Light Gray Lockable Outdoor Storage Utility Cabinet with Upper Open Shelf Specifications

ODC-GRY-980

代码:0B6GQSV1
获取供应商报价
2026-08-28 12:27人气: 30
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

ODC-GRY-980

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall dimensions980 x 500 x 950 mm
Upper open shelf internal dimensions920 x 420 x 280 mm
Middle work surface height above floor600 mm
Lower enclosed cabinet internal dimensions920 x 450 x 570 mm
Elevated foot ground clearance80 mm
Door panel thickness4 mm
Interior adjustable shelf depth430 mm
Top shelf rear lip height30 mm
Carcass Panel Thickness25 mm
Back Panel Thickness9 mm
Door / Drawer Front Thickness22 mm
Shelf Thickness25 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Net product weight25 kg
Total static load capacity120 kg
UV-resistant service life10 years
Door hinge cycle rating10000 open/close cycles
Work surface load width940 mm
Shelf Distributed Load30 kg/shelf
Drawer Slide Load / Life45 kg/pair; 50000 cycles
Hinge Opening Angle / Life165°; 80000 cycles
Anti-tip Fixing ReferenceProducts above 1200 mm should use at least 2 wall fixing points
Recommended Procurement WarrantyCarcass 5 years; hardware 3 years; finish 2 years
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Exterior panelsUV-stabilized HDPE resin with vertical ribbed texture
Internal support framePowder-coated galvanized steel
Door hingesStainless steel 304 grade
Integrated work surfaceMolded HDPE resin with matte non-slip finish
Elevated support feetMolded high-density polymer foot pads
Door lock assemblyKeyed zinc alloy lock cylinder
Interior adjustable shelfMulti-wall HDPE resin with metal support pins
Edge trimIntegrated molded resin edging
Edge Band Thickness2 mm
Primary Connector SpecificationReference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints
Reference Finish / Color CountRecommended 6finish options
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Lower door lockingCentral keyed cylinder lock secures both double doors
Door operationDual hinged doors open 180 degrees outward for full interior access
Elevated base ventilation80 mm ground gap allows air circulation under unit
Interior shelf adjustability1 adjustable shelf with 3 height positions in lower cabinet
Upper open storageFixed recessed open shelf with rear lip for frequently used items
Weather protectionOverlapping door seams and integrated top lip shed rainwater
Assembly requirementKnock-down flat pack assembly with included hardware
Anti-tip securityWall anchor bracket included for securing unit to vertical surfaces
Cable / Vent Opening ReferenceIf fitted, 80 mm diameter
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Package Dimensions2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight100 kg/set in 3 cartons
Reference Packaging Volume0.65 m³/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Residential garden and patioOutdoor storage for gardening tools, soil, pots and outdoor accessories
Balcony utility storageCompact footprint fits apartment balconies for cleaning supply and tool storage
Outdoor potting workstationMiddle work surface provides space for planting and garden prep tasks
Garage side storageFreestanding unit organizes automotive supplies, outdoor toys and seasonal items
Poolside equipment storageWater-resistant panels hold pool chemicals, cleaning tools and accessories
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 581-1:2017Outdoor furniture seating and tables safety requirements, applicable for structural safety
EN 14749:2016Domestic and kitchen storage units safety requirements, applicable for cabinet stability
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for furniture storage cabinets, applicable for structural strength verification
GB/T 17657-2013Test method for surface physical and chemical properties, applicable for finish durability checks
GB/T 16422.3-2013Plastics laboratory light exposure, applicable for UV stability verification
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for furniture storage cabinets, applicable for structural strength verification;
2. GB/T 17657-2013:Test method for surface physical and chemical properties, applicable for finish durability checks;
3. GB/T 16422.3-2013:Plastics laboratory light exposure, applicable for UV stability verification;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · ODC-GRY-980

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · ODC-GRY-980

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · ODC-GRY-980打开导出工具

页面快速操作

发布采购询价

产品描述

The Light Gray Lockable Outdoor Storage Utility Cabinet (model ODC-GRY-980) is a freestanding exterior storage solution with a balanced, functional layout designed for flexible outdoor use. Presented in a neutral light gray finish, its exterior features vertical ribbed texturing across HDPE resin panels, with an elevated base that lifts the unit above ground level. The structure is organized into three distinct zones: a fixed recessed upper open shelf with a rear lip to prevent items from sliding backward, a mid-height integrated molded work surface, and a lower enclosed double-door cabinet, creating a streamlined vertical profile that fits compact outdoor footprints without compromising storage capacity. Built to withstand long-term outdoor exposure, the cabinet uses weather-resistant, UV-stabilized HDPE resin for all exterior panels, the integrated matte non-slip work surface, multi-wall interior adjustable shelf, elevated support foot pads, and integrated molded edge trim. Structural reinforcement comes from a powder-coated galvanized steel internal frame, paired with powder-coated steel hardware, 304-grade stainless steel door hinges, and a keyed zinc alloy lock cylinder. All door seams overlap and an integrated top lip directs rainwater away from interior contents, while the elevated base creates ground clearance that supports continuous air circulation under the unit to reduce moisture buildup. The double doors open 180 degrees outward to grant unobstructed access to the lower cabinet, which is secured by a central keyed lock that engages both doors simultaneously. The lower cabinet includes one adjustable shelf with three configurable height positions to accommodate items of varying sizes, while the upper open shelf keeps frequently used items within easy reach. This cabinet suits a wide range of residential and light commercial exterior spaces. It functions as dedicated garden and patio storage for gardening tools, growing media, plant pots, and outdoor accessories, and its compact footprint fits apartment balconies for organized storage of cleaning supplies and household tools. The middle work surface supports potting and garden preparation tasks, making the unit suitable for use as an outdoor potting workstation. It also serves as freestanding side storage in garages for automotive supplies, outdoor toys, and seasonal items, and its water-resistant construction makes it appropriate for poolside storage of pool chemicals, cleaning tools, and pool accessories. Procurement teams and residential buyers should note the unit is delivered as a knock-down flat pack with all required assembly hardware included, requiring on-site assembly. Freestanding placement removes the need for permanent wall or surface anchoring, allowing flexible repositioning as needs change. When planning for storage capacity, teams should account for per-shelf distributed load limits and total unit static load capacity to match stored items to the cabinet’s rated capabilities, and confirm available installation space aligns with the unit’s overall footprint to ensure proper fit and door clearance for full 180-degree opening.
