商品供应商L-Shaped Panel Workstation with Integrated Storage Pedestals and Privacy Screens,Particle‑board (PB)
可联系供应商获取生产周期与报价。
| 纠错时间 | 修改字段 | 原参数 | 修改后参数 | 说明 / 状态 |
|---|---|---|---|---|
暂无参数纠错记录,发现错误可点击行末旗标提交 | ||||
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Distributed work-surface load | 100 kg | |
|---|---|---|
| Concentrated work-surface load | 30 kg | |
| Single cabinet shelf load | 25 kg | |
| Recommended user capacity | 1 person | |
| Product net weight | 85 kg | |
| Drawer or door cycle reference | 50,000 cycles | |
| Leveling adjustment | 10 mm | |
| Distributed work-surface static load | 100 kg | |
| Pedestal cabinet top load | 60 kg | |
| Drawer or door hardware cycle target | 50000 cycles |
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Work surface | 25 mm wood-grain high-pressure laminate-faced board with sealed matching edgeband | |
|---|---|---|
| Cabinet doors | Vertical-grain laminate-faced particleboard or MDF doors, two visible on right cabinet | |
| Cabinet side panels | 18 mm light-grey laminate board forming floor-standing storage supports | |
| Rear work-surface rail | Wood-grain horizontal rail supporting the lower edge of the privacy screen | |
| Privacy screen panels | Translucent ribbed polymer or frosted acrylic infill with horizontal louvers | |
| Screen frame | Dark grey aluminium or powder-coated steel extrusion with mitred top perimeter | |
| Corner support and screen post | 40 mm square dark metal post joining the two screen runs | |
| Modesty panel | Dark grey composite or steel-backed panel beneath rear work surface | |
| Cable grommet | White round plastic grommet with black cable slot, 80 mm diameter | |
| Power outlet module | Black rectangular socket plate mounted on rear lower rail | |
| Base and leveling hardware | Black concealed foot caps or leveling glides under cabinet and panel bases | |
| Curved front edge | Laminated board edge formed with a concave radius and continuous edgeband |
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| L-shaped work layout | Left and rear work surfaces form a 1400 mm corner workstation for one seated user | |
|---|---|---|
| Integrated storage support | Left cabinet and right two-door cabinet double as floor-standing worktop supports | |
| L-shaped seated workflow | Left and rear tops provide a 1400 x 1400 mm corner layout for one user and dual work zones | |
| Pedestal-supported construction | Left and right floor-standing cabinets carry the work surface without exposed independent legs | |
| Concealed storage access | Right cabinet uses two hinged doors opening from the front for books, files or personal items | |
| Privacy screening | Two 350 mm-high translucent ribbed screens block direct sightlines while transmitting diffused light | |
| Cable pass-through | An 80 mm desktop grommet routes monitor and power cables from the work surface to the rear cavity | |
| Vertical cable concealment | Rear modesty panels hide cables running from the grommet toward the lower outlet and cable tray | |
| Power-module mounting | A black rear outlet plate provides a fixed mounting position for mains and charging sockets | |
| Floor leveling | Threaded glides provide 10 mm vertical compensation on uneven office floors | |
| Knee-space protection | The concave front edge creates a 700 mm wide and 680 mm high seated leg opening | |
| Modular panel joining | Metal corner posts connect two screen runs and permit adjacent workstation clusters |
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Open-plan office workstation | Suitable for one staff member needing visual privacy and L-shaped document or monitor space | |
|---|---|---|
| Financial or paperwork role | Supports documents, calculator, keyboard and reference materials across two work zones | |
| Supervisor workstation | Provides semi-private individual work space in clusters without constructing full-height offices | |
| Government or enterprise desk pool | Suits standardized procurement rows where identical panels, cabinets and grommets ease replacement | |
| Hot-desk neighborhood | Can be grouped into clusters for rotating knowledge workers with cable and power access | |
| Small private office | Fits a single executive or specialist office needing storage and a compact corner layout |
欧洲市场准入与化学品要求
美国及加拿大家具标准
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
适用于中国市场项目的标准
本产品须满足以下技术参数要求: 1. 技术标准与检测报告由供应商在投标或采购确认阶段提供; 最终交付参数、检测报告和验收标准以双方采购合同为准。
以下文件均根据当前已发布商品参数实时生成。
直接下载英文参数报告,可选择公制或英制单位。
导出全部商品信息与参数模块,文件内容统一使用英文。
包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。
生成申报品名、材质、用途、尺寸及海关申报要素。
打开导出工具
