Traditional Executive Wooden Office Bookcase with Glass Upper Doors and Solid Lower Doors Specifications

OFB-GLS3WD3-RW-1350

代码:YVM2EEV1
获取供应商报价
2026-09-27 13:12人气: 4
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

OFB-GLS3WD3-RW-1350

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源:工厂资料结构化字段,最终以实测值为准

Overall dimensions1350 x 400 x 2000 mm
Upper display section height1150 mm
Lower storage section height850 mm
Plinth base height80 mm
Single door width (each column)430 mm
Door frame moulding width30 mm
Upper glass door glass thickness5 mm
Upper shelf count per column3 units
Shelf spacing (upper section)330 mm
Lower cabinet internal shelf count per column1 unit
Lower internal storage clearance per zone360 mm
Vertical pull handle length120 mm
Carcass panel thickness18 mm
Back panel thickness9 mm
Door / Drawer Front Thickness22 mm
Shelf Thickness25 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源:产品性能数据,采购前请核对具体测试口径

Gross product weight95 kg
Single shelf static load capacity30 kg
Hinge cycle rating80000 open/close cycles
Anti-tip connector quantity2 units
Edge banding thickness1 mm
Standard warranty3 years
Available finish options4 units
Shelf Distributed Load30 kg/shelf
Drawer Slide Load / Life45 kg/pair; 50000 cycles
Hinge Opening Angle / Life165°; 80000 cycles
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源:以工厂材质清单与验货报告为准

Carcass and door panels18mm E0-grade engineered wood with red-brown wood grain veneer
Upper door panels5mm clear tempered glass set in wood frames
Door hardwareZinc alloy vertical bar pulls with brushed antique brass finish
Shelf panels18mm matching wood-grain engineered wood, adjustable on metal shelf pins
HingesCold-rolled steel concealed soft-close hinges
Base plinthMatching wood grain composite wood, finished to match door and carcass
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源:功能配置参数,以供应商正式规格为准

Door operation6 swing doors (3 upper, 3 lower) with 110-degree opening angle, fitted with soft-close hinges
Shelf adjustabilityUpper display shelves support 5-level height adjustment in 32mm increments
Storage zoningUpper glass-fronted open display zone for decorative items and reference books, lower solid-door concealed zone for archival storage
Installation configurationFreestanding unit with optional wall anchor anti-tip attachment, delivered flat-packed for on-site assembly
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源:外贸报价与装柜测算参考

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Package Dimensions2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight100 kg/set in 3 cartons
Reference Packaging Volume0.65 m³/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源:依据产品结构与品类整理的推荐应用场景

Executive office backdropPlaced behind executive desks to display awards, decor, and store reference materials
Conference room storageUsed to store meeting materials, presentation supplies, and corporate display items
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 14749:2016Safety and strength requirements for domestic and office storage furniture
EN 312:2010Performance specifications for particleboard used in furniture construction
EN 12521:2015Strength, durability and safety requirements for non-domestic storage furniture
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.9-2019Storage furniture performance standard for office environments, covering load and stability
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for wooden furniture, applicable to structural integrity and finish quality
GB 18580-2017Formaldehyde emission limit for wood-based panels, required for indoor office air quality compliance
GB/T 4897.3-2015Performance requirements for particleboard used in furniture structural components
GB 28007-2011Safety requirements for children's and adult storage furniture, covering anti-tip provisions
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to structural integrity and finish quality;
2. GB 18580-2017:Formaldehyde emission limit for wood-based panels, required for indoor office air quality compliance;
3. GB/T 4897.3-2015:Performance requirements for particleboard used in furniture structural components;
4. GB 28007-2011:Safety requirements for children's and adult storage furniture, covering anti-tip provisions;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · OFB-GLS3WD3-RW-1350

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · OFB-GLS3WD3-RW-1350

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · OFB-GLS3WD3-RW-1350打开导出工具

页面快速操作

发布采购询价

产品描述

The HAIBANG Traditional Executive Wooden Office Bookcase, model OFB-GLS3WD3-RW-1350, is a formal freestanding 6-door split-configuration wooden display storage cabinet designed for professional work environments. The unit features a balanced vertical layout: an upper glass-fronted display section sits above a lower solid-door storage compartment, supported by a matching wood-grain plinth base. Each of its three vertical columns holds a framed glass upper door and a solid wood-grain lower door, fitted with brushed antique brass zinc alloy vertical bar pulls, with subtle 30mm door frame moulding adding traditional visual detail. Constructed from 18mm E0-grade engineered wood finished in a rich red-brown wood grain veneer, the bookcase uses durable, coordinated materials across all components. Upper doors are set with clear tempered glass, while shelves are made from matching wood-grain engineered wood, adjustable via metal shelf pins. Cold-rolled steel concealed soft-close hinges support the swing doors, and edge banding provides a clean, finished look across all panel edges. The unit comes with two anti-tip connectors for optional wall anchoring. Functionally, the bookcase offers zoned storage tailored to office needs. The upper display zone includes adjustable shelves with multiple height positions, suited for showcasing decorative items, awards, and frequently accessed reference books, while the lower solid-door section provides concealed storage for archival materials and less frequently used supplies. Doors open to a wide angle with soft-close motion to reduce noise and impact, and each shelf supports stable static loading for everyday office items. This piece is ideally suited for placement as a backdrop behind executive desks, where it balances professional display and discrete storage, or in conference rooms to hold meeting materials, presentation supplies, and corporate display pieces. It is delivered flat-packed for on-site assembly. Procurement teams should note the unit is freestanding, with optional wall anchoring recommended for high-traffic areas, and that it is covered by a standard 3-year warranty. Four finish options are available to coordinate with existing office furniture. Stakeholders should plan for on-site assembly, and account for packaged shipping weight and volume when coordinating delivery and installation logistics, ensuring appropriate space allocation for the fully assembled unit in target rooms.
