基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 2400 × 600 × 1100 mm | |
|---|---|---|
| Work surface height above floor | 750 mm | |
| Work surface thickness | 50 mm | |
| Front privacy panel height | 1050 mm | |
| Mint green accent panel dimensions | 1600 x 700 mm | |
| Knee clearance height under work surface | 690 mm | |
| Knee clearance depth under work surface | 550 mm | |
| Edge banding thickness | 2 mm | |
| Leveling foot adjustment range | 20 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Countertop static load capacity | 300 kg | |
|---|---|---|
| Recommended maximum number of staff | 2 | |
| Paint surface scratch hardness | 2H | |
| Paint cross-hatch adhesion rating | 5B | |
| Unit net weight | 220 kg | |
| Leveling foot static load per foot | 80 kg | |
| Recommended commercial service life | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Desk carcass substrate | 18 mm thick E0-grade engineered wood panel | |
|---|---|---|
| Front privacy panel | 25 mm thick engineered wood with baked white paint | |
| Curved accent panel | 18 mm thick engineered wood with mint green baked paint | |
| Work surface finish | Matte white baked paint | |
| Internal support frame | 1.2 mm thick square steel tubing | |
| Cable management components | ABS plastic grommets and 0.8 mm thick steel cable tray | |
| Leveling feet | Nylon base with steel threaded stem | |
| Edge banding | 2 mm thick PVC edge trim | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Concealed cable routing | Dual grommets connect to under-desk cable tray | |
|---|---|---|
| Height-adjustable leveling feet | Four threaded feet adjust 20 mm | |
| Full front privacy screen | Solid panel extends from floor to 1050 mm height | |
| Continuous flat work surface | 2400 mm uninterrupted top for dual workstations | |
| Freestanding floor installation | No wall mounting required, self-supporting structure | |
| Smooth sealed surface | Non-porous baked paint finish | |
| Optional under-desk storage compatibility | Fits standard 400 mm deep mobile pedestals under work surface | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Corporate office lobby reception | High-privacy front panel creates professional first impression for visitors | |
|---|---|---|
| 2-staff reception workstation | 2400 mm width supports two simultaneous staff work positions | |
| Modern commercial entry spaces | Minimalist white and mint design complements contemporary office interiors | |
| Service counters for clinics or salons | Counter height and privacy panel suitable for client-facing service roles | |
| Open-plan co-working welcome areas | Freestanding design fits flexible shared workspace layouts | |
| High-traffic public entry points | Durable painted finish resists wear from daily visitor use |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 527-2:2002 | Office worktables safety and strength requirements for commercial desk work surfaces | |
|---|---|---|
| EN 13986:2004 | Wood-based panels for construction, dimensional stability and formaldehyde emission for indoor use |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel construction and dimensional tolerance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E0 grade ≤0.05mg/m³ for indoor commercial use | |
| GB/T 4897.3-2015 | Performance requirements for particleboard used in furniture structural applications |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable for panel construction and dimensional tolerance; 2. GB 18580-2017:Formaldehyde emission limits for wood-based panels, E0 grade ≤0.05mg/m³ for indoor commercial use; 3. GB/T 4897.3-2015:Performance requirements for particleboard used in furniture structural applications; 最终交付参数、检测报告和验收标准以双方采购合同为准。
