4-Person Cross-Shaped Modular Office Cubicle Workstation with Storage Pedestals Specifications

CRX-4P-OFC-1200

代码:PRM095V1
获取供应商报价
2026-09-02 11:24人气: 17
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

CRX-4P-OFC-1200

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Primary Component Thickness40 mm according to load-bearing role
Hardware / Moving-part Clearance5 mm operating clearance
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

total cluster net weight280 kg
static vertical load per work surface100 kg
static load per drawer25 kg
seated user capacity4 persons
surface abrasion resistance2000 cycles
surface scratch resistanceGrade 1
hardware salt spray corrosion resistance48 hours
Reference Static Load150 kg depending on category
Moving-part Durability ReferenceAcceptance target 50000 cycles
Recommended Procurement WarrantyStructure 5 years; hardware 3 years
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

work surface panel25 mm E1 melamine-faced particleboard
cabinet body panel16 mm E1 melamine-faced particleboard
partition frame1.2 mm thick extruded aluminum alloy with powder coating
partition infill panelSolid melamine panel with upper vented metal strip
edge banding2 mm thick matching-color PVC edging
connecting hardware2.5 mm thick zinc alloy cam locks and screws
support legs20 mm diameter powder-coated tapered steel legs
drawer lockZinc alloy keyed cam lock per pedestal
Primary Connector SpecificationReference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color CountRecommended 6finish options
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

privacy separation350 mm tall above-desk dividers block direct line of sight between adjacent seats
storage configurationEach station has 1 lockable upper drawer and 1 lower cabinet door for personal storage
cable managementInternal partition raceways separate power and data cables with desktop grommet access
modular assemblyKnock-down panel connection allows reconfiguration or extension of workstation clusters
floor levelingSmall adjustable foot pads on leg bases compensate for minor uneven finished floors
storage securityKeyed drawer locks secure personal office items and documents at each station
under-desk spaceOpen knee bays allow unobstructed seated leg movement and office chair clearance
Reference Adjustment / Operating Range100 mm or 120° where applicable
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Packaging Volume0.8 m³/set
Reference Packaged Gross Weight120 kg/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

open plan office areasDense staff seating with partial privacy for 4 employees per cluster
call center and admin departmentsHigh-density work positions with personal storage and cable access
startup and co-working spacesModular layout that supports flexible team expansion over time
government and corporate back officesStandardized workstation configuration that meets procurement durability requirements
staff work zonesSeparated work positions reduce visual distraction between adjacent coworkers
IT and operations teamsBuilt-in cable management keeps power and data cords organized out of sight
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 527-1:2011Safety and strength requirements for office work desks
EN 14073-2:2004Safety requirements for office storage furniture
EN 1335-1:2020Office chair dimensional compatibility for desk workstation clearances
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.5-2021Performance and safety standard for office desk products
ANSI/BIFMA X5.9-2019Performance standard for office storage pedestals and cabinets
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB 18580-2017Formaldehyde emission limits for wood-based panels used in interior decoration
GB/T 3324-2017General technical requirements for wooden office furniture products
GB/T 35607-2017Serviceability and test methods for office work surfaces and storage
GB 18584-2001Limit of harmful substances in wooden furniture for indoor use
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB 18580-2017:Formaldehyde emission limits for wood-based panels used in interior decoration;
2. GB/T 3324-2017:General technical requirements for wooden office furniture products;
3. GB/T 35607-2017:Serviceability and test methods for office work surfaces and storage;
4. GB 18584-2001:Limit of harmful substances in wooden furniture for indoor use;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · CRX-4P-OFC-1200

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · CRX-4P-OFC-1200

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · CRX-4P-OFC-1200打开导出工具

页面快速操作

发布采购询价

产品描述

The Fanshidun CRX-4P-OFC-1200 is a 4-person cross-shaped modular office cubicle workstation cluster designed for balanced density, privacy, and flexible workspace organization. Visually, the unit features a symmetrical cross layout with partial-height dividers that deliver a clean, modern office aesthetic. The 350 mm above-desk dividers block direct line of sight between adjacent seats to reduce visual distraction, with a 1.2 mm powder-coated extruded aluminum frame supporting solid melamine infill panels topped with vented metal strips that soften the partitioned feel without compromising separation. All panel edges are finished with 2 mm thick matching-color PVC edging for a cohesive, polished look, supported by 20 mm diameter tapered powder-coated steel legs fitted with small adjustable foot pads to compensate for minor uneven finished floors. Construction leverages graded E1 melamine-faced particleboard sized for load-bearing function: 25 mm panels form durable work surfaces, while 16 mm panels build storage cabinet bodies. Primary structural components are 40 mm thick per load-bearing requirements, connected with 2.5 mm thick zinc alloy cam locks and screws, with M6-M10 connectors used at major joints with at least 2 fixing points per connection for structural stability. The cluster weighs 280 kg net, supporting 100 kg of static vertical load per work surface, 25 kg of static load per drawer, surface abrasion resistance for 2000 cycles, Grade 1 surface scratch resistance, and 48 hours of salt spray corrosion resistance for hardware, with 5 mm operating clearance for moving parts. Each pedestal includes a zinc alloy keyed cam lock to secure contents. Practical features support daily office use: each of the 4 seated workstations comes with one lockable upper drawer and one lower cabinet door for personal storage, internal partition cable raceways that separate power and data cables accessed via desktop grommets, open knee bays for unobstructed leg movement, and knock-down panel connections that allow reconfiguration or extension of clusters as needed. The unit is suited for open plan offices, call center and admin departments, startup and co-working spaces, government and corporate back offices, general staff work zones, and IT and operations teams, supporting high-density seating with standardized durability and flexible layout potential. For procurement, note that each set ships in 2 cartons with 0.8 m³ packaged volume and 120 kg packaged gross weight, requiring 40 minutes of assembly time per unit, with modular compatibility to scale installations over time.
