L-Shaped Office Workstation with Integrated Storage Hutch Specifications

LWS-H1400-OAK-WHT

代码:SM4W30V1
获取供应商报价
2026-09-24 16:58人气: 6
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

LWS-H1400-OAK-WHT

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源:工厂资料结构化字段,最终以实测值为准

Overall workstation footprint1400 x 1400 x 1595 mm
Primary desktop dimensions1400 x 600 mm
Side-return work surface1200 x 450 mm
Desktop working height750 mm
Knee-well opening700 mm wide x 600 mm deep x 690 mm high
Tall storage return1200 mm wide x 450 mm deep x 1595 mm high
Upper hutch shelf height300 mm clearance
Drawer front size450 mm wide x 160 mm high
Lower cabinet door450 mm wide x 600 mm high
Open lower shelf bay350 mm wide x 420 mm deep x 350 mm high
Rear privacy panel1400 mm wide x 32 mm thick x 1200 mm high
Metal support leg50 x 50 mm section, 720 mm high
Leveler foot diameter30 mm adjustable glides
Desk edge thickness25 mm desktop with 2 mm edge band
Finished Top Thickness50 mm
Effective Knee Clearance680 mm high and 900 mm wide per main seat
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源:产品性能数据,采购前请核对具体测试口径

Static desktop load50 kg distributed load
Upper shelf load per level15 kg distributed load
Lower cabinet shelf load20 kg distributed load
Drawer load capacity10 kg evenly loaded
Product net weight71 kg
Single-user capacity1 seated worker
Surface durability acceptance30,000 double-rub wear cycles
Edge impact acceptance2 kg dropped from 150 mm without delamination
Warranty target5 years limited warranty
Top Static Load Reference150 kg uniformly distributed
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源:以工厂材质清单与验货报告为准

Primary work surface25 mm light-oak woodgrain melamine panel with 2 mm PVC edge band
Storage carcass18 mm white melamine-faced particleboard or MDF panels
Back and divider panels16 mm white melamine board with light-oak horizontal insert
Privacy screenLaminate-faced board with muted terracotta accent strip and dark edge trim
Support legPowder-coated white square steel leg, 50 x 50 mm
Storage base supportsCylindrical polymer or metal adjustable leveler feet
Drawer frontLight-oak melamine panel with black electronic combination lock insert
Cabinet doorFlat light-oak melamine swing door with concealed side hinges
Open shelf boardsWhite melamine shelves with matching PVC edge protection
Fasteners and bracketsSteel cam bolts, brackets and connector plates with zinc or black coating
Lower modesty panelWhite laminate panel with black horizontal trim line
Primary Panel Thickness25 mm; load-bearing top may use 40 mm composite build-up
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源:功能配置参数,以供应商正式规格为准

L-shaped work layoutPrimary desk and perpendicular storage return form a one-person corner workflow with a 750 mm work height.
Electronic drawer lockBlack keypad secures one 160 mm-high drawer for personal items and confidential documents.
Enclosed cabinet storageSingle lower door conceals vertical storage for files, supplies or a small CPU unit.
Open hutch organizationTwo upper open compartments provide 300 mm shelf clearance for books, binders and display items.
Lower open shelvingSide return includes accessible shelf bays for frequently used files and office equipment.
Privacy screening1200 mm rear panel shields the seated user and defines an individual workstation boundary.
Leveling installationAdjustable 30 mm glides compensate for uneven floors beneath the storage base and support points.
Cable-management targetDesktop should accept one 60 mm cable grommet or rear cable scallop for laptop and monitor power leads.
Knockdown assemblyPanels, desktop, hutch, leg and hardware ship disassembled and connect with cam-and-bracket fittings.
Fixed storage orientationHutch occupies the left side in the pictured single-user configuration.
Door swing clearanceHinged lower door requires 450 mm front clearance for full access during maintenance.
Static floor placementUnit is non-castered and intended for fixed office-floor placement with leveler adjustment.
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源:外贸报价与装柜测算参考

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Package DimensionsMain top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight180 kg/set in 4 cartons
Reference Packaging Volume1 m³/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源:依据产品结构与品类整理的推荐应用场景

