基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 1800 × 800 × 750 mm | |
|---|---|---|
| Overall assembled dimensions | 1800 x 800 x 750 mm | |
| Desktop thickness | 50 mm | |
| Under-desk knee clearance height | 680 mm | |
| Under-desk knee clearance width | 1400 mm | |
| Under-desk knee clearance depth | 650 mm | |
| Single drawer internal dimensions | 600 x 350 x 100 mm | |
| Metal support leg bar diameter | 20 mm | |
| Sled base footprint width | 400 mm | |
| Drawer front panel thickness | 18 mm | |
| Edge band thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Recommended maximum user weight for seated use | 136 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Surface abrasion resistance rating | 3000 cycles | |
| Net product weight | 65 kg | |
| Available color variants | 2 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Worktop surface | High-gloss faux white marble laminate over MDF core | |
|---|---|---|
| Support frame | Gold polished stainless steel tube frame with sled base | |
| Drawer fronts | High-gloss light grey lacquered MDF panels | |
| Drawer slides | Cold-rolled steel side-mounted ball-bearing slides | |
| Leveling feet | Injected plastic adjustable glides | |
| Edge banding | Matching high-gloss PVC edge trim | |
| Internal drawer panels | 15mm thick melamine-faced particle board | |
| Frame weld joints | Polished TIG-welded metal joints | |
| Worktop core density | 720 kg/m³ | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Drawer storage | Two full-width side drawers extend 350mm on ball-bearing slides for office supply access | |
|---|---|---|
| Floor leveling | Adjustable glides at base corners provide 10mm height adjustment for uneven floors | |
| Cable management | Concealed channel under desk rear routes power and data cables without surface clutter | |
| Surface maintenance | Non-porous glossy worktop resists liquid stains and wipes clean with standard office cleaners | |
| Weight distribution | Sled base distributes load evenly over carpet or hard flooring without leg indentation | |
| Assembly fitment | Knock-down frame attaches to worktop with pre-drilled cam-lock and bolt hardware | |
| Work surface utilization | 1800mm width supports dual monitors, laptop, and task lamp with remaining document space | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Home office study | Fits luxury residential studies for remote work and document handling | |
|---|---|---|
| Private executive office | Suits small corporate executive offices for computer and writing tasks | |
| Boutique consulting space | Works for client meeting and work areas in design or consulting studios | |
| Upscale apartment workspace | Complements modern minimalist and luxury interior design schemes | |
| Single user workstation | Designed for one seated user with sufficient surface area for daily work tasks |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 527-1:2011 | Office worktables and desks, safety and strength requirements | |
|---|---|---|
| EN 527-2:2016 | Office worktables, dimensional and safety requirements for work surfaces | |
| EN 12521:2015 | Furniture, strength, durability and safety requirements for domestic tables |
北美市场采购验货参考 * ANSI/BIFMA 标准
美国及加拿大家具标准
| ANSI/BIFMA X5.5-2021 | Desk Products standard for structural performance and durability | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units standard for drawer performance and cycle testing |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel components | |
|---|---|---|
| GB/T 3327-2017 | Strength and durability requirements for office desks and tables | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to desk panel components; 2. GB/T 3327-2017:Strength and durability requirements for office desks and tables; 3. GB 18584-2001:Indoor decoration material limit of harmful substances for wooden furniture; 最终交付参数、检测报告和验收标准以双方采购合同为准。
