数据来源
可联系供应商获取生产周期与报价。
PRODUCT MODULE 01 / 06
基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源：工厂资料结构化字段，最终以实测值为准
| 产品外部尺寸（宽 × 深 × 高） | 660 × 700 × 1180 mm | |
|---|---|---|
| Seat width | Approx. 510 mm | |
| Seat depth | Approx. 490 mm | |
| Seat height range | Approx. 440-540 mm | |
| Backrest height above seat | Approx. 720 mm | |
| Backrest width (widest lumbar point) | Approx. 480 mm | |
| Integrated headrest height above backrest | Approx. 160 mm | |
| Armrest height above seat | Approx. 210-280 mm | |
| Armrest length | Approx. 240 mm | |
| Five-star base diameter | Approx. 700 mm | |
| Seat cushion thickness | Approx. 80-100 mm | |
| Backrest cushion thickness | Approx. 60-80 mm | |
| Integrated headrest dimensions | Approx. 320 mm wide x 160 mm tall | |
| Armrest top pad dimensions | Approx. 240 mm long x 80 mm wide | |
| Caster diameter | Approx. 50 mm | |
| Finished Seat Cushion Thickness | Approx. 70-90 mm |
PRODUCT MODULE 02 / 06
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源：产品性能数据，采购前请核对具体测试口径
| Net weight range | Approx. 18-22 kg | |
|---|---|---|
| Maximum recommended static load | Approx. 136 kg (300 lbs) | |
| Seat cushion foam density | Approx. 45-55 kg/m³ high resilience polyurethane | |
| Backrest cushion foam density | Approx. 35-45 kg/m³ high resilience polyurethane | |
| Foam rebound rate | Approx. 55-65% | |
| Caster rolling durability | ≥100,000 rolling cycles | |
| Seat sliding wear resistance (upholstery) | ≥50,000 Martindale cycles | |
| Seam stitch pitch | Approx. 8-10 stitches per 50mm | |
| Recommended user height range | 160-190 cm | |
| Gas lift durability | ≥100,000 height adjustment cycles |
PRODUCT MODULE 03 / 06
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源：以工厂材质清单与验货报告为准
| Seat, backrest and headrest upholstery | Taupe brown smooth leather or PU leather | |
|---|---|---|
| Cushion core padding | High-density molded polyurethane foam | |
| Inner backrest frame | Approx. 12-15mm thick plywood or welded steel frame | |
| Armrest support structure | Die-cast aluminum alloy with champagne bronze finish | |
| Armrest top pads | Same taupe brown upholstery over soft foam | |
| Five-star base | Polished die-cast aluminum alloy | |
| Gas lift cylinder | Chrome-plated steel SGS Class 3 gas lift | |
| Height adjustment mechanism | 2.5-3mm thick steel tilt-lock chassis | |
| Casters | 50mm diameter black nylon twin-wheel casters | |
| Tilt tension adjuster | Black plastic tension knob | |
| Seat cushion core padding | 45-55kg/m³ high-density molded polyurethane foam, 80-100mm thick | |
| Backrest cushion core padding | 35-45kg/m³ high-density molded polyurethane foam, 60-80mm thick |
PRODUCT MODULE 04 / 06
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源：功能配置参数，以供应商正式规格为准
| Seat height adjustment | 100mm vertical stroke via Class 3 gas lift, actuated by left-side paddle lever | |
|---|---|---|
| 360-degree swivel rotation | Full unobstructed 360° horizontal rotation around gas lift axis | |
| Synchro-tilt backrest recline | Backrest tilts up to 15 degrees from upright position, with synced seat tilt of 5 degrees | |
| Tilt position locking | Locks at 2 positions (fully upright, mid-recline) via left control lever | |
| Caster mobility | Dual-wheel casters roll freely on hard floors and low-pile carpet, brake not fitted | |
| Fixed height armrests | Non-adjustable padded armrests positioned at standard desk arm height | |
| Integrated cervical support | Curved fixed padded headrest section at top of backrest, aligned to neck height when reclined | |
| Lumbar contour support | Ergonomic curved backrest shaping providing passive lumbar support at 180-220mm above seat | |
| Synchro-tilt recline | Backrest tilts up to 15° from upright position, with synced 5° seat tilt to maintain leg angle, reducing thigh pressure during recline | |
| Tilt resistance adjustment | Tension adjusted via front-right rotary knob, adjustable to match user weights 50-136kg for personalized recline resistance | |
| Passive lumbar support | Ergonomic forward-curved backrest shaping providing passive lumbar support 180-220mm above seat surface, matching natural lumbar lordosis | |
| Recline Angle / Lock Reference | Approx. 90°-125° with 1-3 suggested lock positions |
PRODUCT MODULE 05 / 06
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源：外贸报价与装柜测算参考
| Number of shipping cartons | 1 carton | |
|---|---|---|
| Reference shipping carton dimensions | Approx. 780 x 680 x 580 mm | |
| Reference gross shipping weight | Approx. 22-26 kg | |
