mm / 英寸自动双单位换算 · 工程采购基础规格
| Overall dimensions (main desk + side return) | 2800 x 2200 x 750 mm | |
|---|---|---|
| Main worktop height | 750 mm | |
| Main worktop thickness | 50 mm | |
| Knee clearance width under main worktop (between pedestals) | 1500 mm | |
| Knee clearance height under worktop | 680 mm | |
| Side return (support pedestal) width | 600 mm | |
| Side return worktop depth | 800 mm | |
| Decorative grooved panel height per pedestal front | 450 mm | |
| Modesty panel height (central desk front) | 500 mm | |
| Desktop overhang front edge | 30 mm | |
| Base foot height (pedestal bottom clearance) | 20 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
净重 / 最大承重 / 适用人数 / 耐久性能
| net weight (fully assembled) | 260 kg | |
|---|---|---|
| Desktop static uniform load capacity | 150 kg | |
| Recommended applicable user count | 1 primary user, accommodates 2 additional guests across the desk for in-desk meetings | |
| product service life (with proper use) | 15 years | |
| Soft-close drawer cycle durability | ≥50000 open/close cycles | |
| Surface abrasion resistance (desktop) | ≥2000 revolutions (Taber CS-10 wheel) | |
| Drawer slide open/close cycle durability | ≥50000 cycles | |
| Desktop surface abrasion resistance | ≥2000 Taber CS-10 wheel revolutions | |
| Finish stain resistance rating | Grade 5per cross-hatch stain test | |
| Structural service life (commercial daily use) | 15 years |
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
| Desktop core | High-density E0 grade particleboard (engineered wood) | |
|---|---|---|
| Desktop surface | Matte dark wood veneer / anti-scratch melamine laminate | |
| Central front modesty panel | Matte dark grey lacquered MDF board | |
| Pedestal side decorative panels | Brushed bronze-tone powder-coated steel or aluminum alloy | |
| Pedestal outer end panels | Matte champagne bronze painted MDF or solid wood composite | |
| Internal drawer boxes | E1 grade MDF with dovetail or dowel joinery | |
| Drawer hardware | Soft-close full-extension ball bearing steel slides | |
| Adjustable feet | Nylon-padded steel levelers | |
| Internal support frame | 1.5mm thick square steel tube frame | |
| Desktop core substrate | High-density E0 grade particleboard, 48mm nominal thickness | |
| Desktop surface finish | Matte dark brown wood veneer with anti-scratch UV lacquer topcoat, 2mm thick PVC edge banding | |
| Pedestal outer decorative grooved panels | 1.2mm thick brushed bronze-tone powder-coated steel sheet over MDF substrate |
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
| Storage configuration | Dual side pedestals: left pedestal has 2 pull-out soft-close drawers for file/document storage; central section is closed modesty panel without storage; right pedestal has matching 2 soft-close drawers | |
|---|---|---|
| Drawer operation | Full-extension soft-close slides, drawers open silently and self-close from 50mm from fully closed position, no slamming | |
| Cable management | Built-in cable pass-through grommet with cover at rear center of main worktop, under-desk cable tray to route power/data cables from desktop to floor outlets | |
| Level adjustment | 4 adjustable feet (one per pedestal corner) with 10mm vertical adjustment range to compensate for uneven office flooring | |
| Work surface layout | L-shaped configuration with main front work surface for primary computer work, extended right side return for guest meetings, document placement or secondary office equipment | |
| Surface protection | Matte desktop surface is fingerprint-resistant and stain-resistant, suitable for daily office use with coffee cups, documents and electronic devices | |
| Leveling adjustment | 4 adjustable feet (one at each outer pedestal corner) provide 10mm vertical adjustment range to compensate for uneven office flooring and eliminate desk wobble | |
| Work surface function layout | Single continuous wide work surface with 700mm usable depth, with central 1400mm wide zone for primary user computer work and 700mm wide end zones for document placement, guest interaction or secondary office equipment | |
