seats while maintaining visual privacy
Reference Adjustment / Operating Range	100 mm or 120° where applicable

PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源：外贸报价与装柜测算参考

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源：依据产品结构与品类整理的推荐应用场景

Open-plan office staff zones	Suitable for general administrative and operational staff in open office layouts
Small business office layouts	Fits compact office spaces for 2-person team seating with integrated storage
Corporate call center work areas	Partitions reduce cross-talk distraction while maintaining supervisor visibility over lower panels
Government and institutional offices	Neutral light green and white finish matches formal public sector interior design
Shared co-working spaces	Modular design allows reconfiguration for different team size requirements
Startup open office environments	Integrated cable management and storage reduces desk clutter for efficient work

STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 527-2:2002+A1:2016	Office worktables safety and strength requirements, applicable to structural stability
EN 14073-2:2004	Office storage furniture safety requirements, applicable to mobile pedestal components
EN 13722:2004	Office furniture movable storage cabinets strength and durability testing
EN 71-3:2019	Migration of certain elements safety standard for furniture surface materials

STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.5-2021	Desk products performance standard, applicable to worktop load and cycle testing
ANSI/BIFMA X5.9-2019	Storage units performance standard, applicable to mobile pedestal durability
ANSI/BIFMA X5.10-2021	Panel systems performance standard, applicable to partition frame and panel integrity

STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to MFC worktop and storage components
GB/T 3327-2016	Office desk performance test standards, applicable to work surface load and stability requirements
GB 18584-2001	Formaldehyde emission limit for interior decoration wooden furniture, E1 grade compliance target
GB/T 4893.8-2013	Surface wear resistance test for furniture coatings, applicable to melamine worktop finish

招标文件标准化描述文本

本产品须满足以下技术参数要求：
1. GB/T 3324-2017：General technical requirements for wooden furniture, applicable to MFC worktop and storage components；
2. GB/T 3327-2016：Office desk performance test standards, applicable to work surface load and stability requirements；
3. GB 18584-2001：Formaldehyde emission limit for interior decoration wooden furniture, E1 grade compliance target；
4. GB/T 4893.8-2013：Surface wear resistance test for furniture coatings, applicable to melamine worktop finish；
最终交付参数、检测报告和验收标准以双方采购合同为准。

GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告，可选择公制或英制单位。

PDF · CWK-L2-1206-PED-LGWH

完整参数 Excel

导出全部商品信息与参数模块，文件内容统一使用英文。

XLSX · CWK-L2-1206-PED-LGWH

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段，可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · CWK-L2-1206-PED-LGWH打开导出工具

页面快速操作

发布采购询价

产品描述

The 2-Seat Linear Office Cubicle Workstation from aibi furniture, model CWK-L1206-PED-LGWH, is a partitioned modular office desk designed for flexible, organized shared workspaces. It features a clean modern aesthetic with a coordinated light green and white color scheme, arranged in a straight linear layout that seats two users side by side. The partition system stands to full station height, with a lower fabric-wrapped panel section that rises to block direct seated line of sight between adjacent users, capped with a frosted semi-translucent tempered glass upper section that balances privacy with ambient light flow and open sightlines across the wider space. A raised rear shelf finished to match the work surface runs along the back of the unit, while a wheeled mobile pedestal tucks cleanly under one work surface for a streamlined, uncluttered footprint. Built for durable daily commercial use, the workstation uses high-quality, purpose-selected materials for every component. Its work surfaces are constructed from E1-grade melamine-faced MFC board, with 2mm thick heat-sealed PVC edge banding on all exposed edges to resist impact damage. The partition structure is supported by a powder-coated silver aluminum alloy frame, with lower panels made of sound-dampening light green fabric-wrapped fiberboard and upper panels of frosted safety glass. The included mobile pedestal is formed from cold-rolled steel with a white powder coat finish, fitted with zinc-plated steel locking hardware, full-extension drawer slides, and 360-degree swivel PU silent casters for smooth movement. Threaded leveling feet compensate for uneven floor surfaces, while an internal cable raceway routes power and data cables completely out of sight to eliminate tangled exposed wiring. The lockable pedestal includes a key-locked drawer and hinged door cabinet to secure personal items, and the integrated aluminum frame includes connection points to join additional matching workstations for expanded team layouts as needs change. This workstation is well suited for a wide range of commercial work environments, including open-plan corporate staff zones for administrative and operational teams, compact small business offices for two-person teams, corporate call centers where partitions reduce cross-talk distraction while preserving supervisor visibility, formal government and institutional offices that favor neutral professional finishes, reconfigurable co-working spaces, and startup open offices where built-in storage and cable management support clutter-free efficient work. When procuring this unit, note that each set ships in two cartons, with a 40-minute per-set assembly time. The product includes a 3-year warranty, and is designed to support consistent long-term use across evolving workspace configurations.
