基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 2400 × 800 × 1100 mm | |
|---|---|---|
| worksurface height | 750 mm | |
| front privacy panel height | 1100 mm | |
| knee well recess depth | 450 mm | |
| knee well clear height | 680 mm | |
| worksurface thickness | 25 mm | |
| front panel thickness | 25 mm | |
| green accent panel size | 800 x 1000 mm | |
| edge banding thickness | 2 mm | |
| laminate surface thickness | 0.8 mm | |
| cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| worksurface static load capacity | 150 kg | |
|---|---|---|
| net product weight | 180 kg | |
| surface abrasion resistance | 2000 cycles | |
| recommended attendant capacity | 2 persons | |
| structural warranty period | 5 years | |
| surface stain resistance rating | Grade 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| core substrate | E1 grade high-density particleboard | |
|---|---|---|
| front facade finish | High-gloss white thermally fused laminate | |
| accent panel | Matte lime green laminate panel | |
| worksurface top layer | 0.8mm high-pressure laminate (HPL) | |
| edge treatment | 2mm thick PVC edge banding | |
| internal support frame | Powder-coated steel square tube | |
| leveling feet | Nylon adjustable glides | |
| cable management components | ABS plastic grommets and cable tray | |
| back panel | 18mm thick white melamine board | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| seated attendant workspace | Recessed knee well provides unobstructed leg room for 2 seated staff | |
|---|---|---|
| visitor greeting interface | Raised 1100mm front panel supports standing visitor interaction | |
| cable routing system | Dual 80mm grommets route monitor and power cords under worksurface | |
| floor leveling adjustment | Adjustable nylon glides compensate for 15mm floor height variation | |
| surface cleaning functionality | Non-porous glossy laminate surface supports wipe-down sanitization | |
| decorative accent customization | Replaceable green accent panel allows brand color matching | |
| wall anchoring provision | Pre-drilled rear brackets secure desk to lobby wall for stability | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| corporate office lobby | Long linear design fits wide entry spaces for visitor greeting and check-in | |
|---|---|---|
| shared attendant workspace | 2400mm width supports 2 reception staff working side-by-side | |
| high-traffic public areas | Durable HPL surface resists wear from daily visitor and staff use | |
| brand-customizable spaces | Green accent panel can be swapped to match corporate brand colors | |
| modern minimalist interiors | Clean glossy white facade complements slat wall and neutral lobby finishes |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for worksurface performance | |
|---|---|---|
| EN 13722:2004 | Furniture test for surface resistance to abrasion and staining, applicable for laminate finish | |
| EN 71-3:2019 | Migration of certain elements safety standard, applicable for public space furniture materials |
北美市场采购验货参考 * ANSI/BIFMA 标准
美国及加拿大家具标准
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable for commercial lobby desk load testing | |
|---|---|---|
| ANSI/BIFMA G1-2013 | Ergonomic desk height guideline, applicable for 750mm worksurface height validation |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural quality inspection | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 grade required for indoor office use | |
| GB/T 4897.3-2015 | Particleboard specification for furniture use, applicable for core substrateAcceptance |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable for structural quality inspection; 2. GB 18580-2017:Formaldehyde emission limit for wood-based panels, E1 grade required for indoor office use; 3. GB/T 4897.3-2015:Particleboard specification for furniture use, applicable for core substrateAcceptance; 最终交付参数、检测报告和验收标准以双方采购合同为准。
