基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 2200 × 900 × 750 mm | |
|---|---|---|
| Sintered stone tabletop thickness | 12 mm | |
| Left gunmetal metal pedestal footprint | 600 x 400 mm | |
| Right smoked acrylic support panel thickness | 30 mm | |
| Recessed central tea tray channel length | 1200 mm | |
| Recessed central tea tray channel width | 200 mm | |
| Under-table seated knee clearance height | 680 mm | |
| Under-table clearance from floor to underside of top | 738 mm | |
| Table edge overhang past left pedestal | 300 mm | |
| Table edge overhang past right acrylic support | 300 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Tabletop uniform static load capacity | 150 kg | |
|---|---|---|
| Tabletop localized heat resistance | 1200 °C | |
| Recommended maximum seated user count | 6 people | |
| Product net weight range | 130 kg | |
| Surface stain resistance rating | Grade 5 | |
| Structural service life (commercial use) | 10 years | |
| Tabletop surface abrasion resistance | 6000 revolutions | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Tabletop | 12mm matte black sintered stone, polished square edges | |
|---|---|---|
| Left support pedestal | 1.5mm thick brushed gunmetal 304 stainless steel, rounded column form | |
| Right support panel | 30mm thick smoked bronze translucent acrylic, vertical T-shaped form | |
| Recessed tea tray channel | Matte black sintered stone integrated groove, sloped for drainage | |
| Support connection hardware | Zinc-plated steel M8 mounting bolts, anti-loosening lock washers | |
| Tabletop underside backing | 15mm thick high-density fiberboard reinforcement | |
| Surface finish on metal pedestal | Anti-fingerprint nano-coating, brushed texture | |
| Acrylic panel edge finish | Polished flame-treated smooth edge, no sharp corners | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Integrated recessed central tea tray channel | Sloped drainage groove directs spilled tea to hidden waste outlet | |
|---|---|---|
| Dual asymmetric pedestal support | Distributes weight evenly for stable placement on level hard floors | |
| Open under-table design | Provides unobstructed leg access for seating on both long sides | |
| Heat-resistant tabletop surface | Withstands direct placement of boiling teapots and heated kettles | |
| Non-porous easy-clean surface | Resists tea stains and requires only damp cloth wiping for maintenance | |
| Customization compatibility | Supports pre-drilled holes for optional integrated electric tea boiler | |
| Scratch-resistant hard surface | Resists scratches from ceramic teaware and metal serving accessories | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Executive office reception area | Serves as formal tea reception station for hosting visiting clients | |
|---|---|---|
| Open-plan meeting and lounge space | Supports small team discussions over tea service for 6 users | |
| High-end residential living room or study | Functions as premium tea table for home tea ceremony and casual gathering | |
| VIP lounge and clubhouse space | Provides dedicated tea service area for premium member hospitality | |
| Showroom and product display space | Works as display piece for premium tea set and furniture collection | |
| Balcony or sunroom leisure space | Suitable for casual tea drinking in light-filled residential leisure areas |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 15372:2016 | Furniture – Strength, durability and safety for non-domestic tables | |
|---|---|---|
| EN 13722:2004 | Furniture – Test methods for surface resistance to wet heat | |
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic tables |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for HDF backing components | |
|---|---|---|
| GB 6566-2010 | Limit of radionuclides in building materials, applicable for sintered stone top | |
| GB/T 4893.1-2021 | Furniture surface test for resistance to cold liquids, applicable for tabletop |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable for HDF backing components; 2. GB 6566-2010:Limit of radionuclides in building materials, applicable for sintered stone top; 3. GB/T 4893.1-2021:Furniture surface test for resistance to cold liquids, applicable for tabletop; 最终交付参数、检测报告和验收标准以双方采购合同为准。
