Single-Person L-Shaped Office Cubicle Workstation with Integrated Storage Pedestal Specifications

L-CUB-1600-PED-MESH

代码:C2TEQDV1
获取供应商报价
2026-09-02 11:09人气: 18
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

L-CUB-1600-PED-MESH

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall footprint (L-arm x L-arm x partition height)1600 x 1600 x 1200 mm
Work surface height from floor750 mm
Work surface depth per arm700 mm
Knee well minimum width under work surface600 mm
Knee well minimum clearance height650 mm
Integrated storage pedestal dimensions400 x 550 x 725 mm
Open storage shelf above drawer (internal)360 x 500 x 120 mm
Drawer internal usable dimensions360 x 500 x 150 mm
Lower cabinet internal usable dimensions360 x 500 x 420 mm
Aluminum partition frame profile width40 mm
Vented mesh upper partition height300 mm
Fabric lower partition panel height900 mm
Cable grommet diameter60 mm
Support leg height (floor to desk underside)650 mm
Partition bottom clearance from floor50 mm
Primary Component Thickness40 mm according to load-bearing role
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Work surface uniform static load capacity80 kg
Drawer slide open/close cycle rating50000 cycles
Total assembled unit weight110 kg
Recommended maximum user weight for seated use110 kg
Melamine surface abrasion resistance2000 cycles
Warranty period for structural components5 years
Available color options8
Reference Static Load150 kg depending on category
Moving-part Durability ReferenceAcceptance target 50000 cycles
Recommended Procurement WarrantyStructure 5 years; hardware 3 years
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Worktop construction25mm thick E1-grade melamine-faced particleboard, 2mm PVC rounded edge banding
Partition frame construction1.2mm wall thickness extruded aluminum profile, silver anodized finish
Lower partition panel construction9mm thick MDF core, fabric-wrapped surface for acoustic privacy
Upper partition panel constructionSteel-framed vented perforated mesh panel, powder-coated silver finish
Storage pedestal construction18mm thick E1-grade melamine-faced particleboard, matching PVC edge banding
Drawer slide hardware3-section full-extension cold-rolled steel ball-bearing slides, zinc-plated finish
Drawer lock mechanismZinc-alloy keyed cam lock with 2 included keys
Support leg construction30mm diameter powder-coated steel tapered legs, adjustable floor glides
Cable grommet constructionABS plastic round brush-style grommet, color matched to work surface
Partition connector hardwareDie-cast aluminum corner joints, steel mounting brackets for knock-down assembly
Edge banding properties2mm thick impact-resistant PVC, waterproof and stain-resistant sealed edges
Primary Connector SpecificationReference M6-M10 with at least 2 fixing points at major joints
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Wrap-around two-sided privacy partition90-degree corner panels block direct line of sight from adjacent work areas, with upper mesh for light and airflow
Integrated fixed storage pedestalCombines open top shelf for frequently used items, lockable drawer for small supplies, and lower enclosed cabinet for personal storage
Work surface cable management60mm desk grommet routes power and data cords from devices to under-desk raceways for a clutter-free work surface
Adjustable floor glides10mm height adjustment on all support and partition legs compensates for uneven floors to keep worktop level
Knock-down assembly designAll panels and frames connect with standard hex hardware for on-site assembly and reconfiguration of cubicle layouts
Partition mounting rail systemIntegrated horizontal rails on partition frames support optional accessories like monitor arms, document holders, or coat hooks
Under-desk cable raceway compatibilityRecessed channel along partition bottom supports separate power and data cable runs separated from leg space
Lockable storage accessKeyed drawer lock secures valuable supplies, with optional central locking upgrade available for the lower cabinet
Reference Adjustment / Operating Range100 mm or 120° where applicable
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Packaging Volume0.8 m³/set
Reference Packaged Gross Weight120 kg/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Open-plan office staff workstationsSuitable for 1 person per cubicle, with privacy partitions to reduce distraction in dense office layouts
Administrative and data entry work areas750mm work height and generous knee clearance support all-day seated computer work
Call center and customer service floorsVented mesh upper partitions allow air circulation while maintaining voice privacy between adjacent agents
Startup and co-working flexible officesKnock-down design supports fast reconfiguration of workstation layouts as team sizes change
Government and corporate procurement projectsMeets standard commercial furniture specification requirements for durability and formaldehyde limits
Small business back-office work areasIntegrated storage eliminates need for separate filing cabinets, saving floor space in compact offices
Temporary project team workspacesModular design allows quick assembly and disassembly for short-term project office setups
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 527-1:2011Office work tables safety and strength requirements, applicable for commercial office desk stability
EN 1335-1:2020Office furniture work chair dimensional coordination, matches fixed 750mm worktop height
EN 14073-2:2004Office storage furniture safety requirements, applicable to integrated pedestal and drawer construction
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.5-2021Desk products performance standard, applicable for worktop load and durability testing
ANSI/BIFMA X5.9-2019Storage units performance standard, applicable for drawer load and cycle testing
ANSI/BIFMA e3-2019Furniture sustainability standard, applicable for low-VOC material verification
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for wooden furniture, applicable to worktop and cabinet panel construction
GB 18580-2017Formaldehyde emission limits for wood-based panels, required for indoor office air quality compliance
GB/T 35607-2017Green product assessment specification for furniture, applicable for low-emission material verification
GB/T 10357.1-2013Furniture mechanical performance test for tables, applicable to worktop load and stability testing
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to worktop and cabinet panel construction;
2. GB 18580-2017:Formaldehyde emission limits for wood-based panels, required for indoor office air quality compliance;
3. GB/T 35607-2017:Green product assessment specification for furniture, applicable for low-emission material verification;
4. GB/T 10357.1-2013:Furniture mechanical performance test for tables, applicable to worktop load and stability testing;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · L-CUB-1600-PED-MESH

