3-Door Combination Office Bookcase with Upper Glass Storage and Lower Solid Door Storage Specifications

BC-3D-WOOD-1200

代码:42G5GBV1
获取供应商报价
2026-09-27 10:11人气: 3
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

BC-3D-WOOD-1200

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源:工厂资料结构化字段,最终以实测值为准

Overall dimensions1200 x 400 x 2000 mm
Carcass Panel Thickness25 mm
Back Panel Thickness9 mm
Door / Drawer Front Thickness22 mm
Shelf Thickness25 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源:产品性能数据,采购前请核对具体测试口径

Static load per shelf30 kg
Total cabinet static load capacity250 kg
Total enclosed storage volume0.7 m³
Net product weight85 kg
Recommended wall anchor load rating50 kg
Lock mechanism cycle life10000 operations
Shelf Distributed Load30 kg/shelf
Drawer Slide Load / Life45 kg/pair; 50000 cycles
Hinge Opening Angle / Life165°; 80000 cycles
Anti-tip Fixing ReferenceProducts above 1200 mm should use at least 2 wall fixing points
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源:以工厂材质清单与验货报告为准

Cabinet body panelsE1 grade particleboard with walnut wood grain veneer, 18mm thickness
Upper door panels5mm thick clear tempered glass, set in wood door frames
Door pull handlesPolished zinc alloy with brushed chrome finish, single-post mounting
Internal shelves18mm thick engineered wood with matching wood veneer, fixed mounting
Lock hardwareZinc alloy keyed cam locks, one per locking door section
Edge banding2mm thick PVC edge banding matching wood finish, heat-sealed to all panels
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源:功能配置参数,以供应商正式规格为准

Lockable storageTwo separate keyed locks secure upper glass section and right solid door
Display storageClear glass upper doors keep books and binders visible while reducing dust
Enclosed concealed storageLower solid wood doors hide stored items from direct view
Right side full-height storageSingle full-height solid door provides continuous tall storage space for oversize items
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源:外贸报价与装柜测算参考

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Package Dimensions2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight100 kg/set in 3 cartons
Reference Packaging Volume0.65 m³/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源:依据产品结构与品类整理的推荐应用场景

Executive office placementPositioned behind a desk to store reference documents and display awards
General office filing storageUsed in open work areas to organize archived documents and office supplies
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 14073-2:2004Applicable for safety requirements of office storage furniture
EN 14749:2016Applicable for structural strength and durability of domestic and storage units
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

北美市场选型与验收ANSI/BIFMA X5.9 办公储物单元
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017Applicable for general technical requirements of wooden office furniture
GB 18580-2017Applicable for formaldehyde emission limits for wood-based panel products
GB/T 4897.3-2003Applicable for particleboard used in furniture structural applications
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:Applicable for general technical requirements of wooden office furniture;
2. GB 18580-2017:Applicable for formaldehyde emission limits for wood-based panel products;
3. GB/T 4897.3-2003:Applicable for particleboard used in furniture structural applications;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · BC-3D-WOOD-1200

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · BC-3D-WOOD-1200

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · BC-3D-WOOD-1200打开导出工具

页面快速操作

发布采购询价

产品描述

The HAIBANG BC-3D-WOOD-1200 is a floor-standing 3-door combination office bookcase designed for balanced display and concealed storage, categorized under bookcases and open bookshelves. Its layout splits vertically into two functional zones: an upper section framed for clear glass panels, and a lower section fitted with solid wood-grain doors, plus a dedicated full-height solid door running the full cabinet height along the right side to accommodate oversized stored items. The unit presents a cohesive walnut wood grain finish across all visible surfaces, complemented by polished zinc alloy pull handles with a brushed chrome finish for a polished, professional aesthetic that aligns with formal office interiors. Constructed with durable engineered wood components, the cabinet uses E1 grade particleboard for body panels, finished with matching walnut veneer, and sealed with 2mm thick heat-sealed PVC edge banding that matches the wood finish on all panel edges to resist edge wear. Upper door panels are 5mm thick clear tempered glass set within wood door frames, while internal fixed shelves are built from 18mm thick engineered wood with matching veneer. Locking hardware consists of zinc alloy keyed cam locks, with one lock for each locking door section. Functional design supports multiple storage needs: the clear glass upper section keeps books, binders, and displayed items visible while reducing dust accumulation, while lower solid doors conceal stored items from direct view. Two separate keyed locks independently secure the upper glass section and the right solid door compartment to restrict access to sensitive materials. The full-height right-side storage bay offers continuous vertical space for tall or oversized items, while fixed internal shelves support distributed static loads to hold documents, supplies, and display pieces reliably. This bookcase is well suited for executive offices, where it can be positioned behind a desk to store reference documents and display professional awards, as well as for open general office work areas to organize archived documents and shared office supplies. For procurement planning, note that each unit ships in split cartons, requires on-site assembly, and is designed to pair with appropriate wall anchoring for stable installation. The enclosed storage volume supports both active work materials and archived items, making it a flexible storage solution for professional work environments.
