Wood Veneer Office Display Storage Cabinet with Glass Upper Doors and Solid Lower Doors Specifications

DISPCAB-WV-1200

代码:UR70FVV1
获取供应商报价
2026-09-27 10:17人气: 2
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

DISPCAB-WV-1200

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源:工厂资料结构化字段,最终以实测值为准

Overall dimensions1200 x 400 x 2000 mm
Carcass Panel Thickness25 mm
Back Panel Thickness9 mm
Door / Drawer Front Thickness22 mm
Shelf Thickness25 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源:产品性能数据,采购前请核对具体测试口径

Single shelf static load capacity30 kg
Lock security ratingKeyed alike cylinder lock for private storage access
Door swing angle110 degrees
Net weight95 kg
Anti-tip wall anchorage load rating50 kg
Shelf Distributed Load30 kg/shelf
Drawer Slide Load / Life45 kg/pair; 50000 cycles
Hinge Opening Angle / Life165°; 80000 cycles
Anti-tip Fixing ReferenceProducts above 1200 mm should use at least 2 wall fixing points
Recommended Procurement WarrantyCarcass 5 years; hardware 3 years; finish 2 years
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源:以工厂材质清单与验货报告为准

Cabinet carcass18mm E1 grade MDF core with walnut wood veneer finish, sealed with polyurethane topcoat
Upper display doors5mm clear tempered glass set in wood veneer door frames
Lower/right storage doors18mm matching wood veneer MDF panels with solid wood edge banding
Pull handlesBrushed zinc alloy vertical bar handles with polished chrome end caps
Internal shelves18mm matching veneer MDF adjustable shelves with metal shelf supports
LocksZinc alloy keyed cam locks fitted to lower and right door sets
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源:功能配置参数,以供应商正式规格为准

Display storage functionTwo upper glass-door compartments for visible display of decor, awards and reference books
Concealed storage functionTwo lower solid doors plus right full-height solid door for concealed document and supply storage
Shelf adjustabilityUpper section shelves support 50mm height adjustment via metal peg system to accommodate items of varying heights
Locking securityIndependent key locks secure lower storage and right full-height door for confidential item storage
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源:外贸报价与装柜测算参考

Number of shipping cartons1
Shipping carton dimensions1280 x 480 x 130 mm
Gross shipping weight105 kg
Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Package Dimensions2100× 700× 350 mm/carton according to carcass split
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源:依据产品结构与品类整理的推荐应用场景

Executive office applicationPlaced behind executive desks for display of awards and storage of confidential documents, matching traditional wood office furniture suites
Meeting room / reception applicationUsed in formal meeting rooms or reception areas to display corporate credentials, reference materials and decorative items
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 14749:2016Safety and strength requirements for domestic and office storage units, applicable for shelf load and stability testing
EN 12150-1:2015Thermally toughened soda lime silicate safety glass for cabinet door glazing
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

北美市场选型与验收ANSI/BIFMA X5.9 办公储物单元
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for wooden furniture, applicable for panel strength and finish quality acceptance
GB 18580-2017Formaldehyde emission limits for wood-based panels, requirement for E1 grade ≤0.124mg/m³ for indoor use
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable for panel strength and finish quality acceptance;
2. GB 18580-2017:Formaldehyde emission limits for wood-based panels, requirement for E1 grade ≤0.124mg/m³ for indoor use;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · DISPCAB-WV-1200

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · DISPCAB-WV-1200

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · DISPCAB-WV-1200打开导出工具

页面快速操作

发布采购询价

产品描述

The Wood Veneer Office Display Storage Cabinet with Glass Upper Doors and Solid Lower Doors (model DISPCAB-WV-1200) is an unbranded bookcase and open display cabinet with integrated closed storage, designed to balance visual presentation and secure storage for professional environments. Its vertical, structured layout features two upper glass-door display compartments, paired with two lower solid doors and a full-height right-side solid door, creating a balanced visual split between visible display and concealed storage. The warm walnut wood grain finish, clear tempered glass panels, and brushed zinc alloy vertical bar handles with polished chrome end caps deliver a polished, traditional professional aesthetic that complements classic wood office furniture suites. The cabinet’s carcass is built from 18mm E1 grade MDF core surfaced with walnut wood veneer sealed with a polyurethane topcoat, paired with 25mm thick horizontal shelves, 22mm thick door fronts, 25mm thick carcass panels, and a 9mm thick back panel. Upper display doors use 5mm clear tempered glass set in matching wood veneer frames, while lower and right storage doors feature matching 18mm wood veneer MDF panels finished with solid wood edge banding. All hardware is constructed from zinc alloy, including cam locks and pull handles. The upper glass compartments support open display of decor, awards, reference books, and corporate credentials, with adjustable shelves that support 50mm height increments via a metal peg system to accommodate items of varying heights, each shelf rated for 30kg static distributed load. The lower and full-height right compartments provide concealed storage for documents and office supplies, secured by independent zinc alloy keyed alike cylinder locks for private access to confidential materials, with doors that swing open 110 degrees for unobstructed access. Drawer slides are rated for 45kg per pair with a 50,000 cycle operational life, and the unit includes anti-tip wall anchorage rated for 50kg load for safe installation. This cabinet is suited for placement behind executive desks to display awards and store confidential documents in private offices, as well as for formal meeting rooms or reception areas to showcase corporate credentials, reference materials, and decorative pieces. For procurement, note that the unit ships as one complete set split across two cartons, with a net weight of 95kg and gross shipping weight of 105kg, requiring an 40 minutes of assembly per set, with all mounting hardware and adjustable shelf supports included for installation.