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · L-CUB-1600-PED-MESH

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · L-CUB-1600-PED-MESH打开导出工具

页面快速操作

发布采购询价

产品描述

The Single-Person L-Shaped Office Cubicle Workstation with Integrated Storage Pedestal (model L-CUB-1600-PED-MESH, unbranded) is a purpose-built commercial fixed-height work solution designed to balance privacy, functionality, and space efficiency for professional work environments. Its wrap-around 90-degree corner layout spans equal 1600mm L-arms with a 1200mm tall partition, 750mm standard work surface height, 700mm depth per worktop arm, and 600mm minimum knee well width with 650mm clearance for comfortable seated use. The two-sided partition combines a fabric-wrapped 9mm MDF core lower panel for acoustic privacy, with a vented perforated silver powder-coated steel mesh upper panel that preserves natural light transmission and cross-ventilation, while blocking direct line of sight from adjacent work areas. The 25mm thick E1-grade melamine-faced particleboard worktop is finished with 2mm rounded PVC edge banding, supported by 30mm diameter powder-coated tapered steel legs fitted with 10mm adjustable floor glides to compensate for uneven flooring and maintain a level work surface. The integrated fixed storage pedestal, constructed from 18mm thick matching E1 melamine-faced particleboard with coordinated PVC edge banding, sits beneath one work arm to eliminate the need for separate storage furniture: it includes an open 360x500x120mm internal top shelf for frequently accessed items, a lockable drawer with zinc-alloy keyed cam lock (two keys included) mounted on zinc-plated 3-section full-extension cold-rolled steel ball-bearing slides rated for 50000 open/close cycles, and a lower enclosed cabinet for personal belongings. A color-matched 60mm round ABS brush-style cable grommet routes power and data cords through the work surface, paired with a recessed under-partition channel that supports separated power and data cable runs clear of leg space to reduce surface clutter. Integrated horizontal mounting rails on the silver anodized 1.2mm extruded aluminum partition frame accommodate optional accessories such as monitor arms, document holders, or coat hooks. The work surface supports 80kg of uniform static load, the melamine finish offers 2000 cycles of abrasion resistance, and structural components carry a 5-year warranty, with 8 available color options to coordinate with existing office interiors. This workstation is suited for open-plan office staff zones, administrative and data entry areas, call center floors, flexible co-working and startup spaces, small business back offices, and government or corporate procurement projects that require compliant commercial grade furniture. Its knock-down assembly uses standard hex hardware for 40-minute on-site assembly per set, shipped in two cartons, and supports easy reconfiguration as team needs change, with a total assembled weight of 110kg and recommended maximum seated user weight of 110kg. Procurement teams should note the knock-down format requires on-site assembly, confirm color selection prior to order, and account for the unit’s 110kg assembled weight and 120kg packaged gross weight for delivery and installation planning.
