Low-Back Upholstered Height-Adjustable Swivel Office Conference Chair Specifications

OFC-LB-062PU-CR

代码:V2JVGJV1
获取供应商报价
2026-08-13 09:35人气: 31
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

OFC-LB-062PU-CR

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall dimensions620 x 660 x 995 mm
Finished Seat Cushion Thickness90 mm
Backrest Padding Thickness70 mm
Lumbar Support Zone Height240 mm
Clear Width Between Armrests540 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Net product weight16 kg
Maximum static user load capacity150 kg
Recommended user body weight120 kg
Caster rolling durability cycles40000
Gas lift vertical stroke65 mm
Seating capacity1 person
Standard commercial warranty period3 years
Seat Foam Density / Rebound Reference45 kg/m³ / 65%
Back Foam Density Reference38 kg/m³
Upholstery Thickness / Abrasion Reference1.4 mm / 50000 cycles
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Seat and back upholsteryBlack smooth polyurethane (PU) leather
Cushion padding45kg/m³ high-density polyurethane foam
Integrated armrestsRigid molded PU over steel inner support
Five-star basePolished chrome-plated 2mm thick steel tube
Height adjustment gas liftClass 3 chrome-plated steel gas lift
Seat control mechanism2.5mm thick steel tilt/lock chassis
Casters50mm diameter black nylon hard-floor casters
Internal back frame12mm thick molded plywood
Seat Internal Support Board Thickness14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness14 mm bent plywood/composite reinforced frame
Tilt Mechanism Plate Thickness2.5 mm cold-rolled steel
Five-star Base Material ThicknessMetal base wall 3.5 mm; diameter 700 mm
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Seat height adjustmentPneumatic lift adjustment with 65mm vertical travel
360-degree swivel rotationFull 360-degree horizontal rotation enabled by central swivel joint
Smooth rolling mobilityFive caster-mounted points for free movement on hard floors
Backrest tilt function12-degree backward tilt with single-position lock
Fixed integrated armrestsNon-adjustable fixed armrests providing forearm support at 205mm height
Tilt tension adjustmentRotary knob adjusts tilt resistance to match user weight
Recline Angle / Lock Reference125° with 3suggested lock positions
Tilt Tension User-weight RangeReference adjustment coverage 120 kg
Rotation / Mobility Configuration360° swivel with 5-caster multidirectional movement
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Carton Dimensions850× 420× 720 mm
Reference Packaged Gross Weight23 kg/set
Reference Carton Volume0.26 m³/set
Indicative 20GP Loading135 sets at 85% space utilization
Indicative 40HQ Loading320 sets at 85% space utilization
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Corporate conference roomsLow-profile design ideal for meeting rooms and boardroom table setups
Executive private officesProfessional black upholstery suitable for guest seating opposite desks
Open office workstationsCompact footprint fits standard workstation layouts without excessive space
Visitor waiting areasSmooth upholstery and rolling base suit short-term guest seating applications
Home office spacesProfessional styling works for residential office workspaces requiring formal seating
Training room settingsDurable construction and mobility suit flexible training room reconfiguration
Recommended Matching Desk Size2.4 m executive desk
Reference Daily Use Duration8 hours/day; confirm by ergonomic testing
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 1335-1:2020Applies to office chair dimensional safety and performance requirements
EN 1335-2:2018Applies to structural strength and durability testing criteria
EN 1335-3:2009Applies to stability and safety verification for office seating
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.1-2017Applies to general-purpose office chair strength and durability benchmarks
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3326-2016Applies to dimensional tolerance and stability requirements for office seating
GB/T 22792.1-2009Applies to general safety requirements for office swivel chairs
GB 18587-2001Applies to formaldehyde emission limits for upholstered furniture materials
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3326-2016:Applies to dimensional tolerance and stability requirements for office seating;
2. GB/T 22792.1-2009:Applies to general safety requirements for office swivel chairs;
3. GB 18587-2001:Applies to formaldehyde emission limits for upholstered furniture materials;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · OFC-LB-062PU-CR

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · OFC-LB-062PU-CR

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · OFC-LB-062PU-CR打开导出工具

页面快速操作

发布采购询价

产品描述

The Low-Back Upholstered Height-Adjustable Swivel Office Conference Chair (model OFC-LB-062PU-CR) balances streamlined professional aesthetics with functional versatility for both commercial and residential seating needs. Presented in smooth black PU leather upholstery, the chair features a clean low-back profile paired with fixed, integrated armrests that create a neat, unobtrusive silhouette suited to formal and semi-formal space layouts. Its polished chrome-plated five-star steel base supports the central swivel joint, creating a stable, polished foundation complemented by black nylon casters that align with the chair’s understated, professional color palette. Built for regular daily use, the chair pairs its 45kg/m³ high-density foam padding (90mm thick at the seat, 70mm thick at the backrest) with durable underlying structures: a molded plywood internal back frame, bent plywood seat support, Class 3 chrome-plated steel gas lift, steel tilt/lock chassis, and rigid molded PU armrests formed over steel inner supports. This construction supports a single user, with a maximum static load capacity of 150kg and a recommended user weight of 120kg. Core functional features support flexible, comfortable use: pneumatic seat height adjustment delivers 65mm of vertical travel to align with varied table heights, full 360-degree swivel enables easy orientation during group discussions, and the backrest offers up to 125 degrees of recline with three lock positions, paired with a rotary tilt tension knob to adjust resistance to user preference. The 12-degree backward tilt with single-position lock adds quick support for upright focus or relaxed recline, while fixed armrests sit at a set height to provide consistent forearm support, and hard-floor nylon casters enable smooth, free movement across hard surface flooring. This chair is well suited to a broad range of settings: its low-profile design fits seamlessly around corporate conference room and boardroom tables, its polished black finish works for guest seating in executive private offices, its compact footprint aligns with open office workstation layouts, its smooth, easy-clean upholstery and mobile base support short-term seating in visitor waiting areas, its durable construction enables flexible reconfiguration in training rooms, and its formal professional styling suits residential home office spaces that require structured, work-appropriate seating. For procurement planning, note the chair carries a 3-year standard commercial warranty. Each unit ships across two cartons, with an assembly time of 40 minutes per set, and a packaged gross weight of 23kg. When planning bulk shipments, a 20GP container can hold 135 sets at 85% space utilization, supporting streamlined large-scale project ordering.