| Surface performance | Matte UV lacquer desktop finish is fingerprint-resistant and glare-resistant, suitable for 8+ hours of daily computer work without reflective screen interference | |
| Structural stability | Dual full-depth pedestal design eliminates cross-braces under the knee zone, allowing unobstructed leg movement and executive chair swivel without contact | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
经核验的外箱 / 毛重 / 组装 / 装柜数据
| Number of shipping packages | 5 flat-packed cartons | |
|---|---|---|
| Reference carton dimensions (largest carton, desktop section) | 2850 x 1150 x 120 mm | |
| Reference total gross shipping weight | 310 kg | |
| Reference total shipping volume (CBM) | 1.4CBM | |
| assembly time (2 trained installers) | 90 minutes | |
| 40HQ container loading quantity | 58units | |
| Number of flat-packed shipping cartons | 5 cartons | |
| Largest carton dimensions (desktop section) | 1450 x 1150 x 120 mm | |
| Total gross shipping weight (all packages) | 320 kg | |
| Total shipping volume | 1.3CBM |
推荐空间 / 目标用户 / 使用方式
| Primary application space | Executive offices for CEO, general manager or senior management in corporate headquarters, law firms or financial institutions | |
|---|---|---|
| Supporting furniture matching | Pairs with high-back leather executive office chairs, visitor seating, matching wall-integrated bookshelves and lounge sofa sets as shown in the render | |
| Usage scenario suitability | Suitable for daily computer work, document review, small in-office meetings with 2 guests, and confidential business discussions | |
| Recommended office size for placement | Minimum 25 sqm private office space (≥5m x 5m floor area) to allow clearance for chair movement, side tables and circulation around the desk | |
| Style compatibility | Fits contemporary, minimalist luxury, modern light commercial office interiors with marble wall finishes, neutral tone flooring and soft ambient lighting | |
| Recommended office space size for placement | Minimum 25 sqm private office (minimum 5m x 5m floor area) to allow 1000mm clearance around the desk for chair movement, guest circulation and side furniture placement | |
| Interior style compatibility | Fits contemporary minimalist luxury, modern commercial, and light luxury office interiors with marble wall finishes, neutral tone large-format tile flooring, soft indirect lighting and neutral fabric soft furnishings | |
| Secondary use case | Suitable for high-end conference room head tables or luxury private meeting room desks requiring large work surface and premium aesthetic appearance |
欧洲市场准入与化学品要求
| EN 527-1:2011 Office furniture - Work tables and desks - Part 1: Dimensions | Applicable for verifying ergonomic worktop height, clearance dimensions and dimensional tolerance | |
|---|---|---|
| EN 527-2:2019 Office furniture - Work tables and desks - Part 2: Safety, strength and durability requirements | Applicable for structural strength, stability and durability testing requirements | |
| EN 13986:2004 Wood-based panels for use in construction - Characteristics, evaluation of conformity and marking | Applicable for verifying engineered wood panel quality and formaldehyde emission performance |
美国及加拿大办公家具标准
适用于中国市场项目的标准
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable as primary acceptance standard for wooden desk structural stability, dimensional tolerance and finish quality | |
|---|---|---|
| GB/T 3327-2016 Office desks and tables | Applicable for desk ergonomic dimensions, load bearing and safety requirements | |
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applicable for formaldehyde and harmful emission limits for all wood-based panel components |
本产品须满足以下技术参数要求： 1. GB/T 3324-2017 General technical requirements for wooden furniture：Applicable as primary acceptance standard for wooden desk structural stability, dimensional tolerance and finish quality； 2. GB/T 3327-2016 Office desks and tables：Applicable for desk ergonomic dimensions, load bearing and safety requirements； 3. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture：Applicable for formaldehyde and harmful emission limits for all wood-based panel components； 最终交付参数、检测报告和验收标准以双方采购合同为准。
