商品供应商2-Person L-Adjacent Office Cubicle Workstation with Mobile Pedestals,Particle‑board (PB)
可联系供应商获取生产周期与报价。
| 纠错时间 | 修改字段 | 原参数 | 修改后参数 | 说明 / 状态 |
|---|---|---|---|---|
暂无参数纠错记录,发现错误可点击行末旗标提交 | ||||
mm / 英寸自动双单位换算 · 工程采购基础规格
| Overall workstation dimensions | 3020 x 1530 x 1140 mm | |
|---|---|---|
| Per-seat desktop dimensions | 1510 x 610 mm | |
| Desktop thickness | 25 mm | |
| Knee clearance height under desktop | 673 mm | |
| Lower privacy modesty panel height | 420 mm | |
| Upper mesh partition section height | 460 mm | |
| Partition frame thickness | 60 mm | |
| Mobile pedestal dimensions | 400 x 500 x 654 mm | |
| Pedestal caster diameter | 50 mm | |
| Adjustable leveling foot height range | 15 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
净重 / 最大承重 / 适用人数 / 耐久性能
| Total assembled product weight | 160 kg | |
|---|---|---|
| Per-seat desktop static load capacity | 136 kg | |
| Recommended per-user weight limit | 136 kg | |
| Worktop surface abrasion resistance | 2000 cycles | |
| Frame service life rating | 10 years | |
| Available color options | 6 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
| Work surface | E1 grade MFC board with melamine laminate, 2mm PVC edge banding | |
|---|---|---|
| Support frame | Powder-coated square steel tubing, matte silver finish | |
| Partition lower panels | Fabric-covered MDF board, beige-grey finish | |
| Partition upper panels | Metal-framed mesh grille, silver finish | |
| Mobile pedestals | Melamine-faced MDF construction, lockable top drawer, dark grey drawer front | |
| Pedestal casters | Hard nylon dual-wheel casters, 2 per pedestal with locking function | |
| Leveling feet | Injection-molded nylon base with metal threaded stem | |
| Cable management | Plastic desk grommets, under-desk PVC raceway channels | |
| Fastening hardware | Zinc-plated steel cam locks and screws, corrosion-resistant | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
| Privacy partition layout | 90-degree L-shaped partial dividers separate 2 adjacent work positions | |
|---|---|---|
| Mobile pedestal storage | 2 lockable 2-drawer pedestals roll under desks for personal file storage | |
| Floor leveling | Threaded adjustable feet on desk bases correct up to 15mm floor unevenness | |
| Cable management | Top-surface grommets route power and data cables under the work surface | |
| Pedestal mobility | Locking casters allow pedestal repositioning and secure stationary use | |
| Modular configuration | Knock-down frame design supports reconfiguration into alternate layouts | |
| Assembly design | Cam-lock assembly requires no specialized on-site fabrication tools | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
经核验的外箱 / 毛重 / 组装 / 装柜数据
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
推荐空间 / 目标用户 / 使用方式
| Open plan office staff areas | Provides defined personal workspaces with moderate acoustic and visual privacy | |
|---|---|---|
| Call center and customer service floors | Supports close seating while reducing cross-talk between adjacent agents | |
| Small business startup offices | Delivers two dedicated work positions with built-in storage in a compact footprint | |
| Temporary project team spaces | Modular design allows fast reconfiguration as team sizes change | |
| Finance and administrative departments | Lockable mobile pedestals provide secure personal document storage at each seat |
欧洲市场准入与化学品要求
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to work surface design | |
|---|---|---|
| EN 1335-1:2020 | Office furniture dimensional safety for seated work, applicable to knee clearance | |
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to mobile pedestals |
美国及加拿大家具标准
| ANSI/BIFMA X5.5-2021 | Desk products performance and safety standard, applicable to worktop load testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to mobile pedestal durability | |
| ANSI/BIFMA X5.6-2016 | Panel systems performance standard, applicable to partition integrity |
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to wood worktops and pedestals | |
|---|---|---|
| GB/T 3325-2017 | Metal office furniture safety requirements, applicable to steel support frames and partition framing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to MFC/MDF components | |
| GB/T 10357.1-2013 | Desk strength and durability test methods, applicable to worktop load verification |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden office furniture, applicable to wood worktops and pedestals; 2. GB/T 3325-2017:Metal office furniture safety requirements, applicable to steel support frames and partition framing; 3. GB 18580-2017:Formaldehyde emission limits for wood-based panels, applicable to MFC/MDF components; 4. GB/T 10357.1-2013:Desk strength and durability test methods, applicable to worktop load verification; 最终交付参数、检测报告和验收标准以双方采购合同为准。
