PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源：工厂资料结构化字段，最终以实测值为准

产品外部尺寸（宽 × 深 × 高）	3759 × 3708 × 1575 mm
Overall footprint	3759 x 3708 x 1575 mm
Single work surface size	1200 x 610 mm
Work surface height	750 mm
Privacy partition height	1575 mm
Partition panel thickness	41 mm
Work surface thickness	25 mm
Cable grommet diameter	60 mm
Knee clearance height under desk	680 mm
Per-station storage pedestal size	400 x 600 x 650 mm
Perforated metal partition strip height	150 mm
Tapered support leg height	120 mm
Pedestal drawer internal height	240 mm
Primary Component Thickness	40 mm according to load-bearing role
Hardware / Moving-part Clearance	5 mm operating clearance

PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源：产品性能数据，采购前请核对具体测试口径

Per work surface static load capacity	91 kg
Total product shipping weight	517 kg
Recommended maximum user weight per seat	136 kg
Work surface abrasion resistance	2000 cycles
Surface stain and water resistance rating	Level 3
Fabric partition noise reduction coefficient	0.35
Standard product warranty	10 years
Available color options	60
Reference Static Load	150 kg depending on category
Moving-part Durability Reference	Acceptance target 50000 cycles

PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源：以工厂材质清单与验货报告为准

Work surface panel	25mm thick E1 grade melamine-faced MFC board, 2mm PVC edge banding
Privacy partition core	15mm thick MDF core with 13mm high-density foam padding, wrapped in taupe polyester fabric
Partition top accent strip	Perforated cold-rolled steel with silver powder-coat finish
Partition support frame	1.2mm thick extruded aluminum profile with matte silver anodized finish
Storage cabinet body	18mm thick matching melamine-faced particleboard with PVC edge sealing
Drawer and cabinet door hardware	Zinc-alloy lock core, cold-rolled steel drawer slides, plastic recessed handles
Support legs	Tapered 1.5mm thick steel tube with dark powder-coat finish, adjustable leveling foot
Cable grommet	ABS plastic round cable pass-through with brush insert
Primary Connector Specification	Reference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color Count	Recommended 6finish options

PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源：功能配置参数，以供应商正式规格为准

Seated user separation	Full-height fabric partitions block direct line of sight between adjacent 4 users for visual privacy
Per-workstation storage	1 lockable top drawer for office supplies + 1 lower closed cabinet for personal items per seat
Cable management	Round desktop grommet routes power/data cables from surface to under-desk area, with optional under-desk raceway
Modular assembly	Knock-down CKD construction allows reconfiguration of panel and desk segments for layout changes
Leveling adjustment	Adjustable feet on each support leg compensate for uneven office floors by up to 15mm
Partition surface utility	Tackable fabric panel surface allows pinning of notes, documents and office decor
Lockable storage security	Keyed lock on each top drawer secures personal valuables and work materials
Acoustic distraction reduction	Foam-backed fabric partitions absorb ambient office speech noise to reduce cross-seat distraction
Reference Adjustment / Operating Range	100 mm or 120° where applicable

PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源：外贸报价与装柜测算参考

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源：依据产品结构与品类整理的推荐应用场景

Open plan office staff zones	Fits 4 employees in open office spaces to create independent, low-distraction work positions with built-in storage
Small business work areas	Compact cross layout uses minimal square footage while providing full dedicated workspace for 4 team members
Co-working space dedicated desks	Partitioned design provides semi-private permanent workstations with personal lockable storage for co-working members
Call center work floors	Fabric partitions reduce cross-talk distraction for high-concentration phone and computer work
Back-of-house office areas	Durable laminate construction and integrated storage support administrative, accounting and operational staff daily use
Government and institutional offices	Standard ergonomic dimensions and lockable storage meet public sector workspace functional and security requirements

STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 527-1:2011	Office work tables – Part 1: Dimensions, applicable to ergonomic desk height and clearance requirements
EN 527-2:2002+A1:2019	Office work tables – Part 2: Mechanical safety requirements, applicable to structural stability
EN 1335-1:2020	Office work furniture seating dimensions reference for seated clearance compatibility
EN 1022:2018	Furniture – Seating and tables – Determination of stability, applicable to workstation structure

STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.5-2021	Standard for desk products, applicable to work surface load and durability testing
ANSI/BIFMA X5.1-2017	Standard for office chairs, referenced for seated clearance compatibility
ANSI/BIFMA M7.1-2020	Standard test method for determining VOC emissions from office furniture systems
ANSI/BIFMA G1-2013	Ergonomic guidelines for office furniture, applicable to work surface height and clearance

STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to laminate desk and cabinet components
GB/T 1951.1-2010	Performance test methods for desks for office and institutional use, applicable to work surface load testing
GB 18580-2017	Formaldehyde emission limit for wood-based panels, required for E1 grade board verification
GB/T 4893.8-2013	Surface wear resistance test for furniture coatings, applicable to melamine work surfaces

招标文件标准化描述文本

本产品须满足以下技术参数要求：
1. GB/T 3324-2017：General technical requirements for wooden furniture, applicable to laminate desk and cabinet components；
2. GB/T 1951.1-2010：Performance test methods for desks for office and institutional use, applicable to work surface load testing；
3. GB 18580-2017：Formaldehyde emission limit for wood-based panels, required for E1 grade board verification；
4. GB/T 4893.8-2013：Surface wear resistance test for furniture coatings, applicable to melamine work surfaces；
最终交付参数、检测报告和验收标准以双方采购合同为准。

GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告，可选择公制或英制单位。

PDF · CUB-CRS-4P-TAUPE-2437

完整参数 Excel

导出全部商品信息与参数模块，文件内容统一使用英文。

XLSX · CUB-CRS-4P-TAUPE-2437

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段，可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · CUB-CRS-4P-TAUPE-2437打开导出工具

页面快速操作

发布采购询价

产品描述

The 4-Person Cross Modular Office Cubicle Workstation with Integrated Storage, model CUB-CRS-4P-TAUPE-2437, is an unbranded cross-layout workspace solution designed to support four users in a balanced, space-efficient footprint. Its central cross configuration positions four individual work surfaces facing outward from a shared core, with full-height taupe fabric privacy partitions reaching 1575 mm to block direct line of sight between adjacent users. Each work surface measures 1200 x 610 mm at a standard ergonomic height of 750 mm, supported by tapered dark powder-coated steel legs fitted with adjustable leveling feet that compensate for uneven floors. The partitions use extruded matte silver anodized aluminum framing, with MDF cores wrapped in high-density foam and taupe polyester fabric, topped with a perforated silver powder-coated steel accent strip. Work surfaces are constructed from 25mm E1 grade melamine-faced MFC board with 2mm PVC edge banding, with matching 18mm melamine-faced particleboard used for integrated storage cabinetry fitted with zinc-alloy lock cores, cold-rolled steel drawer slides, and recessed plastic handles. Each workstation includes a lockable top drawer for office supplies and a lower closed cabinet for personal items, with keyed locks securing stored valuables. The tackable fabric partition surface allows pinning of notes and documents, while 60mm diameter ABS plastic cable grommets with brush inserts route power and data cables from the desktop to under-desk areas, with compatibility for optional under-desk cable raceways. Knock-down CKD construction supports reconfiguration of desk and panel segments to adapt to changing layout needs. The work surface supports a static load of 91 kg per position, with a stain and water resistance rating of Level 3, abrasion resistance rated for 2000 cycles, and fabric partitions delivering a 0.35 noise reduction coefficient to reduce cross-talk distraction. This cubicle system is suited for open plan office staff zones, small business work areas, co-working space dedicated desks, call center floors, back-of-house administrative spaces, and government or institutional offices, where its compact cross layout minimizes required square footage while delivering dedicated, low-distraction work positions. Procurement teams should note that the unit ships in 2 cartons per set, with a reference assembly time of 40 minutes per set, and comes backed by a 10-year standard product warranty. It has a 680 mm knee clearance height under each desk, a 41 mm partition panel thickness, and a recommended maximum user weight of 136 kg per seat to ensure long-term functional use.

4-Person Cross Modular Office Cubicle Workstation with Integrated Storage Specifications
