基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 1000 × 1000 × 750 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Product net weight | 30 kg | |
|---|---|---|
| Evenly distributed static tabletop load | 160 kg | |
| Seating capacity | 4 people | |
| Surface water and stain resistance rating | Level 2 for commercial lacquered surfaces | |
| Gloss finish abrasion resistance | 2000 cycles | |
| Base static stability load | 220 kg | |
| Recommended warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Tabletop substrate | E1-grade medium-density fiberboard | |
|---|---|---|
| Tabletop surface finish | Multi-layer high-gloss white polyurethane lacquer | |
| Tabletop edge banding | 2mm thick PVC matching white finish | |
| Central support column | 1.5mm thick powder-coated black steel tube | |
| Base prong construction | 1.2mm thick polished chrome-plated steel tube | |
| Base foot pads | Non-slip 10mm thick rubber pads | |
| Assembly hardware | Grade 8.8 zinc-plated steel connecting bolts | |
| Finish coating thickness | 0.2mm | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Structure type | Fixed-height single central pedestal design | |
|---|---|---|
| Seating access | Unobstructed 360-degree knee clearance around full perimeter | |
| Assembly requirement | Knockdown assembly requiring attachment of base to tabletop | |
| Floor protection | Rubber foot pads prevent scratches to hard floors and carpet | |
| Surface maintenance | Smooth non-porous glossy surface allows wipe-clean sanitization | |
| Stability design | Four outward-splayed prongs distribute weight evenly to prevent tipping | |
| Customization compatibility | Compatible with alternative top finishes and diameter options | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Small office meeting rooms | Fits 4-person casual discussion settings with all-around access | |
|---|---|---|
| Cafe and casual dining spaces | Modern minimalist aesthetic suits contemporary food service interiors | |
| Residential dining nooks | 1000mm diameter fits small apartment dining areas without wasted space | |
| Break room and lounge areas | Provides stable surface for refreshments and informal staff gatherings | |
| Reception waiting areas | Serves as a side accent table for reading materials and decor | |
| Hotel guest room dining zones | Compact size fits standard hotel room layouts for in-room dining |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 15372:2016 | Furniture – Strength, durability and safety for non-domestic tables | |
|---|---|---|
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic dining tables | |
| EN 13722:2004 | Furniture – Test methods for surface finish resistance to staining and abrasion |
北美市场采购验货参考 * ANSI/BIFMA 标准
美国及加拿大家具标准
| ANSI/BIFMA X5.5-2021 | Office Furnishings – Desk Products, applicable for commercial meeting table use | |
|---|---|---|
| ANSI/BIFMA X5.1-2017 | General Purpose Office Chairs – Chair/table clearance compatibility standard |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop panel performance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade required for substrate | |
| GB/T 4893.9-2013 | Surface finish heat resistance test method, applicable to tabletop lacquer performance |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to tabletop panel performance; 2. GB 18580-2017:Formaldehyde emission limits for wood-based panels, E1 grade required for substrate; 3. GB/T 4893.9-2013:Surface finish heat resistance test method, applicable to tabletop lacquer performance; 最终交付参数、检测报告和验收标准以双方采购合同为准。