| Reference shipping volume (CBM) | Approx. 0.31 CBM per unit | |
| Estimated assembly time | 10-15 minutes per unit | |
| Reference 20ft GP container loading quantity | Approx. 180 units | |
| Reference 40ft HQ container loading quantity | Approx. 420 units | |
| Reference Package Count | 1 set / 1-2 cartons | |
| Reference Assembly Time | Approx. 15-40 minutes per set | |
| Reference Carton Dimensions | Approx. 760-850 × 330-420 × 620-720 mm |
PRODUCT MODULE 06 / 06
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源：依据产品结构与品类整理的推荐应用场景
| Executive private office | Suited for senior management workstations, matching dark wood or modern laminate executive desks for formal professional appearance | |
|---|---|---|
| Corporate conference rooms | Appropriate for boardroom and meeting room seating for long 1-3 hour meetings, providing upright and reclined postural support | |
| Home office executive setups | Suitable for premium home workspaces for professionals requiring all-day seating comfort with a refined aesthetic | |
| Managerial open-plan workstations | Usable for department manager workstations, combining professional appearance with ergonomic adjustment functionality | |
| Reception and VIP waiting areas | Suitable for formal guest seating in executive reception zones, presenting a polished, high-end visual impression | |
| Executive reception and VIP waiting areas | Suitable for formal guest seating in executive reception and VIP waiting zones, presenting a polished, high-end visual impression | |
| Private consultation rooms | Appropriate for legal, financial and executive consultation rooms, providing comfortable supportive seating for 1-2 hour client meetings | |
| Recommended Matching Desk Size | Approx. 1.8-2.4 m executive desk |
STANDARD S1
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| Applicable office chair safety standard | EN 1335-1:2020 Office furniture - Office work chairs - Part 1: Dimensions - safety requirements | |
|---|---|---|
| Applicable upholstery durability standard | EN 1335-2:2018 Office furniture - Office work chairs - Part 2: Safety requirements | |
| Applicable caster standard | EN 12529:2010 Castors and wheels - Castors for office furniture | |
| Office chair dimensional safety reference | EN 1335-1:2020 Office furniture - Office work chairs - Part 1: Dimensions - safety requirements | |
| Office chair mechanical safety reference | EN 1335-2:2018 Office furniture - Office work chairs - Part 2: Safety requirements | |
| Caster performance reference | EN 12529:2010 Castors and wheels - Castors for office furniture |
STANDARD S2
北美市场采购验货参考 * ANSI/BIFMA 标准
美国及加拿大家具标准
| Applicable office chair performance standard | ANSI/BIFMA X5.1-2017 Office Chairs - Tests | |
|---|---|---|
| Applicable caster performance standard | ANSI/BIFMA X5.9-2019 Casters | |
| Office chair performance reference | ANSI/BIFMA X5.1-2017 Office Chairs - Tests | |
| Caster performance reference | ANSI/BIFMA X5.9-2019 Casters |
STANDARD S3
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| Applicable standard for office chair safety | GB/T 3324-2017 General technical requirements for wooden furniture | |
|---|---|---|
| Applicable standard for upholstered furniture durability | GB/T 26397-2011 Office furniture upholstered office chair | |
| Applicable standard for hazardous substances | GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | |
| Office chair structural safety reference | GB/T 26397-2011 Office furniture - Upholstered office chair | |
| Hazardous substance limit reference | GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | |
| Hardware durability reference | GB/T 10357.3-2013 Test of mechanical properties of furniture - Strength and durability of chairs and stools |
招标文件标准化描述文本
本产品须满足以下技术参数要求： 1. Applicable standard for office chair safety：GB/T 3324-2017 General technical requirements for wooden furniture； 2. Applicable standard for upholstered furniture durability：GB/T 26397-2011 Office furniture upholstered office chair； 3. Applicable standard for hazardous substances：GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture； 4. Office chair structural safety reference：GB/T 26397-2011 Office furniture - Upholstered office chair； 5. Hazardous substance limit reference：GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture； 6. Hardware durability reference：GB/T 10357.3-2013 Test of mechanical properties of furniture - Strength and durability of chairs and stools； 最终交付参数、检测报告和验收标准以双方采购合同为准。
