Two-Tone Upholstered Swivel Lounge Armchair with Matching Ottoman Specifications

LGS-4S-TT01

代码:3Z91T3V1
获取供应商报价
2026-09-20 13:37人气: 2
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

LGS-4S-TT01

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall chair dimensions860 x 840 x 1110 mm
Overall ottoman dimensions550 x 500 x 440 mm
Chair seat height440 mm
Chair seat width530 mm
Chair seat depth560 mm
Chair backrest height above seat670 mm
Chair armrest height above seat180 mm
4-star base leg spread (chair)780 mm
4-star base leg spread (ottoman)620 mm
Ottoman top height above floor430 mm
Finished Seat Cushion Thickness90 mm
Backrest Padding Thickness70 mm
Lumbar Support Zone Height240 mm
Clear Width Between Armrests540 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Recommended static weight capacity (chair)120 kg
Recommended static weight capacity (ottoman)80 kg
Total set net weight23 kg
Seat suspension load deflection38 mm
Swivel rotation range360 degrees
Seam stitch pitch8 stitches per inch
Seat Foam Density / Rebound Reference45 kg/m³ / 65%
Back Foam Density Reference38 kg/m³
Upholstery Thickness / Abrasion Reference1.4 mm / 50000 cycles
Five-star Base Static Load ReferenceAcceptance target ≥120 kg; chair reference load 150 kg
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Seat, inner back and inner arm upholsteryWoven textured polyester fabric
Outer back and outer shell upholsterySmooth matte burgundy performance upholstery
Seat and back padding core40kg/m³ high-density polyurethane foam
Top upholstery padding layer20mm soft synthetic fiber wrap
Internal support frame18mm thick molded plywood with 1.2mm steel reinforcement
Seat support system3.8mm gauge sinuous zig-zag springs
Chair and ottoman swivel basesMatte black powder-coated 2mm thick steel 4-prong spider legs
Swivel mechanismLubricated steel ball-bearing swivel plate
Seat Internal Support Board Thickness14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness14 mm bent plywood/composite reinforced frame
Gas-lift Engineering SpecificationRecommended Class 4; outer tube 50 mm; stroke 100 mm
Tilt Mechanism Plate Thickness2.5 mm cold-rolled steel
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

360-degree swivel rotationSmooth ball-bearing rotation without tilt or height adjustment
Enveloping ergonomic supportCurved winged back and integrated arms support full upper body
Matching ottoman alignmentOttoman geometry matches chair styling and base design for coordinated foot support
Non-marring floor contactEach base leg has a small plastic floor glide to prevent surface damage
Fixed recline posture110-degree fixed relaxed back angle with no manual recline adjustment
Easy maintenance accessTaut upholstered surface allows regular vacuuming and spot cleaning
Recline Angle / Lock Reference125° with 3suggested lock positions
Tilt Tension User-weight RangeReference adjustment coverage 120 kg
Height Adjustment Stroke100 mm continuous travel
Rotation / Mobility Configuration360° swivel with 5-caster multidirectional movement
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Carton Dimensions850× 420× 720 mm
Reference Packaged Gross Weight23 kg/set
Reference Carton Volume0.26 m³/set
Indicative 20GP Loading135 sets at 85% space utilization
Indicative 40HQ Loading320 sets at 85% space utilization
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Residential living room placementPositioned near sofas or windows as primary casual reading and relaxation seating
Hotel lobby and guest room useInstalled in hospitality common areas or suites for contemporary guest seating
Office lounge and breakout areasDeployed in informal work break spaces for relaxed employee and visitor use
Studio waiting areasUsed in creative studios, salons or boutique waiting spaces for comfortable guest seating
Recommended placement clearanceMaintain 300mm clearance behind chair for unobstructed 360° swivel movement
Recommended Matching Desk Size2.4 m executive desk
Reference Daily Use Duration8 hours/day; confirm by ergonomic testing
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 1022:2018Stability test standard applicable to residential seating furniture
EN 12520:2015Strength, durability and safety requirements for domestic seating
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

North America procurement and testing referenceRecommended references: ANSI/BIFMA X5.4
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements applicable to wooden and upholstered household furniture
GB 18584-2001Indoor decoration material formaldehyde emission limit applicable to furniture components
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements applicable to wooden and upholstered household furniture;
2. GB 18584-2001:Indoor decoration material formaldehyde emission limit applicable to furniture components;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · LGS-4S-TT01

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · LGS-4S-TT01

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · LGS-4S-TT01打开导出工具

页面快速操作

发布采购询价

产品描述

The JUESHANGDA Two-Tone Upholstered Swivel Lounge Armchair with Matching Ottoman, model LGS-4S-TT01, is a coordinated lounge seating set defined by a modern, organic silhouette with a distinct two-tone upholstery treatment. The set pairs a curved, wing-backed armchair with a geometrically matched ottoman, both fitted with matte black powder-coated 4-prong spider steel bases for visual cohesion. The chair features integrated arms and a tall, enveloping back that flows seamlessly into its base structure, with the ottoman scaled to align with the chair’s proportions for a unified, polished look across any placement. The set is constructed with durable, thoughtfully selected materials for long-term regular use. The seat, inner back, and inner arm surfaces are upholstered in woven textured polyester fabric, while the outer back and shell use smooth matte burgundy performance upholstery to create the signature two-tone effect. Padding consists of a high-density polyurethane foam core wrapped in a soft synthetic fiber layer, supported by an internal frame of molded plywood with steel reinforcement, sinuous zig-zag springs, and bent plywood seat support. The 360-degree swivel function operates via a lubricated steel ball-bearing plate, with each base leg fitted with a non-marring plastic glide to protect floor surfaces. Upholstery seams are finished with consistent, even stitching, and the taut fabric surface supports simple regular maintenance via vacuuming and spot cleaning. Functional design prioritizes relaxed, supported seating: the chair offers enveloping ergonomic upper body support with a fixed relaxed back angle, paired with smooth full rotation without tilt or height adjustment. The matching ottoman provides aligned foot support to enhance resting comfort, with weight ratings suited for regular casual use. The set fits equally well in residential and commercial spaces: in homes, it serves as primary casual seating for reading and relaxation near living room sofas or windows; in commercial settings, it works for hotel lobbies and guest rooms, office lounge and breakout areas, and creative studio, salon, or boutique waiting spaces. For procurement, note that each set ships in two cartons, with assembly taking roughly the referenced time per unit. When planning placement, maintain sufficient clearance behind the chair to allow unobstructed full swivel movement.
