基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 2000 × 900 × 750 mm | |
|---|---|---|
| Tabletop thickness | 30 mm | |
| Attached left side cabinet dimensions | 800 x 350 x 650 mm | |
| Upholstered cylindrical support diameter | 350 mm | |
| Metal Z-leg wall thickness | 12 mm | |
| Perimeter chair clearance under table | 680 mm | |
| Cabinet internal shelf height | 300 mm | |
| Tabletop overhang around supports | 100 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Tabletop static load capacity | 260 kg | |
|---|---|---|
| Recommended seating capacity | 6 users | |
| Tabletop heat resistance | 180 °C | |
| Tabletop surface abrasion resistance | 4000 cycles | |
| Product net weight (reference) | 185 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Tabletop | Polished blue natural luxury stone with nano anti-stain coating | |
|---|---|---|
| Left cylindrical support column | Steel inner frame wrapped in champagne beige faux leather upholstery | |
| Right Z-shaped support leg | Thick carbon steel with dark bronze powder-coated finish | |
| Left side storage cabinet carcass | 18mm thick E0-grade multi-layer engineered wood | |
| Cabinet back panel | 9mm thick moisture-resistant MDF with matching wood veneer | |
| Support base foot pads | 8mm thick non-slip rubber floor protectors | |
| Hardware fasteners | 304 stainless steel connecting bolts and brackets | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Left side cabinet storage | Enclosed compartment with one adjustable shelf to hold water buckets, waste bins and tea sets | |
|---|---|---|
| Tabletop surface function | Sealed non-porous surface supports wet tea service, resists tea stains and liquid spills | |
| Asymmetric support structure | Offset dual supports create unobstructed leg room for 6 perimeter seated guests | |
| Optional integrated tea system compatibility | Pre-cut cavity support for hidden induction cooker, auto water feed and drainage system in side cabinet | |
| Cabinet door access | Hinged side door opens 110 degrees for full access to stored tea service supplies | |
| Floor protection function | Rubber foot pads prevent hard surface scratches and reduce movement noise during use | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Executive office reception area | Serves 6 guests for formal business tea reception with integrated storage | |
|---|---|---|
| High-end residential tea room | Functions as a premium tea service station in villa or large apartment spaces | |
| Private club lounge | Provides durable, elegant tea service surface for high-traffic member hospitality | |
| Open-plan lounge breakout area | Offers perimeter seating for casual team or guest tea breaks in premium offices |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 12521:2015 | Furniture strength, durability and safety requirements for domestic tables | |
|---|---|---|
| EN 16122:2012 | Storage furniture for non-domestic use, applicable to attached side cabinet |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to cabinet carcass components | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard specification for dry-condition furniture use, applicable to engineered wood parts | |
| GB 18584-2001 | Indoor decorating material limit of harmful substances for wooden furniture |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to cabinet carcass components; 2. GB/T 4897.3-2015:Particleboard specification for dry-condition furniture use, applicable to engineered wood parts; 3. GB 18584-2001:Indoor decorating material limit of harmful substances for wooden furniture; 最终交付参数、检测报告和验收标准以双方采购合同为准。
