PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源：工厂资料结构化字段，最终以实测值为准

产品外部尺寸（宽 × 深 × 高）	3600 × 2400 × 1200 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源：产品性能数据，采购前请核对具体测试口径

Total workstation capacity	6 users
Work surface uniform static load capacity	100 kg
Partition panel lateral stability load	20 kg
Total unit reference net weight	480 kg
Drawer slide cycle durability	50000 open/close cycles
Work surface surface abrasion resistance	2000 revolutions
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Life	Acceptance target 80000 cycles
Top Abrasion Reference	Acceptance target ≥4,000 abrasion cycles or finish-system test

PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源：以工厂材质清单与验货报告为准

Work surface substrate	18mm E1-grade particle board
Work surface finish	0.7mm thick melamine laminate
Partition support frame	Powder-coated extruded aluminum
Lower solid partition panels	Fabric-wrapped medium density fiberboard
Upper partition grille	Horizontal aluminum slat screen
Mobile pedestal drawer fronts	Two-tone melamine-faced particle board
Mobile pedestal casters	Black nylon swivel casters with brake
Desk modesty panel	25mm thick melamine particle board
Drawer lock hardware	Zinc alloy cam lock with keys
Frame connection hardware	Zinc-plated steel screws and brackets
Primary Panel Thickness	25 mm; load-bearing top may use 40 mm composite build-up
Edge Band Thickness	2 mm

PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源：功能配置参数，以供应商正式规格为准

Modular partition connection	Aluminum post-and-rail system
Mobile pedestal storage	2-compartment unit (1 pencil drawer, 1 file drawer)
Cable management	Pre-drilled 60mm diameter desk grommet per station
Privacy screening	1200mm tall partition with opaque lower section
Pedestal mobility	4 swivel casters with 2 front locking brakes
Curved corner work surface	Radiused inner front edge
Drawer security	Keyed alike cam lock per pedestal
Cable Management Capacity	Reference capacity 10power/data cables; tray load 10 kg
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源：外贸报价与装柜测算参考

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源：依据产品结构与品类整理的推荐应用场景

Open plan office spaces	High density 6-person layout
Corporate back-of-house departments	Ideal for administrative, finance, or operations teams
Startup and co-working offices	Modular design supports future layout changes
Government and institutional workspaces	Durable commercial grade construction
Call center and customer service floors	Partial height partitions reduce cross-talk distraction
Project team work areas	Individual stations with adjacent storage

STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

Office furniture safety standard	EN 527:2002+A1:2019
Office furniture storage stability	EN 14073:2004
Formaldehyde emission for wood panels	EN 13986:2004+A1:2015

STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

Desk strength and durability	ANSI/BIFMA X2021
Mobile storage unit performance	ANSI/BIFMA X2019

STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

Desk surface dimensional standard	GB/T 3326
Panel material formaldehyde emission	GB 18580
Office furniture stability requirement	GB/T 10357.2
Hardware durability requirement	GB/T 10357.5

招标文件标准化描述文本

本产品须满足以下技术参数要求：
1. Desk surface dimensional standard：GB/T 3326；
2. Panel material formaldehyde emission：GB 18580；
3. Office furniture stability requirement：GB/T 10357.2；
4. Hardware durability requirement：GB/T 10357.5；
最终交付参数、检测报告和验收标准以双方采购合同为准。

GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告，可选择公制或英制单位。

PDF · CUB-6P-L-2400

完整参数 Excel

导出全部商品信息与参数模块，文件内容统一使用英文。

XLSX · CUB-6P-L-2400

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段，可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · CUB-6P-L-2400打开导出工具

页面快速操作

发布采购询价

产品描述

This 6-Person L-Shaped Modular Office Cubicle Workstation delivers a high-density, reconfigurable work solution designed to balance open collaboration and individual focus for professional work environments. Arranged in an efficient L-shaped layout, the workstation features curved, radiused inner front edges on its corner work surface for comfortable, ergonomic access across all six user positions, paired with 1200mm tall partial-height partitions. These partitions combine opaque fabric-wrapped lower panels for direct sightline and noise distraction reduction with horizontal aluminum slat upper screens that maintain ambient light flow through open floorplans, creating a balanced work environment that avoids the enclosed feel of full-height cubicles. Each user station is built for long-term commercial use, starting with a durable work surface constructed from E1-grade particle board substrate finished with 0.7mm thick melamine laminate, mounted on robust support sections with steel hardware. Partitions are held in place by a powder-coated extruded aluminum post-and-rail connection system that enables straightforward reconfiguration as team needs evolve. Each station includes a pre-drilled cable grommet paired with integrated cable trays to keep power and data cords organized and out of sight, while a thick modesty panel conceals under-desk space for a polished, professional appearance. Every position comes with a matching mobile pedestal built from two-tone melamine-faced particle board, fitted with four black nylon swivel casters; two front casters include locking brakes to hold the unit securely in place when needed. Each pedestal offers two storage compartments: a shallow pencil drawer for small office supplies and a deeper file drawer for document organization, secured by a keyed-alike zinc alloy cam lock for consistent, convenient security. The drawer slides are engineered to withstand repeated daily use over extended service life. This workstation is well suited for a wide range of commercial spaces, including high-density open-plan offices, corporate back-of-house departments supporting administrative, finance or operations teams, flexible startup and co-working environments that require regular layout adjustments, durable government and institutional workspaces, call center and customer service floors where reduced cross-talk improves focus, and dedicated project team areas that pair individual work zones with accessible personal storage. When planning procurement, buyers should note the unit ships across multiple cartons, with a reference assembly time for professional installation teams. The L-shaped footprint requires appropriate corner floor space to accommodate six users, and the modular frame design allows connection to matching workstation units if future workspace expansion is planned. All casters include locking functionality to prevent unintended pedestal movement during daily use, and the melamine work surface finish resists routine abrasion from regular office tasks. Drawer lock systems use matched keys per pedestal to simplify key management for facility teams.

6-Person L-Shaped Modular Office Cubicle Workstation with Mobile Pedestals Specifications
