2-Person L-Shaped Modular Office Cubicle Workstation with Lockable End Storage Cabinets,型号 CUB-L2-1200-GRGR,归属“L型办公桌”栏目,整体尺寸 3050 × 1650 × 1140 mm,主材为Particle‑board (PB)。承重参数:113 kg。认证标签:two-tone,fabric,partitions,integrated,lockable,storage,L-shaped,work,bays,modular,panel,system。本页汇总该型号 6 类产品参数及 GB / EN / ANSI/BIFMA 标准参考,支持公制与英制单位切换,目前已登记 1 家供应商,可直接发起询价。
| 纠错时间 | 修改字段 | 原参数 | 修改后参数 | 说明 / 状态 |
|---|---|---|---|---|
暂无参数纠错记录,发现错误可点击行末旗标提交 | ||||
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| Overall assembled footprint | 3050 x 1650 x 1140 mm | |
|---|---|---|
| Worksurface depth | 610 mm | |
| Seated worksurface height | 750 mm | |
| Under-desk knee clearance height | 680 mm | |
| Partition panel thickness | 25 mm | |
| Lower opaque partition height | 700 mm | |
| Upper green privacy screen height | 440 mm | |
| Integrated end cabinet dimensions | 450 x 600 x 1140 mm | |
| Curved front entry edge radius | 300 mm | |
| Leveling foot adjustment range | 20 mm | |
| Desktop cable grommet diameter | 60 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Per-worksurface static load capacity | 113 kg | |
|---|---|---|
| Total packaged system weight | 300 kg | |
| Recommended user capacity | 2 people | |
| Commercial surface abrasion resistance | 2000 cycles | |
| Limited product warranty | 10 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Worksurface construction | 25 mm thermally fused laminate over particleboard core | |
|---|---|---|
| Partition panel construction | 25 mm composite hardboard core, fabric upholstery over powder-coated steel frame | |
| Frame and support hardware | 1.2 mm thick powder-coated steel connectors and support posts | |
| Storage cabinet construction | 18 mm melamine-faced engineered wood cabinet body with matching white laminate finish | |
| Leveling components | Reinforced nylon adjustable leveling feet with steel threaded stems | |
| Underside modesty panel | 3 mm thick dark grey steel panel |
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Cable management system | Integrated base raceways with desktop grommets | |
|---|---|---|
| Storage access control | Keyed cam locks on all integrated end cabinet doors | |
| Modular reconfiguration | Steel bracket panel connectors allow layout rearrangement | |
| Floor stability adjustment | Threaded leveling feet at all partition and cabinet bases |
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Open plan office spaces | Designed for two-person team clusters in corporate open office layouts, provides seated visual privacy | |
|---|---|---|
| Small business team work areas | Suitable for startup or branch office work zones, integrates storage without additional furniture |
欧洲市场准入与化学品要求
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to desk surfaces | |
|---|---|---|
| EN 1335-1:2020 | Office furniture work chair dimensional coordination, aligned to desk clearance | |
| EN 1022:2018 | Domestic and contract furniture seating stability reference for chair clearance |
美国及加拿大家具标准
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard for commercial office worksurfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard applicable to integrated lockable cabinets |
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminate work surfaces and cabinets | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel frames and hardware | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to engineered wood components |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to laminate work surfaces and cabinets; 2. GB/T 3325-2017:Metal furniture general technical requirements, applicable to steel frames and hardware; 3. GB 18580-2017:Formaldehyde emission limits for wood-based panels, applicable to engineered wood components; 最终交付参数、检测报告和验收标准以双方采购合同为准。
