1-Person L-Shaped Office Cubicle Workstation with Frosted Dividers, 3-Drawer Pedestal and CPU Stand Specifications

CUB-L1600-FR-3DR-CPU

代码:QW7H7HV1
获取供应商报价
2026-09-04 11:03人气: 22
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

CUB-L1600-FR-3DR-CPU

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall footprint1600 x 1600 x 1200 mm
Work surface height750 mm
Work surface thickness25 mm
Work surface depth (main work area)600 mm
Knee clearance height under desk725 mm
3-drawer fixed pedestal dimension400 x 550 x 725 mm
Frosted glass partition thickness5 mm
Lower solid partition panel thickness40 mm
PVC edge banding thickness2 mm
Wheeled CPU shelf dimension250 x 500 x 120 mm
Cable grommet diameter60 mm
Drawer front height (per drawer)150 mm
Primary Component Thickness40 mm according to load-bearing role
Hardware / Moving-part Clearance5 mm operating clearance
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Uniform desktop static load80 kg
Single drawer load capacity15 kg
Drawer slide cycle life50000 operations
Net weight (assembled unit)85 kg
Recommended user weight capacity136 kg
Formaldehyde emission limit (panels)0.124 mg/m³
Laminate surface scratch resistance2 N
Warranty period5 years
Available color options5
Reference Static Load150 kg depending on category
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Work surfaceE1 grade particleboard core, light oak melamine laminate, 2mm PVC edge banding
Partition upper section5mm frosted tempered glass, white powder-coated steel frame
Partition lower sectionE1 grade melamine-faced MDF panel, light wood finish
Partition frame1.2mm thick 6063-T5 aluminum alloy, white powder-coated finish
Drawer pedestal bodyE1 grade melamine-faced particleboard, light gray drawer fronts, white curved plastic handles
Drawer slides3-section full-extension steel ball-bearing slides, zinc-plated finish
Pedestal lockCentralized keyed cam lock, controls all 3 drawers simultaneously
CPU stand0.8mm thick cold-rolled steel shelf, 4 30mm black nylon casters
Cable management60mm ABS plastic cable grommet, under-desk steel wire raceway
Foot levelers10mm diameter nylon adjustable glides, 15mm adjustment range
Primary Connector SpecificationReference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color CountRecommended 6finish options
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Privacy partition2-sided L-shaped 1200mm high divider with upper frosted glass for semi-private work and light transmission
Drawer storage3 equal-height drawers with full-extension slides, central lock for securing office documents and supplies
CPU storagePull-out wheeled shelf under right desk section, slides out for PC access and ventilation
Cable managementRear desktop grommet routes power and data cables from desk surface to under-desk raceway
Height stabilityAdjustable nylon foot glides compensate for uneven floors, eliminating desk wobble
ReconfigurabilityModular aluminum frame allows connection to adjacent cubicles for multi-seat office layouts
Surface durabilityScratch, stain and water-resistant melamine finish withstands daily office use and cleaning
Assembly requirementKnock-down design requires on-site assembly with included hardware and instruction manual
Reference Adjustment / Operating Range100 mm or 120° where applicable
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Carton packaging specification1650 x 650 x 120 mm per main panel carton, smaller hardware cartons included
Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Packaging Volume0.8 m³/set
Reference Packaged Gross Weight120 kg/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Open plan officeSuitable for open-plan corporate offices, providing individual semi-private workspaces
Startup/co-working spaceIdeal for co-working facilities, reconfigurable for changing team layouts
Government/institution officeSuitable for administrative and public sector office areas, meeting standard commercial furniture specs
Single user work setupAccommodates one office worker with dedicated desk, storage and CPU placement
Call center workspaceAppropriate for call center seating, providing basic privacy and compact footprint
Small business officeSuitable for small business staff workstations, integrated storage reduces need for separate cabinets
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 527-2:2002Office worktables, safety and strength requirements for desk structural performance
EN 12521:2015Furniture, strength, durability and safety for domestic and non-domestic seating-adjacent tables
EN 13986:2004Wood-based panels for construction, formaldehyde emission performance limits
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.5-2021Desk products standard, applicable to load and durability performance for office workstations
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for wooden furniture, applicable to panel desk and pedestal components
GB 18580-2017Formaldehyde emission limit for wood-based panels, E1 grade requirement for indoor use
GB/T 24821-2009General specifications for office desks and workstations, applicable to structural performance
GB/T 35607-2017Safety requirements for office furniture, applicable to edge and stability requirements
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to panel desk and pedestal components;
2. GB 18580-2017:Formaldehyde emission limit for wood-based panels, E1 grade requirement for indoor use;
3. GB/T 24821-2009:General specifications for office desks and workstations, applicable to structural performance;
4. GB/T 35607-2017:Safety requirements for office furniture, applicable to edge and stability requirements;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · CUB-L1600-FR-3DR-CPU

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · CUB-L1600-FR-3DR-CPU

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · CUB-L1600-FR-3DR-CPU打开导出工具

页面快速操作

发布采购询价

产品描述

This 1-person L-shaped office cubicle workstation, model CUB-L1600-FR-3DR-CPU, is an unbranded modular commercial seating solution designed for focused individual work in shared office environments. Visually, it features a clean two-sided L-shaped layout with 1200mm tall partial-height dividers: the upper divider section uses frosted tempered glass set in a white powder-coated aluminum frame to balance light transmission and semi-private separation, while the lower section uses a light wood-finish solid panel paired with a light oak melamine work surface, light gray drawer fronts, and crisp white hardware accents for a modern, professional aesthetic. Constructed for consistent daily use, the unit uses E1 grade panel cores across all work and storage surfaces, finished with scratch, stain, and water-resistant melamine laminate sealed with 2mm PVC edge banding. Its structural framing includes powder-coated metal supports, 3-section full-extension zinc-plated steel ball-bearing drawer slides, a 0.8mm cold-rolled steel wheeled CPU stand with black nylon casters, and adjustable nylon foot glides to eliminate wobble on uneven floors. The work surface supports 80kg of uniform static load, each drawer holds 15kg, and the drawer slides are rated for 50000 operations; all panels meet a 0.124 mg/m³ formaldehyde emission limit. The laminate surface resists scratches up to 2N of force, and the assembled unit weighs 85kg with a 136kg recommended user weight capacity. Functional design elements support streamlined office workflows: the 2-sided divider creates semi-private work space without blocking ambient light, three equal-height lockable drawers secure documents and supplies, the pull-out wheeled CPU shelf enables easy access and ventilation for desktop towers, and integrated cable management routes cords through a desktop grommet to an under-desk steel wire raceway to reduce surface clutter. Its modular aluminum frame supports connection to adjacent matching cubicles for expanded multi-seat layouts. This workstation is well-suited for open-plan corporate offices, co-working and startup spaces, government administrative areas, call centers, small business offices, and dedicated single-user home or professional work setups, with integrated storage that reduces the need for separate filing cabinets. For procurement, note that each unit ships in two cartons with a total packaged gross weight of 120kg and 0.8 m³ packaging volume, requires 40 minutes of assembly time per set, and connects seamlessly with matching modular units to scale with evolving workspace needs.
