基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 700 × 700 × 1100 mm | |
|---|---|---|
| Tabletop diameter | 700 mm | |
| Tabletop thickness | 20 mm | |
| Pedestal column diameter | 80 mm | |
| Cross base footprint | 600 x 600 mm | |
| Under-table leg clearance height | 1020 mm | |
| Single base prong length | 300 mm | |
| Base prong ground contact thickness | 12 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Net product weight | 40 kg | |
|---|---|---|
| Static tabletop load capacity | 227 kg | |
| Recommended seating capacity | 4 persons | |
| Surface abrasion resistance | 6000 cycles | |
| Metal frame rust resistance service life | 5 years | |
| Assembly fastener torque rating | 12 N·m | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Tabletop surface | Polished marble-veined natural stone slab | |
|---|---|---|
| Tabletop edge | Straight polished eased edge | |
| Support column | Brushed finish 304 stainless steel tube | |
| Cross base prongs | Brushed stainless steel formed sections | |
| Mounting hardware | Zinc-plated steel connection plates and screws | |
| Base foot pads | Non-slip TPE rubber floor protectors | |
| Metal surface treatment | Anti-fingerprint brushed clear coat | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Height adjustment | Fixed non-adjustable 1100mm bar height | |
|---|---|---|
| Floor leveling | Fixed rubber foot pads without adjustable glides | |
| Assembly structure | Knockdown 3-piece design for flat-pack shipping | |
| Cable management | No built-in wire channel or power module | |
| Surface maintenance | Sealed polished stone surface resistant to water spills | |
| Stability design | Symmetric 4-prong cross base prevents tipping under edge load | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Commercial cafe bistro seating | Pairs with bar stools for casual drink and small plate service | |
|---|---|---|
| Office lounge collaboration area | Provides standing-height space for quick informal meetings | |
| Residential home bar or kitchen island extension | Adds extra elevated serving space for home entertaining | |
| Hotel lobby welcome refreshment station | Serves as compact elevated table for beverage and display placement | |
| Outdoor covered patio seating | Stainless steel base resists moisture in sheltered outdoor spaces |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
本产品须满足以下技术参数要求: 1. 技术标准与检测报告由供应商在投标或采购确认阶段提供; 最终交付参数、检测报告和验收标准以双方采购合同为准。