Private office workstationSuits one executive or administrative user needing a 750 mm desk, storage hutch and visual privacy in a 1400 mm-wide office bay.
Open-plan staff seatingRear 1200 mm screen defines a single seated position in call centers, administration rows and shared office floors.
Home office studyFits a dedicated study corner where laptop work, document storage and binder shelving occur in one footprint.
Managerial workspaceLockable 160 mm drawer and enclosed 600 mm cabinet support confidential papers and personal office items.
Reception back-office areaProvides writing surface and immediate storage for registers, forms, small plants and reference materials.
Project or drafting supportL-shaped layout supports a laptop on the main run and documents or peripherals on the 1200 mm return.
Small business administrationSuitable for accounting, sales or HR staff requiring one seated workstation with file and supply storage.
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 527-1:2011+A1:2024Office desks safety, strength and durability requirements for the work surface and support structure.
EN 527-2:2002+A1:2003Office desk mechanical safety, strength and durability test methods.
EN 15372:2016Furniture strength, durability and safety requirements for non-domestic storage units.
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

North America procurement and testing referenceRecommended references: ANSI/BIFMA X5.5
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for wooden furniture, applicable to panel dimensions, edge finishing and stability.
GB/T 3325-2017Metal furniture general technical requirements, applicable to the steel support leg and hardware.
GB/T 4893.1-2021Surface resistance to cold liquids, suggested for laminate desktop acceptance.
GB 18580-2017Formaldehyde emission limit for wood-based panels, suggested for E1-grade board verification.
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to panel dimensions, edge finishing and stability.;
2. GB/T 3325-2017:Metal furniture general technical requirements, applicable to the steel support leg and hardware.;
3. GB/T 4893.1-2021:Surface resistance to cold liquids, suggested for laminate desktop acceptance.;
4. GB 18580-2017:Formaldehyde emission limit for wood-based panels, suggested for E1-grade board verification.;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · LWS-H1400-OAK-WHT

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · LWS-H1400-OAK-WHT

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · LWS-H1400-OAK-WHT打开导出工具

页面快速操作

发布采购询价

产品描述

The L-Shaped Office Workstation with Integrated Storage Hutch combines a compact corner workflow with built-in organization for a single seated user. Its light-oak work surfaces and white storage panels create a clean, contemporary appearance, while the rear privacy screen introduces a muted terracotta accent and dark edge trim. The primary desk and perpendicular return establish a defined L-shaped layout, with the tall storage return forming one side of the workstation and the upper hutch extending the vertical storage profile. The rear panel visually separates the seated position and gives the footprint a structured, individual-workspace character. Construction uses a 25 mm light-oak woodgrain melamine primary work surface with 2 mm PVC edge banding. Storage components are made from 18 mm white melamine-faced particleboard or MDF, with 16 mm white melamine back and divider panels and a light-oak horizontal insert. The open shelves feature matching PVC edge protection, while a powder-coated white square steel leg supports the desk. Adjustable cylindrical polymer or metal leveler feet beneath the storage base and support points help the workstation sit evenly on imperfect floors. The privacy screen is a laminate-faced board, and the light-oak drawer front includes a black electronic combination lock insert. The cabinet door is a flat light-oak melamine swing door with concealed side hinges. Functionally, the workstation offers a 750 mm working height and separate surfaces that support a laptop on the main run while keeping documents or peripherals within reach on the return. The lockable drawer is suited to personal items and confidential documents, and the lower enclosed cabinet provides concealed space for files, supplies, or a small CPU unit. Two upper open compartments accommodate books, binders, and display items, while lower open shelf bays keep frequently used files and office equipment accessible. Rated capacities include a 50 kg distributed static load on the desktop, 15 kg per upper shelf level, 20 kg for the lower cabinet shelf, and 10 kg evenly loaded in the drawer. The surface is accepted through a 30,000 double-rub wear-cycle test. This model is appropriate for private offices, open-plan administrative rows, call centers, managerial workstations, reception back-office areas, and dedicated home study corners. It is also useful where writing, laptop work, document handling, and reference storage need to occupy one coordinated footprint. Procurement planning should account for the corner orientation, the 1400 by 1400 by 1595 mm overall footprint, 750 mm desk height, and 1595 mm-high storage return. Buyers should also plan for assembly, floor protection, and delivery handling, noting the reference packaging information and the need to coordinate multiple cartons on site.
