PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源：工厂资料结构化字段，最终以实测值为准

Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源：产品性能数据，采购前请核对具体测试口径

Work surface distributed load	80 kg per seat
Mobile pedestal load capacity	30 kg total
Drawer slide dynamic load	15 kg per drawer
Caster load rating	30 kg per set of 4
Partition lateral stability target	20 kg horizontal force at 1000 mm height
Seating capacity	2 users
Product net weight	95 kg
Floor loading	39.6 kg per square meter
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源：以工厂材质清单与验货报告为准

Work surface	25 mm melamine-faced particleboard with matching light oak grain and impact-sealed edge banding
Partition lower panels	Wood-composite core with beige fabric-laminate privacy facing inside dark aluminum rails
Upper screen section	Translucent ribbed acrylic or polycarbonate light panel in an aluminum frame
Screen frame and posts	Dark gray powder-coated extruded aluminum sections with visible corner connectors
Under-worktop support	Dark gray powder-coated steel beam and vertical end supports forming the rear modesty structure
Mobile pedestal	Light oak melamine cabinet body, black side/back panel, white drawer pull, lock, and four twin-wheel casters

PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源：功能配置参数，以供应商正式规格为准

Workstation configuration	Two face-to-face seated positions separated by a central low partition, with end screens providing side privacy
Cable management	One 60 mm round grommet routes monitor and power cables from the work surface into the rear support zone
Storage and mobility	Mobile pedestal provides one lockable upper drawer and one lower cabinet or file compartment on four swivel casters
Privacy and light control	Lower opaque panels block sightlines while the upper translucent strip retains borrowed light between workstations

PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源：外贸报价与装柜测算参考

Number of packages	4 cartons
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源：依据产品结构与品类整理的推荐应用场景

Open-plan office	Suitable for administrative and clerical teams needing two defined seats, visual privacy, and shared footprint efficiency
Back-office or processing center	Suits document, computer, and telephone workflows because each seat has a 1200 mm top, grommet, and lockable mobile storage

STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 527-1:2011+A1:2019	Office work tables and desks, safety and dimensional requirements for the work surfaces.
EN 527-2:2002+A1:2019	Mechanical safety requirements for office work tables, applicable to load and stability verification.
EN 1023-1:1996	Office storage furniture dimensional requirements, applicable to the mobile pedestal.
EN 1023-2:2000	Office storage furniture safety requirements, applicable to drawer, lock, and tip-over checks.
EN 13986:2004+A1:2015	Wood-based panels for construction and furniture use, applicable to board performance documentation.

STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.5

STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to the melamine worktops and pedestal cabinet.
GB/T 3325-2017	General technical requirements for metal furniture, applicable to steel supports and aluminum screen framing.
GB/T 3326-2016	Furniture dimensional coordination, applicable to desk height, clearances, and seated-use verification.
GB 18580-2017	Formaldehyde emission limit for wood-based panels, applicable to particleboard components and laminates.
GB/T 10357.5-2011	Furniture surface physicochemical test for paint or film hardness, applicable as a laminate-surface acceptance reference.

招标文件标准化描述文本

本产品须满足以下技术参数要求：
1. GB/T 3324-2017：General technical requirements for wooden furniture, applicable to the melamine worktops and pedestal cabinet.；
2. GB/T 3325-2017：General technical requirements for metal furniture, applicable to steel supports and aluminum screen framing.；
3. GB/T 3326-2016：Furniture dimensional coordination, applicable to desk height, clearances, and seated-use verification.；
4. GB 18580-2017：Formaldehyde emission limit for wood-based panels, applicable to particleboard components and laminates.；
5. GB/T 10357.5-2011：Furniture surface physicochemical test for paint or film hardness, applicable as a laminate-surface acceptance reference.；
最终交付参数、检测报告和验收标准以双方采购合同为准。

GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告，可选择公制或英制单位。

PDF · WS-P2F-2400-MP

完整参数 Excel

导出全部商品信息与参数模块，文件内容统一使用英文。

XLSX · WS-P2F-2400-MP

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段，可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · WS-P2F-2400-MP打开导出工具

页面快速操作

发布采购询价

产品描述

The Two-Person Face-to-Face Partition Workstation with Mobile Pedestal is an unbranded office cubicle desk configured for two users in opposing seated positions. Its layout balances shared footprint efficiency with personal separation: a central low partition runs between the two work zones, while end screens add side privacy. The lower partition uses opaque panels to block direct sightlines, and the upper translucent ribbed acrylic or polycarbonate strip preserves borrowed light across the workstation. Dark gray powder-coated aluminum posts and frames, visible corner connectors, light oak grain surfaces, and beige fabric-laminate privacy facing create a structured commercial appearance. Construction combines panel, metal, and composite elements. The work surface is 25 mm melamine-faced particleboard with matching light oak grain and impact-sealed edge banding, presented with a finished top thickness of 50 mm. Partition lower panels use a wood-composite core set within dark aluminum rails. The frame and trim are extruded aluminum, while a dark gray powder-coated steel beam and vertical end supports sit beneath the worktop and form the rear modesty structure. Each main seat provides effective knee clearance of 680 mm in height and 900 mm in width, with a main support section of 80 mm and 2 mm metal wall thickness. Practical features support daily desk-based work. A 60 mm round cable grommet on each surface routes monitor and power cords into the rear support zone, which accommodates an 80 mm cable opening and a cable tray depth of 120 mm. The included mobile pedestal has a light oak melamine body, black side and back panels, a white drawer pull, a lock, and four twin-wheel swivel casters. It offers one lockable upper drawer and one lower cabinet or file compartment, allowing users to move personal or work materials beside either seat as needed. Rated seating capacity is two users, with work surface distributed load capacity of 80 kg per seat; pedestal capacity is 30 kg total, drawer slide dynamic capacity is 15 kg per drawer, and caster capacity is 30 kg per set of four. This workstation is well suited to open-plan offices, administrative and clerical areas, back-office teams, and processing centers where computer, telephone, and document tasks require defined seating, visual privacy, and compact shared space. It also fits residential settings used as a dual study or administrative workspace where a more commercial-style layout is acceptable. Procurement planning should account for site access, floor protection, and assembly coordination, as the set is supplied in multiple cartons and requires assembly. Buyers should also confirm power and data routing requirements, pedestal placement within the knee space, floor surface suitability for casters, and whether the light oak, dark gray frame, and beige partition palette aligns with the interior scheme.

Two-Person Face-to-Face Partition Workstation with Mobile Pedestal Specifications
