基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 800 × 800 × 750 mm | |
|---|---|---|
| Tabletop diameter | 800 mm | |
| Tabletop thickness | 25 mm | |
| Central support column diameter | 80 mm | |
| Four-star base overall spread | 700 mm | |
| Base foot length (single prong) | 330 mm | |
| Knee clearance height under tabletop | 690 mm | |
| Knee clearance perimeter | Full 360-degree unobstructed | |
| Floor contact pad thickness | 5 mm | |
| Tabletop edge radius | 12 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Recommended maximum seated users | 3 | |
|---|---|---|
| Static distributed tabletop load capacity | 91 kg | |
| Base static stability load | 150 kg | |
| Tabletop surface scratch resistance | 2000 cycles | |
| Chrome base salt spray corrosion resistance | 48 hours | |
| Net product weight | 22 kg | |
| Recommended warranty period | 3 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Tabletop core | 18mm medium-density fiberboard | |
|---|---|---|
| Tabletop surface finish | High-gloss UV-cured dark brown lacquer | |
| Tabletop edge banding | 2mm dark brown ABS edging | |
| Central support column | 1.5mm thick chrome-plated steel tube | |
| Four-star base prongs | 2.0mm thick chrome-plated steel | |
| Floor protection pads | Non-marking black rubber pads | |
| Connection hardware | Zinc-plated steel mounting bolts | |
| Base plating thickness | 0.08mm decorative chrome plating | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Height adjustment | Fixed non-adjustable 750mm working height | |
|---|---|---|
| Floor leveling | Fixed rubber foot pads, no adjustable glides | |
| Surface utility | Smooth non-porous glossy surface, supports writing and device placement | |
| Assembly structure | Knock-down construction, tabletop attaches to column/base with bolts | |
| Seating access | 360-degree unobstructed leg access, no corner legs blocking seating | |
| Mobility | Static fixed placement, no integrated casters | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Small office meeting rooms | Seats 3users for quick internal discussions and check-ins | |
|---|---|---|
| Office reception and waiting areas | Provides compact surface for guest refreshments and materials | |
| Breakout and collaboration zones | Supports informal brainstorming and small team conversations | |
| Corporate visitor negotiation spaces | Professional glossy finish suitable for client meeting areas | |
| Coworking space common areas | Compact footprint fits flexible open-plan work environments | |
| Healthcare and public facility waiting rooms | Stable easy-to-clean surface for public area use |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 527-1:2011 | Office furniture: work tables and desks, safety and strength requirements | |
|---|---|---|
| EN 15372:2016 | Furniture: strength, durability and safety for non-domestic tables | |
| EN 13722:2004 | Furniture: surface resistance to cold liquids for laminated furniture tops |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop structural performance | |
|---|---|---|
| GB/T 3327-2018 | Furniture: tables for office and public use, applicable to stability and load requirements | |
| GB 18584-2001 | Indoor decorating and refurbishing materials: limit of harmful substances for wooden furniture | |
| GB/T 4893.8-2013 | Surface wear resistance test for furniture surfaces, applicable to tabletop finish |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to tabletop structural performance; 2. GB/T 3327-2018:Furniture: tables for office and public use, applicable to stability and load requirements; 3. GB 18584-2001:Indoor decorating and refurbishing materials: limit of harmful substances for wooden furniture; 4. GB/T 4893.8-2013:Surface wear resistance test for furniture surfaces, applicable to tabletop finish; 最终交付参数、检测报告和验收标准以双方采购合同为准。
