基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 620 × 650 × 1000 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Net weight | 15 kg | |
|---|---|---|
| Recommended user weight capacity | 135 kg | |
| Suitable user height range | 1850 mm | |
| Seat foam density | 45 kg/m3 | |
| Back foam density | 35 kg/m3 | |
| Foam rebound rating | 40% | |
| Fabric or leather abrasion acceptance target | 50,000 Martindale cycles | |
| Gas-lift durability target | 100,000 height-adjustment cycles | |
| Caster rolling durability target | 100,000 cycles | |
| Suggested commercial warranty | 5 years |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Outer upholstery | Green leather-look surface with stitched padded seat and back panels | |
|---|---|---|
| Seat cushion | 80 mm high-resilience polyurethane foam on a load-bearing seat shell | |
| Back cushion | 90 mm layered polyurethane foam with horizontal lumbar contour | |
| Internal seat frame | 2.0 mm steel reinforcing plate beneath the plywood or molded seat shell | |
| Back support structure | 1.5 mm bent steel or reinforced polymer back bracket fixed to the mechanism | |
| Armrests | Upholstered curved pads on polished tubular steel side supports | |
| Five-star base | Polished aluminum-alloy five-star base with 2.5 mm wall section | |
| Gas lift | Black 50 mm steel telescopic gas lift with class 3 performance target | |
| Tilt mechanism | Black steel synchronized chassis with 2.5 mm plate and side actuating lever | |
| Casters | Black nylon twin-wheel casters with steel swivel stems | |
| Surface finish | Satin-polished metal base with matte black mechanism and caster components | |
| Seam construction | Continuous perimeter upholstery seam at 8 stitches per 100 mm |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Seat height adjustment | Pneumatic lift provides 80 mm travel through a 50 mm class-3 gas column | |
|---|---|---|
| Swivel function | 360-degree full rotation around the central gas-lift axis | |
| Tilt operation | Side lever controls recline with a 15-degree backward tilt angle | |
| Tilt lock | Single-position upright lock through the visible black under-seat lever | |
| Tilt tension control | Under-seat tension knob adjusts resistance for users up to 135 kg | |
| Mobility | Five 60 mm twin-wheel casters provide rolling movement on hard floors or low-pile carpet | |
| Arm support | Fixed curved armrests provide forearm support 220 mm above the seat | |
| Lumbar support | Integrated horizontal padded contour provides passive mid-lumbar support | |
| Seat orientation | Forward-tilting rounded cushion front reduces pressure behind the knees | |
| Base stability | 640 mm five-star base distributes load during swivel and recline | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Executive office | Suitable behind a 1800 mm executive desk where the 620 mm width preserves circulation space | |
|---|---|---|
| Private manager workspace | Appropriate for daily computer, meeting, and phone tasks with passive lumbar contour and swivel access | |
| Meeting or conference room | Usable around conference tables when seat height is adjusted to 520 mm | |
| Home office | Fits compact study rooms because the 650 mm depth and fixed arms reduce overall footprint | |
| Reception consultation area | Provides mobile visitor or consultant seating with polished base and coordinated armrest styling | |
| Procurement configuration | Order hard-floor casters for tile or wood floors and soft-floor casters for carpet | |
| Cleaning environment | Recommended for offices with regular dry wiping and periodic upholstery maintenance | |
| Recommended Matching Desk Size | 2.4 m executive desk |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 1335-1 applicability | Use for office-chair dimensions and ergonomic geometry verification | |
|---|---|---|
| EN 1335-2 applicability | Use for safety requirements including strength, stability, and structural durability | |
| EN 1335-3 applicability | Use for test methods covering seat, back, armrest, and base durability | |
| EN 1021-1 applicability | Use for cigarette-ignition upholstered-furniture flammability testing |
北美市场采购验货参考 * ANSI/BIFMA 标准
美国及加拿大家具标准
| ANSI/BIFMA X5.1 applicability | Use for office-chair safety, strength, stability, and durability acceptance in North America |
|---|
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 10357.3 applicability | Use for furniture strength and durability testing of chair seat and back | |
|---|---|---|
| GB/T 27923 applicability | Use for office-chair general technical requirements and quality inspection | |
| GB 18584 applicability | Use for limiting formaldehyde and harmful emissions from interior furniture materials |
本产品须满足以下技术参数要求: 1. GB/T 10357.3 applicability:Use for furniture strength and durability testing of chair seat and back; 2. GB/T 27923 applicability:Use for office-chair general technical requirements and quality inspection; 3. GB 18584 applicability:Use for limiting formaldehyde and harmful emissions from interior furniture materials; 最终交付参数、检测报告和验收标准以双方采购合同为准。
