3-Door Horizontal Metal Outdoor Storage Shed Specifications

OUT-SHD-MTL-003

代码:KX0A5ZV1
获取供应商报价
2026-08-28 12:31人气: 27
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

OUT-SHD-MTL-003

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Primary Component Thickness40 mm according to load-bearing role
Hardware / Moving-part Clearance5 mm operating clearance
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Total internal storage volume3.2 cbm
Maximum roof distributed snow load50 kg/sqm
Total product net weight95 kg
Door panel static load capacity15 kg per door
Recommended maximum evenly distributed floor load200 kg/sqm
Corrosion resistance service life10 years
Reference Static Load150 kg depending on category
Moving-part Durability ReferenceAcceptance target 50000 cycles
Recommended Procurement WarrantyStructure 5 years; hardware 3 years
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Wall and roof panels0.4mm galvanized color steel with embossed wood grain powder coating
Structural frame members1.0mm thick galvanized steel square tubing
Top scalloped trimPressed galvanized steel with matching grey powder coat
Base bottom railGalvanized steel channel with corrosion-resistant finish
Door hinges and fastenersZinc-plated carbon steel hardware
Door lock/latch assemblyStainless steel 3-point latching system
Side corner postsRoll-formed galvanized steel with matching finish
Primary Connector SpecificationReference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color CountRecommended 6finish options
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Front access designThree full-height corrugated steel doors swing outward for full front access
Weather sealing systemContinuous EPDM rubber gaskets line all door edges to prevent water ingress
Internal ventilationTwo louvered vents at upper side walls reduce condensation buildup
Lockable securityCentral latching system accepts standard padlocks for secured storage
Internal anchor pointsPre-punched holes on base rail for anchoring to concrete or wooden foundations
Modular assemblyBolt-together panel design allows two-person on-site assembly without specialized tools
Reference Adjustment / Operating Range100 mm or 120° where applicable
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Packaging Volume0.8 m³/set
Reference Packaged Gross Weight120 kg/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Residential backyard storageStores garden tools, patio furniture cushions, and lawn equipment
Balcony utility storageFits on large apartment balconies for bicycle and household item storage
Small commercial site storageSecures maintenance tools and supplies at small retail or office exterior sites
Workshop accessory storagePlaced adjacent to home garages for bulky tool and supply overflow storage
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 10169-1:2010Applicable for specification of continuously organic coated steel sheet used for panels
EN 16121:2013Applicable for storage furniture safety, strength and durability requirements
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 1766-2008Applicable for rating powder coating weathering and corrosion resistance on steel surfaces
GB 28007-2011Applicable for structural safety requirements of outdoor metal storage furniture
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 1766-2008:Applicable for rating powder coating weathering and corrosion resistance on steel surfaces;
2. GB 28007-2011:Applicable for structural safety requirements of outdoor metal storage furniture;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · OUT-SHD-MTL-003

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · OUT-SHD-MTL-003

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · OUT-SHD-MTL-003打开导出工具

页面快速操作

发布采购询价

产品描述

The QILISEN 3-Door Horizontal Metal Outdoor Storage Shed, model OUT-SHD-MTL-003, is a robust outdoor storage solution built for reliable long-term exterior use. Its visual design features corrugated wall and roof panels finished with embossed wood grain powder coating, paired with pressed galvanized steel top scalloped trim in a matching grey finish, creating a structured, polished look that blends with both residential and light commercial exterior landscapes. The horizontal form factor positions three full-height front-facing doors that swing outward to deliver unobstructed full front access to the interior, eliminating awkward reach around narrow entryways. Construction prioritizes weather resilience and structural stability. Wall and roof panels are crafted from 0.4mm galvanized color steel, supported by a frame of 1.0mm thick galvanized steel square tubing, with roll-formed galvanized steel side corner posts and galvanized steel channel base rails treated with a corrosion-resistant finish. All door hinges and fasteners are zinc-plated carbon steel, paired with a stainless steel 3-point latching system, and major joints use M6-M10 connectors with a minimum of two fixing points for rigid assembly. Primary structural components are sized to 40mm thickness aligned with load-bearing requirements, with 5mm operating clearance for all moving hardware parts. The product supports a 10-year corrosion resistance service life, with a maximum roof distributed snow load of 50kg per square meter, recommended maximum evenly distributed floor load of 200kg per square meter, 15kg static load capacity per door panel, and 3.2 cubic meters of total internal storage volume. Functional features include continuous EPDM rubber gaskets lining all door edges to block water ingress, two upper side wall louvered vents to reduce internal condensation, pre-punched base rail holes for anchoring to concrete or wooden foundations, and a central latching system compatible with standard padlocks for secured storage. The bolt-together modular panel design enables two-person assembly without specialized tools, with a 40-minute assembly time per unit. This shed fits a range of spaces: residential backyards for storing garden tools, patio cushions and lawn equipment; large apartment balconies for bicycle and household item storage; small commercial exterior sites for securing maintenance tools and supplies; and areas adjacent to home garages for overflow storage of bulky workshop tools and supplies. Six finish options are available to match surrounding exterior aesthetics. For procurement, note that each unit ships in two cartons, with a packaged gross weight of 120kg and 0.8 cubic meter packaging volume, and the finished product has a 95kg net weight. Confirm foundation compatibility prior to installation, and select a finish option that aligns with site design requirements.
