4-Person F-Config Modular Office Cubicle Workstation Cluster with Mobile Pedestals Specifications

CUB-4F-SLAT-MP-LWGRN

代码:DZ7F25V1
获取供应商报价
2026-09-02 12:00人气: 22
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

CUB-4F-SLAT-MP-LWGRN

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall cluster dimensions3220 x 3220 x 1200 mm
Individual worksurface size1400 x 700 mm per station
Finished worksurface height750 mm
Seated knee clearance height650 mm
Lower solid privacy panel height900 mm
Upper slatted transom panel height300 mm
Partition panel thickness60 mm
Mobile pedestal dimensions400 x 500 x 600 mm
Worksuface thickness25 mm
Partition frame profile thickness1.5 mm
Caster wheel diameter for pedestals50 mm
Primary Component Thickness40 mm according to load-bearing role
Hardware / Moving-part Clearance5 mm operating clearance
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Per-station worksurface static load capacity100 kg
Partition ambient noise reduction40%
Worksuface surface hardness2H
Total product net weight reference220 kg
Recommended user capacity4 people
Product service life reference10 years
Available finish options14 colors
Reference Static Load150 kg depending on category
Moving-part Durability ReferenceAcceptance target 50000 cycles
Recommended Procurement WarrantyStructure 5 years; hardware 3 years
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Worksurface coreE1-grade MDF engineered wood
Worksurface facingMelamine laminate with anti-scratch, anti-stain coating
Worksurface edge banding2mm PVC edge trim
Partition support frameDark powder-coated cold-rolled steel
Lower partition privacy panelsTwo-tone melamine composite (light wood, sage green)
Upper partition slatted panelsPerforated/slatted composite grille
Mobile pedestal constructionCold-rolled steel cabinet with melamine drawer fronts
Pedestal castersHard nylon swivel casters with brake
Partition connecting hardwareZinc-plated steel joint connectors
Cable management componentsABS plastic wire raceways integrated into partition frames
Primary Connector SpecificationReference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color CountRecommended 6finish options
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Modular layout configurationF-shape 4-station cross cluster with shared central partition structure
Privacy partitioningMid-height dividers separate individual work zones, upper slats allow light transmission
Mobile storage accessEach station includes a wheeled 3-drawer pedestal that rolls freely under the desk
Cable routingBuilt-in raceways route power and data cables from floor level to worksurface
Knockdown assemblyFlat-pack design allows on-site reconfiguration and disassembly for relocation
Pedestal mobility lockTwo locking casters per pedestal prevent unintended movement when positioned
Acoustic performanceSolid lower partition panels block direct line of sight and reduce cross-station noise
Custom layout adaptabilityModular connection system supports reconfiguration to T-shape, I-shape or cross layouts
Warranty coverage5 year limited warranty for structural frame and worksurface components
Reference Adjustment / Operating Range100 mm or 120° where applicable
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Packaging Volume0.8 m³/set
Reference Packaged Gross Weight120 kg/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Open plan office staff zonesIdeal for 4-person team clusters, balancing privacy and collaborative visibility
Call center and admin work areasDurable worksurfaces and integrated storage suit high-utilization daily desk work
Startup and co-working spacesModular design allows flexible reconfiguration as team size changes
Small business back office spacesAll-in-one cluster provides dedicated work zones without full-height wall construction
Government and corporate open officesCommercial-grade construction meets regular use requirements for permanent staff seating
Educational institution staff roomsDurable surfaces and mobile storage support administrative and teaching staff tasks
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 527-2:2002+A1:2019Office worktables safety and strength requirements, applicable to worksurface load testing
EN 1335-1:2020Office furniture dimensional coordination for seated workstations, applicable to clearance dimensions
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.5-2021Desk products performance standard, applicable to worksurface static load and durability
ANSI/BIFMA X5.9-2019Storage units performance standard, applicable to mobile pedestal load testing
ANSI/BIFMA e3-2019Furniture sustainability standard for material emissions and corporate responsibility
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for wooden office furniture, applicable to worksurfaces and panels
GB/T 3327-2017Performance test standards for office desks and workstations, applicable to load testing
GB 18580-2017Formaldehyde emission limits for wood-based panels, applicable to E1-grade core material
GB/T 24821-2009Performance requirements for office panel furniture hardware and connectors
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for wooden office furniture, applicable to worksurfaces and panels;
2. GB/T 3327-2017:Performance test standards for office desks and workstations, applicable to load testing;
3. GB 18580-2017:Formaldehyde emission limits for wood-based panels, applicable to E1-grade core material;
4. GB/T 24821-2009:Performance requirements for office panel furniture hardware and connectors;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · CUB-4F-SLAT-MP-LWGRN

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · CUB-4F-SLAT-MP-LWGRN

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · CUB-4F-SLAT-MP-LWGRN打开导出工具

页面快速操作

发布采购询价

产品描述

This 4-Person F-Config Modular Office Cubicle Workstation Cluster with Mobile Pedestals is an unbranded commercial-grade office furniture solution, designed to balance personal privacy, collaborative accessibility, and spatial efficiency for shared work environments. The cluster adopts an F-shaped four-station cross layout anchored by a shared central partition structure, spanning 3220 x 3220 x 1200 mm overall. Mid-height partitions separate individual work zones, with solid two-tone lower panels finished in light wood and sage green reaching 900 mm tall to block direct line of sight, paired with 300 mm tall upper slatted transom panels that allow natural light transmission across the cluster. Each station includes a 1400 x 700 mm worksurface set at a 750 mm finished height, with 650 mm of seated knee clearance to support comfortable, ergonomic seated work. The workstation is built for long-term, high-frequency use: worksurfaces use an E1-grade MDF core faced with scratch- and stain-resistant melamine laminate, finished with 2mm PVC edge trim for impact protection, and rated to support 100 kg of static load with a 2H surface hardness. The partition structure is supported by a dark powder-coated cold-rolled steel frame, with 60 mm thick composite panels that deliver 40% ambient noise reduction between adjacent stations. Each user is assigned a cold-rolled steel mobile pedestal measuring 400 x 500 x 600 mm, fitted with hard nylon swivel casters (two locking per unit) that allow the 3-drawer unit to roll freely under the desk for accessible storage, and lock in place to prevent unintended movement. Additional functional details include built-in cable raceways to route power and data cables from floor level to the worksurface, and a knockdown flat-pack design that supports on-site reconfiguration and easy disassembly for relocation. This cluster is well suited for open plan office staff zones, call center and admin work areas, startup and co-working spaces, small business back offices, corporate and government open offices, as well as educational institution staff rooms, where it delivers dedicated individual work zones without requiring full-height permanent wall construction. The referenced product service life is 10 years, with 14 available finish options to align with varied interior design schemes. For procurement, note that each set ships in 2 cartons with a packaged gross weight of 120 kg and 0.8 m³ packaging volume, with a referenced assembly time of 40 minutes per set; the total net weight of the assembled unit is 220 kg.
