Fuchsia Fabric Upholstered Height-Adjustable Swivel Lounge Armchair with 4-Star Chrome Base Specifications

SWL-4CHR-FUS-01

代码:32GVNQV1
获取供应商报价
2026-09-18 10:58人气: 2
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

SWL-4CHR-FUS-01

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall dimensions762 x 762 x 871 mm
Maximum seat height521 mm
Minimum seat height419 mm
Seat width533 mm
Seat depth533 mm
Seat cushion thickness152 mm
Backrest total height457 mm
Integrated armrest height above seat203 mm
4-star base diameter686 mm
Central gas lift stem diameter50 mm
Finished Seat Cushion Thickness90 mm
Backrest Padding Thickness70 mm
Lumbar Support Zone Height240 mm
Clear Width Between Armrests540 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Recommended static load capacity136 kg
Assembled net weight20 kg
360-degree swivel rotation360 °
Gas lift height adjustment stroke120 mm
Fabric abrasion resistance (Martindale)30000 cycles
Seat foam density45 kg/m³
Back foam density35 kg/m³
Foam rebound rate55 %
Seat Foam Density / Rebound Reference45 kg/m³ / 65%
Back Foam Density Reference38 kg/m³
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Outer back/arm shell upholsteryFuchsia woven polyester-linen look fabric
Inner seat/back padded cushionsHigh-resilience polyurethane foam with fibre wrap
Internal support frame12 mm thick moulded plywood and polypropylene shell
Central support stemPolished chrome-plated steel tube
4-star base structure1.5 mm thick polished chrome-plated cast aluminium
Floor contact glides10 mm diameter nylon with felt bottom pads
Seat underside mechanism plate3 mm thick black powder-coated steel
Upholstery stitching10 mm seam pitch, matching fuchsia thread
Seat Internal Support Board Thickness14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness14 mm bent plywood/composite reinforced frame
Gas-lift Engineering SpecificationRecommended Class 4; outer tube 50 mm; stroke 100 mm
Tilt Mechanism Plate Thickness2.5 mm cold-rolled steel
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Height adjustment mechanismSide-mounted lever actuates Class 3 gas lift to adjust seat height 120 mm
Swivel functionFull 360° horizontal rotation on sealed ball bearing joint
Floor protectionFixed non-marking felt glides prevent floor scuffing, no rolling casters
Ergonomic supportTwo-section contoured back padding provides lumbar and upper back support
Wrap-around arm supportIntegrated curved armrests form continuous bucket seat edge for elbow support
Stability designWide 4-star spider base distributes weight for stable stationary seating
Upholstery maintenanceFixed upholstery over contoured cushions for wrinkle-free surface
Recline Angle / Lock Reference125° with 3suggested lock positions
Tilt Tension User-weight RangeReference adjustment coverage 120 kg
Rotation / Mobility Configuration360° swivel with 5-caster multidirectional movement
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Carton Dimensions850× 420× 720 mm
Reference Packaged Gross Weight23 kg/set
Reference Carton Volume0.26 m³/set
Indicative 20GP Loading135 sets at 85% space utilization
Indicative 40HQ Loading320 sets at 85% space utilization
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Office reception areasProvides comfortable guest seating with 360° swivel for visitor interaction
Executive private office lounge zonesAdds stylish adjustable seating for casual meetings and breaks
Boutique hotel lobbiesDelivers modern aesthetic and durable construction for high-traffic public areas
Co-working breakout spacesSupports flexible seating arrangements with stable non-rolling base
Residential home office spacesOffers lounge comfort paired with functional height adjustment for mixed use
Waiting room environmentsContoured padding supports extended seated comfort for waiting guests
Recommended Matching Desk Size2.4 m executive desk
Reference Daily Use Duration8 hours/day; confirm by ergonomic testing
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

Seating strength and stabilityEN 16139:2013
Upholstered furniture flammabilityEN 1021:2014
Furniture hardware durabilityEN 12520:2015
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

Lounge seating safetyANSI/BIFMA X2022
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

Upholstered furniture safetyGB 28007
Formaldehyde emission limitsGB 18580
Metal furniture coatingGB/T 3324
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. Upholstered furniture safety:GB 28007;
2. Formaldehyde emission limits:GB 18580;
3. Metal furniture coating:GB/T 3324;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · SWL-4CHR-FUS-01

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · SWL-4CHR-FUS-01

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · SWL-4CHR-FUS-01打开导出工具

页面快速操作

发布采购询价

产品描述

The Fuchsia Fabric Upholstered Height-Adjustable Swivel Lounge Armchair is a contemporary seating solution defined by its bold, cohesive bucket-style silhouette. Its form features integrated wrap-around armrests that flow seamlessly from the contoured backrest to create an enclosed, inviting seat profile, paired with a sleek polished chrome 4-star base that balances soft upholstered texture with reflective metallic detailing. The vibrant fuchsia woven polyester-linen look fabric is stitched with matching thread at a consistent seam pitch, creating a smooth, wrinkle-resistant surface across the outer shell, back, and armrests. Beneath the upholstery, a moulded inner support shell constructed from thick bent plywood and polypropylene provides structural rigidity, while high-resilience polyurethane cushions with fibre wrap form the seat and back. The seat uses higher-density foam paired with a thick padded cushion, while the back uses contoured two-section padding to support both lumbar and upper back regions. The central chrome-plated steel stem connects the seat assembly to a wide 4-star cast aluminium base, finished with fixed nylon glides fitted with felt bottom pads. A black powder-coated steel mechanism plate under the seat houses the height adjustment hardware. This armchair delivers full 360-degree horizontal rotation via a sealed ball bearing joint, with a side-mounted lever operating a gas lift to adjust seat height across a 120 mm stroke. The fixed non-marking glides prevent floor scuffing and eliminate unintended movement, as no rolling casters are included, while the wide base distributes weight evenly for stable stationary seating. The fabric’s abrasion resistance supports regular use in high-traffic settings, and the fixed upholstery maintains a neat, tailored appearance over time. The chair suits a range of commercial and residential spaces: it works well in office reception areas to support comfortable guest interaction, adds stylish casual seating for breaks and informal meetings in executive private office lounge zones, brings durable modern design to boutique hotel lobbies and shared waiting rooms, supports flexible arrangements in co-working breakout spaces thanks to its stable non-rolling base, and blends lounge comfort with functional adjustability for residential home offices. When procuring this model, note that it ships unbranded in two cartons per set, with an assembly time of 40 minutes per unit. Plan for storage and delivery logistics in line with packaged dimensions and weight, and confirm the static load capacity aligns with intended use cases. The fixed glides make it best suited for spaces where stationary, stable seating is preferred over wheeled mobility.
